SDO HMI 2014-02-25 18:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 37.18 | 123.78 | 26.52 | 87.77 | 8.42 | 132.48 | -42.90 | 70.69 | 0.7154 | 492.0 | 182.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-02-25 18:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.64 | 0.00 | 1.00 | 7.31 | 142.34 | -33.04 | 66.98 | 0.5899 | -869.0 | -688.7 | |
| 0.00 | 1.29 | 0.00 | 0.80 | 7.13 | 141.34 | -34.04 | 67.89 | 0.6017 | -680.0 | -477.7 | |
| 0.00 | 1.29 | 0.00 | 0.82 | 8.26 | 140.18 | -35.20 | 66.90 | 0.6224 | -706.0 | -582.3 | |
| 0.00 | 0.86 | 0.00 | 0.54 | 8.09 | 140.05 | -35.33 | 67.24 | 0.6231 | -679.0 | -581.0 | |
| 0.00 | 0.86 | 0.00 | 0.55 | 8.91 | 139.67 | -35.71 | 66.25 | 0.6323 | -636.0 | -563.2 | |
| 0.00 | 1.81 | 0.00 | 1.16 | 7.56 | 138.96 | -36.42 | 68.67 | 0.6342 | -592.0 | -484.7 | |
| 0.00 | 0.43 | 0.00 | 0.29 | 12.93 | 137.58 | -37.80 | 61.97 | 0.6791 | 510.0 | 409.6 | |
| 1.03 | 2.58 | 0.70 | 1.74 | 7.52 | 135.21 | -40.17 | 70.68 | 0.6800 | -616.5 | -448.1 | |
| 0.00 | 0.86 | 0.00 | 0.60 | 7.43 | 133.10 | -42.27 | 71.77 | 0.7046 | 702.0 | 655.2 | |
| 0.00 | 1.12 | 0.00 | 0.78 | 6.78 | 133.14 | -42.24 | 72.63 | 0.7018 | -419.0 | -324.1 | |
| 7.66 | 30.99 | 5.43 | 21.96 | 8.74 | 132.44 | -42.94 | 70.31 | 0.7174 | 1030.4 | 439.8 | |
| 0.00 | 1.29 | 0.00 | 0.91 | 7.33 | 132.13 | -43.24 | 72.32 | 0.7156 | 611.0 | 568.6 | |
| 0.00 | 1.38 | 0.00 | 0.98 | 7.62 | 131.98 | -43.40 | 72.00 | 0.7185 | 531.0 | 384.9 | |
| 28.49 | 74.11 | 20.39 | 53.26 | 8.38 | 131.71 | -43.67 | 71.12 | 0.7244 | 780.1 | 159.2 | |
| 0.00 | 1.81 | 0.00 | 1.31 | 9.22 | 131.50 | -43.88 | 70.10 | 0.7300 | 486.0 | 351.3 | |
| 0.00 | 0.69 | 0.00 | 0.50 | 9.40 | 131.30 | -44.08 | 69.96 | 0.7328 | 278.0 | 190.1 | |
| 0.00 | 0.77 | 0.00 | 0.57 | 9.38 | 130.76 | -44.62 | 70.22 | 0.7388 | 329.0 | 257.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
