SDO HMI 2014-02-28 01:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 108.79 | 557.32 | 89.27 | 461.45 | -24.49 | 92.57 | -52.62 | 115.32 | 0.8001 | 37.6 | -3.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-02-28 01:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.78 | 0.00 | 0.52 | -17.90 | 103.65 | -41.53 | 108.85 | 0.6690 | 537.0 | 511.6 | |
| 0.00 | 1.03 | 0.00 | 0.76 | -24.21 | 98.37 | -46.82 | 116.29 | 0.7441 | 561.0 | 465.3 | |
| 0.00 | 0.78 | 0.00 | 0.60 | -24.82 | 96.30 | -48.88 | 116.54 | 0.7666 | -448.0 | -331.7 | |
| 5.43 | 247.25 | 4.13 | 186.71 | -23.74 | 96.56 | -48.62 | 115.21 | 0.7615 | 793.2 | 354.8 | |
| 1.47 | -4.00 | 1.11 | -4.00 | -23.30 | 96.63 | -48.55 | 114.66 | 0.7598 | 732.6 | 999999 | |
| 1.98 | -4.00 | 1.51 | -4.00 | -23.48 | 96.50 | -48.69 | 114.86 | 0.7616 | 644.3 | 999999 | |
| 42.41 | -4.00 | 31.99 | -4.00 | -22.69 | 96.83 | -48.35 | 113.91 | 0.7565 | 999.6 | 999999 | |
| 0.00 | 1.98 | 0.00 | 1.54 | -24.00 | 95.63 | -49.55 | 115.33 | 0.7715 | 414.0 | 318.7 | |
| 0.00 | 0.34 | 0.00 | 0.26 | -23.06 | 96.06 | -49.12 | 114.22 | 0.7652 | 135.0 | 134.8 | |
| 0.00 | 1.29 | 0.00 | 1.03 | -25.61 | 94.52 | -50.66 | 117.11 | 0.7858 | 394.0 | 311.3 | |
| 5.86 | 20.43 | 4.54 | 15.87 | -23.45 | 95.56 | -49.62 | 114.62 | 0.7710 | 419.5 | 62.9 | |
| 3.19 | -11.00 | 2.49 | -11.00 | -23.78 | 95.29 | -49.89 | 114.97 | 0.7744 | -214.1 | 999999 | |
| 0.00 | 0.34 | 0.00 | 0.27 | -23.57 | 95.10 | -50.08 | 114.66 | 0.7759 | -513.0 | -453.5 | |
| 0.00 | 5.17 | 0.00 | 4.08 | -24.05 | 94.79 | -50.39 | 115.20 | 0.7799 | -252.0 | -273.0 | |
| 0.00 | 1.47 | 0.00 | 1.14 | -23.26 | 95.16 | -50.02 | 114.28 | 0.7747 | 380.0 | 313.4 | |
| 0.00 | 1.90 | 0.00 | 1.49 | -23.55 | 94.95 | -50.23 | 114.62 | 0.7773 | -501.0 | -414.5 | |
| 0.00 | 2.67 | 0.00 | 2.13 | -24.29 | 94.30 | -50.88 | 115.40 | 0.7852 | -560.0 | -543.4 | |
| 1.72 | 7.16 | 1.38 | 5.71 | -23.92 | 94.09 | -51.09 | 114.89 | 0.7865 | -718.4 | -605.5 | |
| 0.78 | -18.00 | 0.62 | -18.00 | -23.70 | 94.11 | -51.08 | 114.62 | 0.7859 | -761.2 | 999999 | |
| 0.00 | 1.98 | 0.00 | 1.55 | -22.31 | 94.78 | -50.40 | 113.00 | 0.7767 | -193.0 | -186.9 | |
| 0.00 | 2.50 | 0.00 | 1.99 | -23.32 | 94.15 | -51.03 | 114.16 | 0.7848 | 534.0 | 317.3 | |
| 0.00 | 0.86 | 0.00 | 0.69 | -23.14 | 93.53 | -51.66 | 113.80 | 0.7906 | -340.0 | -313.8 | |
| 0.00 | 1.21 | 0.00 | 0.99 | -24.30 | 92.76 | -52.42 | 115.10 | 0.7999 | -596.0 | -511.4 | |
| 0.34 | 1.38 | 0.28 | 1.12 | -23.24 | 93.26 | -51.92 | 113.88 | 0.7933 | 426.2 | 331.7 | |
| 0.00 | 2.41 | 0.00 | 1.96 | -22.96 | 92.99 | -52.19 | 113.48 | 0.7954 | 641.0 | 404.2 | |
| 0.00 | 0.60 | 0.00 | 0.49 | -22.89 | 92.61 | -52.58 | 113.33 | 0.7990 | 348.0 | 326.6 | |
| 1.21 | 3.19 | 1.00 | 2.66 | -23.59 | 91.99 | -53.19 | 114.09 | 0.8060 | -642.8 | -476.6 | |
| 0.00 | 1.55 | 0.00 | 1.35 | -25.79 | 90.36 | -54.82 | 116.47 | 0.8244 | -650.0 | -555.9 | |
| 0.43 | 1.29 | 0.37 | 1.12 | -25.01 | 90.31 | -54.87 | 115.53 | 0.8235 | -490.6 | -488.3 | |
| 0.00 | 1.12 | 0.00 | 0.98 | -24.92 | 89.98 | -55.21 | 115.36 | 0.8264 | -487.0 | -451.8 | |
| 10.86 | 246.64 | 9.71 | 224.44 | -25.93 | 89.21 | -55.98 | 116.44 | 0.8346 | -1038.3 | -267.4 | |
| 1.81 | -31.00 | 1.65 | -31.00 | -26.66 | 88.42 | -56.77 | 117.17 | 0.8423 | -693.8 | 999999 | |
| 26.47 | -31.00 | 24.12 | -31.00 | -26.18 | 88.42 | -56.76 | 116.60 | 0.8416 | -720.2 | 999999 | |
| 2.41 | -31.00 | 2.16 | -31.00 | -25.05 | 89.07 | -56.12 | 115.37 | 0.8345 | -606.1 | 999999 | |
| 0.78 | -31.00 | 0.71 | -31.00 | -25.66 | 88.39 | -56.79 | 115.98 | 0.8412 | -495.7 | 999999 | |
| 1.64 | -31.00 | 1.50 | -31.00 | -25.24 | 88.15 | -57.04 | 115.46 | 0.8427 | -786.5 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
