SDO HMI 2014-02-26 05:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 126.24 | 585.14 | 67.25 | 311.30 | -1.40 | 148.96 | -20.37 | 74.94 | 0.3611 | -196.3 | -91.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-02-26 05:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 44.21 | 270.08 | 22.94 | 140.09 | -2.19 | 152.64 | -16.70 | 74.10 | 0.2998 | -1371.3 | -485.4 | |
| 0.86 | -1.00 | 0.45 | -1.00 | -2.02 | 152.18 | -17.16 | 74.04 | 0.3081 | -762.3 | 999999 | |
| 1.03 | -1.00 | 0.54 | -1.00 | -1.42 | 152.03 | -17.31 | 72.34 | 0.3135 | -970.8 | 999999 | |
| 1.64 | 8.45 | 0.86 | 4.41 | -0.90 | 151.78 | -17.55 | 71.05 | 0.3203 | -872.8 | -737.6 | |
| 0.00 | 1.72 | 0.00 | 0.90 | -0.66 | 151.78 | -17.55 | 70.35 | 0.3216 | -144.0 | -112.2 | |
| 1.38 | 3.36 | 0.72 | 1.76 | -0.70 | 151.13 | -18.21 | 71.15 | 0.3316 | -855.4 | -620.5 | |
| 0.00 | 1.12 | 0.00 | 0.59 | -2.04 | 151.05 | -18.28 | 75.11 | 0.3258 | -665.0 | -549.7 | |
| 0.60 | 2.07 | 0.32 | 1.09 | -0.90 | 150.97 | -18.37 | 71.89 | 0.3329 | -949.9 | -747.2 | |
| 0.34 | 2.41 | 0.18 | 1.27 | -1.14 | 150.94 | -18.40 | 72.60 | 0.3322 | -1061.2 | -815.3 | |
| 19.04 | 26.20 | 9.99 | 13.74 | -1.64 | 150.90 | -18.43 | 74.09 | 0.3301 | -1064.2 | -661.2 | |
| 0.00 | 1.12 | 0.00 | 0.59 | -2.50 | 150.77 | -18.57 | 76.73 | 0.3284 | 827.0 | 709.8 | |
| 0.00 | 1.90 | 0.00 | 1.00 | -1.54 | 149.77 | -19.56 | 74.77 | 0.3485 | -1123.0 | -951.8 | |
| 0.00 | 0.86 | 0.00 | 0.46 | -1.24 | 149.74 | -19.59 | 73.97 | 0.3504 | -763.0 | -628.8 | |
| 0.86 | 5.08 | 0.45 | 2.68 | -2.16 | 149.64 | -19.70 | 76.60 | 0.3478 | -1153.9 | -883.4 | |
| 0.00 | 5.08 | 0.00 | 2.69 | -1.79 | 149.52 | -19.82 | 75.68 | 0.3513 | -784.0 | -720.6 | |
| 0.86 | 8.88 | 0.46 | 4.69 | -2.51 | 149.47 | -19.86 | 77.69 | 0.3490 | -1092.5 | -781.6 | |
| 0.78 | -16.00 | 0.41 | -16.00 | -2.58 | 149.22 | -20.12 | 78.08 | 0.3527 | -829.3 | 999999 | |
| 0.00 | 1.38 | 0.00 | 0.73 | -1.95 | 149.07 | -20.26 | 76.46 | 0.3576 | -754.0 | -534.9 | |
| 0.00 | 0.69 | 0.00 | 0.37 | -2.78 | 148.33 | -21.01 | 79.19 | 0.3662 | -678.0 | -616.4 | |
| 0.00 | 0.86 | 0.00 | 0.46 | -2.89 | 148.01 | -21.33 | 79.66 | 0.3709 | -762.0 | -584.7 | |
| 0.00 | 1.38 | 0.00 | 0.74 | -2.74 | 147.98 | -21.36 | 79.28 | 0.3719 | -658.0 | -552.1 | |
| 1.90 | 5.77 | 1.01 | 3.09 | -2.42 | 147.63 | -21.70 | 78.66 | 0.3785 | -772.2 | -257.5 | |
| 1.12 | 49.98 | 0.60 | 26.96 | -1.99 | 146.77 | -22.56 | 78.10 | 0.3936 | 701.4 | 638.8 | |
| 0.00 | 0.69 | 0.00 | 0.37 | -3.26 | 146.59 | -22.75 | 81.37 | 0.3922 | 672.0 | 527.4 | |
| 2.76 | -23.00 | 1.49 | -23.00 | -2.25 | 146.57 | -22.76 | 78.85 | 0.3957 | 1206.7 | 999999 | |
| 1.03 | 3.88 | 0.56 | 2.09 | -2.75 | 146.37 | -22.97 | 80.19 | 0.3972 | 843.6 | 703.5 | |
| 0.00 | 3.71 | 0.00 | 2.00 | -1.49 | 146.30 | -23.04 | 77.16 | 0.4030 | 843.0 | 679.3 | |
| 12.67 | -23.00 | 6.85 | -23.00 | -2.11 | 146.22 | -23.11 | 78.72 | 0.4018 | 1077.6 | 999999 | |
| 0.00 | 1.29 | 0.00 | 0.70 | -1.26 | 145.85 | -23.49 | 76.89 | 0.4109 | 828.0 | 719.3 | |
| 0.00 | 1.64 | 0.00 | 0.89 | -1.45 | 145.39 | -23.95 | 77.61 | 0.4172 | 807.0 | 580.1 | |
| 0.00 | 0.95 | 0.00 | 0.52 | -0.95 | 145.00 | -24.33 | 76.69 | 0.4252 | 680.0 | 566.9 | |
| 0.00 | 1.81 | 0.00 | 0.99 | -1.22 | 144.48 | -24.86 | 77.61 | 0.4321 | 995.0 | 785.0 | |
| 0.00 | 2.93 | 0.00 | 1.61 | -1.39 | 144.34 | -24.99 | 78.08 | 0.4335 | 840.0 | 631.9 | |
| 16.03 | 163.65 | 8.83 | 90.39 | -0.10 | 144.29 | -25.05 | 75.25 | 0.4397 | 1281.2 | 450.8 | |
| 0.00 | 2.15 | 0.00 | 1.18 | -1.74 | 144.18 | -25.16 | 78.95 | 0.4348 | 727.0 | 667.9 | |
| 0.00 | 0.95 | 0.00 | 0.52 | -1.37 | 143.98 | -25.35 | 78.23 | 0.4391 | 597.0 | 480.5 | |
| 17.67 | -34.00 | 9.78 | -34.00 | 0.40 | 143.89 | -25.44 | 74.42 | 0.4479 | 957.2 | 999999 | |
| 1.46 | -34.00 | 0.81 | -34.00 | 0.02 | 143.80 | -25.54 | 75.31 | 0.4476 | 831.9 | 999999 | |
| 0.00 | 1.98 | 0.00 | 1.10 | 1.02 | 143.46 | -25.87 | 73.39 | 0.4572 | 743.0 | 605.9 | |
| 0.00 | 1.12 | 0.00 | 0.63 | -0.49 | 141.16 | -28.18 | 77.84 | 0.4850 | 655.0 | 441.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
