SDO HMI 2014-03-01 15:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 13.64 | 0.00 | 7.14 | 7.59 | 135.03 | 10.69 | 324.60 | 0.3209 | 222.2 | 57.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-01 15:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.64 | 0.00 | 0.88 | 6.98 | 141.17 | 16.83 | 309.85 | 0.3759 | -823.0 | -702.6 | |
| 0.00 | 3.36 | 0.00 | 1.76 | 4.75 | 138.38 | 14.03 | 310.12 | 0.3174 | -777.0 | -608.4 | |
| 0.00 | 0.60 | 0.00 | 0.32 | 9.18 | 136.54 | 12.20 | 323.25 | 0.3501 | -2.0 | -4.1 | |
| 0.00 | 1.21 | 0.00 | 0.63 | 8.56 | 135.33 | 10.98 | 325.05 | 0.3302 | -764.0 | -641.9 | |
| 0.00 | 1.21 | 0.00 | 0.63 | 7.38 | 133.71 | 9.36 | 327.20 | 0.2992 | 1062.0 | 860.6 | |
| 0.00 | 2.42 | 0.00 | 1.26 | 9.86 | 132.31 | 7.97 | 334.97 | 0.3241 | 827.0 | 662.5 | |
| 0.00 | 1.04 | 0.00 | 0.54 | 8.38 | 130.49 | 6.15 | 338.44 | 0.2895 | 814.0 | 659.6 | |
| 0.00 | 1.04 | 0.00 | 0.54 | 9.02 | 130.38 | 6.04 | 339.57 | 0.2990 | 751.0 | 646.6 | |
| 0.00 | 1.12 | 0.00 | 0.58 | 8.38 | 130.31 | 5.97 | 339.01 | 0.2884 | 912.0 | 735.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
