SDO HMI 2014-02-28 08:16:13 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 112.67 | 625.22 | 85.71 | 477.30 | -24.36 | 92.76 | -48.46 | 116.08 | 0.7591 | 3.2 | 11.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-02-28 08:16:13 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.86 | 0.00 | 0.61 | -24.61 | 97.18 | -44.03 | 117.65 | 0.7158 | -532.0 | -394.8 | |
| 8.37 | 328.62 | 5.94 | 232.24 | -23.71 | 96.66 | -44.55 | 116.27 | 0.7187 | 821.2 | 315.9 | |
| 46.76 | -2.00 | 32.92 | -2.00 | -22.60 | 96.91 | -44.31 | 114.83 | 0.7129 | 1025.4 | 999999 | |
| 1.04 | -2.00 | 0.74 | -2.00 | -23.65 | 96.32 | -44.89 | 116.09 | 0.7222 | 446.2 | 999999 | |
| 0.00 | 0.69 | 0.00 | 0.51 | -25.42 | 95.17 | -46.04 | 118.10 | 0.7394 | 360.0 | 365.4 | |
| 1.55 | -2.00 | 1.12 | -2.00 | -23.58 | 95.89 | -45.32 | 115.87 | 0.7266 | 446.3 | 999999 | |
| 2.24 | -2.00 | 1.61 | -2.00 | -23.11 | 95.87 | -45.34 | 115.23 | 0.7256 | 491.5 | 999999 | |
| 0.00 | 1.55 | 0.00 | 1.13 | -24.19 | 95.29 | -45.93 | 116.52 | 0.7347 | 281.0 | 178.7 | |
| 0.00 | 1.29 | 0.00 | 0.95 | -24.20 | 95.00 | -46.21 | 116.44 | 0.7377 | -234.0 | -90.4 | |
| 0.86 | 2.07 | 0.63 | 1.50 | -23.24 | 95.25 | -45.96 | 115.24 | 0.7326 | 120.2 | 79.9 | |
| 0.00 | 1.04 | 0.00 | 0.77 | -24.49 | 94.00 | -47.21 | 116.55 | 0.7489 | -697.0 | -544.6 | |
| 2.85 | 10.09 | 2.11 | 7.45 | -24.03 | 94.18 | -47.04 | 116.00 | 0.7459 | -845.5 | -566.9 | |
| 0.00 | 1.21 | 0.00 | 0.90 | -24.40 | 93.66 | -47.55 | 116.34 | 0.7522 | -490.0 | -437.2 | |
| 0.00 | 3.02 | 0.00 | 2.30 | -24.51 | 92.82 | -48.39 | 116.27 | 0.7610 | -822.0 | -640.7 | |
| 0.00 | 1.98 | 0.00 | 1.49 | -23.04 | 93.35 | -47.86 | 114.49 | 0.7522 | 468.0 | 399.9 | |
| 0.00 | 2.24 | 0.00 | 1.69 | -23.17 | 93.05 | -48.17 | 114.59 | 0.7556 | 291.0 | 309.3 | |
| 4.14 | 9.58 | 3.17 | 7.34 | -23.53 | 92.18 | -49.03 | 114.86 | 0.7653 | -731.4 | -507.1 | |
| 0.00 | 1.55 | 0.00 | 1.24 | -25.07 | 90.22 | -50.99 | 116.36 | 0.7878 | -593.0 | -554.0 | |
| 0.00 | 1.12 | 0.00 | 0.90 | -24.84 | 90.15 | -51.06 | 116.06 | 0.7881 | -598.0 | -532.8 | |
| 0.00 | 0.95 | 0.00 | 0.76 | -25.07 | 89.96 | -51.25 | 116.31 | 0.7904 | -726.0 | -659.2 | |
| 0.00 | 1.04 | 0.00 | 0.84 | -25.02 | 89.73 | -51.49 | 116.19 | 0.7925 | -599.0 | -541.3 | |
| 12.51 | 256.32 | 10.33 | 214.68 | -25.93 | 88.85 | -52.37 | 117.13 | 0.8025 | -1031.6 | -265.9 | |
| 29.07 | -22.00 | 24.38 | -22.00 | -26.22 | 88.16 | -53.05 | 117.34 | 0.8093 | -801.9 | 999999 | |
| 2.16 | -22.00 | 1.81 | -22.00 | -25.32 | 87.91 | -53.30 | 116.20 | 0.8099 | -746.4 | 999999 | |
| 1.12 | -22.00 | 0.95 | -22.00 | -25.52 | 87.62 | -53.59 | 116.38 | 0.8130 | -490.7 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
