SDO HMI 2014-03-02 09:01:13 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 20.72 | 77.82 | 25.71 | 96.47 | 12.82 | 51.05 | -63.40 | 72.48 | 0.9156 | -208.6 | 52.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-02 09:01:13 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 12.95 | 58.90 | 15.35 | 71.08 | 12.71 | 51.88 | -62.57 | 72.39 | 0.9102 | -573.4 | 0.6 | |
| 2.76 | 4.75 | 3.35 | 5.75 | 13.44 | 51.48 | -62.97 | 71.72 | 0.9142 | -313.4 | -202.6 | |
| 0.00 | 1.12 | 0.00 | 1.53 | 13.24 | 48.43 | -66.03 | 72.71 | 0.9332 | 449.0 | 444.8 | |
| 1.04 | 3.37 | 1.40 | 4.54 | 12.73 | 48.54 | -65.91 | 73.21 | 0.9317 | 495.8 | 440.1 | |
| 0.00 | 1.21 | 0.00 | 1.66 | 13.26 | 48.26 | -66.19 | 72.72 | 0.9342 | 438.0 | 397.5 | |
| 0.00 | 0.35 | 0.00 | 0.46 | 12.26 | 48.55 | -65.91 | 73.70 | 0.9310 | 381.0 | 369.2 | |
| 3.97 | 8.12 | 5.61 | 11.45 | 13.12 | 47.56 | -66.90 | 73.03 | 0.9381 | 338.8 | 212.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
