SDO HMI 2014-02-28 08:16:13 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 37.87 | 137.52 | 27.17 | 99.56 | 15.84 | 100.13 | -41.08 | 60.18 | 0.7302 | -5.3 | 61.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-02-28 08:16:13 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.29 | 2.59 | 0.88 | 1.77 | 16.24 | 104.11 | -37.10 | 57.18 | 0.6914 | -770.7 | -626.6 | |
| 2.76 | 24.42 | 1.89 | 16.79 | 15.05 | 103.32 | -37.90 | 59.23 | 0.6927 | -659.7 | -154.8 | |
| 7.25 | -2.00 | 4.99 | -2.00 | 15.42 | 103.12 | -38.09 | 58.89 | 0.6970 | -658.2 | 999999 | |
| 0.00 | 1.55 | 0.00 | 1.07 | 14.87 | 102.89 | -38.33 | 59.75 | 0.6963 | -229.0 | -185.2 | |
| 0.00 | 1.55 | 0.00 | 1.09 | 16.40 | 102.14 | -39.07 | 58.29 | 0.7130 | -689.0 | -589.1 | |
| 0.00 | 2.33 | 0.00 | 1.61 | 14.46 | 102.46 | -38.75 | 60.54 | 0.6985 | -544.0 | -474.2 | |
| 4.75 | 9.92 | 3.34 | 7.00 | 16.13 | 101.93 | -39.28 | 58.77 | 0.7137 | -794.1 | -474.5 | |
| 0.00 | 1.29 | 0.00 | 0.90 | 15.41 | 102.09 | -39.12 | 59.56 | 0.7078 | 260.0 | 246.9 | |
| 0.00 | 3.11 | 0.00 | 2.15 | 14.58 | 102.16 | -39.06 | 60.58 | 0.7025 | 86.0 | 122.2 | |
| 0.00 | 0.78 | 0.00 | 0.55 | 16.16 | 101.56 | -39.65 | 58.96 | 0.7177 | -544.0 | -494.3 | |
| 0.43 | 1.55 | 0.30 | 1.08 | 14.18 | 101.56 | -39.65 | 61.44 | 0.7067 | -551.2 | -431.8 | |
| 2.59 | 5.00 | 1.85 | 3.58 | 16.21 | 100.98 | -40.23 | 59.26 | 0.7240 | -654.9 | -406.2 | |
| 1.47 | 4.31 | 1.05 | 3.07 | 15.92 | 101.01 | -40.20 | 59.60 | 0.7220 | -634.2 | -93.9 | |
| 0.00 | 2.16 | 0.00 | 1.55 | 16.38 | 100.90 | -40.31 | 59.10 | 0.7257 | 435.0 | 280.7 | |
| 0.00 | 5.26 | 0.00 | 3.76 | 15.41 | 100.60 | -40.61 | 60.47 | 0.7235 | -598.0 | -288.7 | |
| 0.00 | 1.21 | 0.00 | 0.86 | 14.35 | 100.68 | -40.53 | 61.75 | 0.7170 | 457.0 | 432.9 | |
| 0.00 | 1.12 | 0.00 | 0.82 | 16.81 | 99.96 | -41.25 | 59.13 | 0.7376 | 492.0 | 495.8 | |
| 0.00 | 4.83 | 0.00 | 3.50 | 15.94 | 100.02 | -41.19 | 60.16 | 0.7323 | -585.0 | -295.4 | |
| 0.00 | 2.85 | 0.00 | 2.06 | 15.28 | 99.86 | -41.36 | 61.07 | 0.7306 | 261.0 | 283.6 | |
| 0.00 | 0.95 | 0.00 | 0.69 | 15.65 | 99.64 | -41.57 | 60.74 | 0.7348 | 654.0 | 526.6 | |
| 4.31 | 34.85 | 3.14 | 25.59 | 15.10 | 99.40 | -41.81 | 61.55 | 0.7343 | 795.4 | 132.9 | |
| 2.33 | -21.00 | 1.72 | -21.00 | 15.78 | 98.90 | -42.31 | 61.00 | 0.7430 | 508.1 | 999999 | |
| 6.38 | -21.00 | 4.69 | -21.00 | 15.40 | 98.91 | -42.30 | 61.46 | 0.7409 | 384.4 | 999999 | |
| 1.55 | 6.56 | 1.19 | 5.04 | 17.18 | 97.32 | -43.89 | 60.20 | 0.7657 | 837.2 | 621.5 | |
| 0.00 | 0.95 | 0.00 | 0.73 | 17.63 | 97.05 | -44.16 | 59.82 | 0.7704 | 561.0 | 460.7 | |
| 0.86 | -24.00 | 0.66 | -24.00 | 17.21 | 97.05 | -44.16 | 60.31 | 0.7684 | 715.0 | 999999 | |
| 0.00 | 1.38 | 0.00 | 1.08 | 17.57 | 96.63 | -44.58 | 60.11 | 0.7741 | 474.0 | 424.9 | |
| 0.00 | 1.47 | 0.00 | 1.13 | 16.90 | 96.84 | -44.37 | 60.78 | 0.7690 | 718.0 | 524.9 | |
| 1.90 | 7.94 | 1.47 | 6.17 | 17.14 | 96.68 | -44.53 | 60.58 | 0.7717 | 804.8 | 535.1 | |
| 0.00 | 2.67 | 0.00 | 2.07 | 16.77 | 96.57 | -44.64 | 61.08 | 0.7709 | 638.0 | 521.5 | |
| 0.00 | 4.92 | 0.00 | 3.85 | 17.04 | 96.05 | -45.16 | 61.03 | 0.7772 | 539.0 | 449.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
