SDO HMI 2014-03-04 00:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 207.63 | 887.26 | 108.58 | 463.55 | -25.19 | 90.74 | -2.30 | 174.72 | 0.3168 | -65.5 | -5.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-04 00:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 20.21 | 137.24 | 10.36 | 70.36 | -21.89 | 96.11 | 3.07 | 191.13 | 0.2589 | 1308.1 | 485.0 | |
| 0.00 | 0.95 | 0.00 | 0.49 | -23.81 | 95.93 | 2.89 | 189.18 | 0.2900 | -656.0 | -558.8 | |
| 0.00 | 1.55 | 0.00 | 0.80 | -22.48 | 95.74 | 2.70 | 189.40 | 0.2675 | 510.0 | 444.7 | |
| 0.00 | 0.95 | 0.00 | 0.49 | -24.46 | 95.71 | 2.67 | 188.16 | 0.3003 | 557.0 | 489.9 | |
| 0.00 | 0.78 | 0.00 | 0.40 | -24.55 | 95.65 | 2.61 | 187.92 | 0.3017 | 679.0 | 464.7 | |
| 0.86 | -1.00 | 0.44 | -1.00 | -22.11 | 95.54 | 2.50 | 188.95 | 0.2609 | 934.6 | 999999 | |
| 0.00 | 1.73 | 0.00 | 0.90 | -24.28 | 95.29 | 2.24 | 186.95 | 0.2963 | 510.0 | 425.8 | |
| 1.90 | 30.14 | 0.98 | 15.58 | -23.84 | 95.21 | 2.17 | 186.92 | 0.2889 | 818.3 | 570.6 | |
| 8.38 | 22.54 | 4.31 | 11.61 | -22.98 | 95.10 | 2.06 | 186.97 | 0.2743 | 1039.2 | 477.6 | |
| 0.00 | 4.49 | 0.00 | 2.30 | -22.30 | 95.03 | 1.99 | 187.05 | 0.2628 | 869.0 | 945.7 | |
| 0.00 | 1.90 | 0.00 | 0.99 | -24.53 | 95.00 | 1.95 | 185.96 | 0.2999 | 431.0 | 186.1 | |
| 9.15 | -8.00 | 4.73 | -8.00 | -23.72 | 94.95 | 1.91 | 186.14 | 0.2864 | 1106.1 | 999999 | |
| 3.89 | 10.71 | 2.00 | 5.50 | -22.61 | 94.87 | 1.83 | 186.36 | 0.2676 | 1154.4 | 922.1 | |
| 0.00 | 1.21 | 0.00 | 0.63 | -24.34 | 94.80 | 1.76 | 185.43 | 0.2965 | 655.0 | 429.1 | |
| 0.69 | 2.07 | 0.36 | 1.08 | -25.15 | 94.58 | 1.54 | 184.51 | 0.3097 | -835.8 | -683.4 | |
| 0.00 | 1.90 | 0.00 | 0.98 | -23.13 | 94.46 | 1.42 | 184.75 | 0.2758 | 931.0 | 728.0 | |
| 0.52 | 7.95 | 0.27 | 4.08 | -22.64 | 94.36 | 1.32 | 184.57 | 0.2674 | 1095.0 | 911.1 | |
| 1.73 | 4.06 | 0.89 | 2.09 | -22.95 | 94.30 | 1.25 | 184.26 | 0.2725 | 977.8 | 840.3 | |
| 0.00 | 0.86 | 0.00 | 0.45 | -25.09 | 94.25 | 1.21 | 183.56 | 0.3083 | 646.0 | 553.0 | |
| 0.00 | 1.21 | 0.00 | 0.62 | -22.73 | 94.07 | 1.03 | 183.54 | 0.2686 | 911.0 | 788.3 | |
| 1.73 | -17.00 | 0.89 | -17.00 | -22.51 | 94.04 | 0.99 | 183.48 | 0.2649 | 1135.6 | 999999 | |
| 35.67 | 141.81 | 18.47 | 73.43 | -24.15 | 93.92 | 0.87 | 182.74 | 0.2924 | 1157.6 | 394.2 | |
| 0.00 | 1.30 | 0.00 | 0.67 | -22.76 | 93.88 | 0.83 | 182.87 | 0.2689 | 771.0 | 642.4 | |
| 0.00 | 2.59 | 0.00 | 1.33 | -22.18 | 93.84 | 0.80 | 182.87 | 0.2590 | 844.0 | 722.5 | |
| 0.00 | 0.69 | 0.00 | 0.35 | -21.75 | 93.74 | 0.70 | 182.60 | 0.2517 | 768.0 | 596.2 | |
| 0.00 | 2.16 | 0.00 | 1.11 | -22.67 | 93.62 | 0.58 | 182.00 | 0.2672 | 805.0 | 638.0 | |
| 0.00 | 1.30 | 0.00 | 0.67 | -24.90 | 93.43 | 0.39 | 181.16 | 0.3046 | 798.0 | 531.0 | |
| 0.00 | 2.94 | 0.00 | 1.53 | -24.96 | 93.13 | 0.09 | 180.27 | 0.3056 | 679.0 | 583.4 | |
| 0.00 | 0.78 | 0.00 | 0.40 | -22.58 | 93.07 | 0.03 | 180.10 | 0.2654 | 586.0 | 450.8 | |
| 0.00 | 1.21 | 0.00 | 0.63 | -25.53 | 92.77 | -0.27 | 179.22 | 0.3149 | 509.0 | 459.1 | |
| 0.00 | 0.78 | 0.00 | 0.40 | -22.33 | 92.75 | -0.29 | 178.96 | 0.2613 | 746.0 | 477.9 | |
| 2.76 | 4.92 | 1.44 | 2.56 | -25.28 | 92.61 | -0.43 | 178.73 | 0.3108 | 507.2 | 283.2 | |
| 1.73 | 6.22 | 0.90 | 3.25 | -25.68 | 91.58 | -1.46 | 175.85 | 0.3183 | -1011.7 | -497.8 | |
| 0.00 | 1.55 | 0.00 | 0.81 | -25.30 | 91.39 | -1.65 | 175.20 | 0.3123 | 525.0 | 367.6 | |
| 0.00 | 0.86 | 0.00 | 0.45 | -25.83 | 91.35 | -1.69 | 175.23 | 0.3212 | -749.0 | -591.4 | |
| 1.55 | 5.53 | 0.81 | 2.90 | -26.24 | 90.95 | -2.10 | 174.24 | 0.3285 | -982.2 | -732.6 | |
| 0.00 | 1.04 | 0.00 | 0.54 | -25.77 | 90.36 | -2.68 | 172.44 | 0.3218 | -759.0 | -696.7 | |
| 1.21 | 9.41 | 0.64 | 4.95 | -26.55 | 90.28 | -2.77 | 172.56 | 0.3349 | -902.7 | -808.3 | |
| 0.00 | 0.26 | 0.00 | 0.14 | -27.97 | 90.14 | -2.91 | 172.79 | 0.3583 | -652.0 | -663.0 | |
| 0.00 | 1.21 | 0.00 | 0.64 | -27.21 | 90.06 | -2.98 | 172.28 | 0.3461 | -728.0 | -589.7 | |
| 0.95 | 2.68 | 0.50 | 1.41 | -26.93 | 89.86 | -3.18 | 171.65 | 0.3419 | -964.5 | -813.1 | |
| 0.00 | 5.53 | 0.00 | 2.94 | -28.61 | 89.75 | -3.30 | 172.11 | 0.3694 | -850.0 | -681.3 | |
| 0.00 | 0.95 | 0.00 | 0.51 | -29.31 | 89.72 | -3.32 | 172.34 | 0.3808 | -628.0 | -546.5 | |
| 0.00 | 1.04 | 0.00 | 0.55 | -28.99 | 89.60 | -3.45 | 171.93 | 0.3759 | -637.0 | -598.1 | |
| 0.00 | 1.55 | 0.00 | 0.81 | -24.70 | 89.60 | -3.44 | 169.69 | 0.3063 | 942.0 | 747.7 | |
| 1.12 | 44.13 | 0.59 | 23.12 | -25.98 | 89.36 | -3.68 | 169.82 | 0.3278 | -656.5 | -0.5 | |
| 5.70 | -46.00 | 2.98 | -46.00 | -25.57 | 89.18 | -3.86 | 169.06 | 0.3217 | 962.1 | 999999 | |
| 1.21 | -46.00 | 0.63 | -46.00 | -26.16 | 89.02 | -4.02 | 169.03 | 0.3319 | -903.2 | 999999 | |
| 10.80 | 21.59 | 5.71 | 11.43 | -27.52 | 88.84 | -4.20 | 169.38 | 0.3542 | -1015.2 | -514.2 | |
| 0.00 | 0.60 | 0.00 | 0.32 | -25.38 | 88.82 | -4.22 | 167.95 | 0.3198 | 375.0 | 397.4 | |
| 0.00 | 1.21 | 0.00 | 0.63 | -25.47 | 88.49 | -4.55 | 167.10 | 0.3225 | 697.0 | 473.1 | |
| 22.80 | 344.17 | 12.05 | 181.71 | -27.16 | 88.25 | -4.79 | 167.70 | 0.3505 | -1121.9 | -401.6 | |
| 0.00 | 1.99 | 0.00 | 1.04 | -25.65 | 88.32 | -4.73 | 166.77 | 0.3261 | 286.0 | 275.7 | |
| 0.86 | -52.00 | 0.46 | -52.00 | -27.70 | 88.09 | -4.95 | 167.68 | 0.3596 | -725.5 | 999999 | |
| 5.44 | -52.00 | 2.87 | -52.00 | -26.78 | 88.00 | -5.04 | 166.81 | 0.3453 | 687.2 | 999999 | |
| 4.23 | -52.00 | 2.24 | -52.00 | -26.87 | 87.43 | -5.61 | 165.45 | 0.3489 | -824.3 | 999999 | |
| 0.00 | 1.21 | 0.00 | 0.66 | -31.31 | 86.54 | -6.50 | 166.68 | 0.4215 | -659.0 | -445.7 | |
| 0.00 | 0.95 | 0.00 | 0.51 | -28.22 | 86.58 | -6.47 | 164.53 | 0.3737 | -753.0 | -586.2 | |
| 55.19 | -52.00 | 29.13 | -52.00 | -26.51 | 86.64 | -6.40 | 163.21 | 0.3468 | -1316.4 | 999999 | |
| 0.00 | 2.50 | 0.00 | 1.34 | -28.67 | 86.38 | -6.66 | 164.44 | 0.3814 | -759.0 | -717.5 | |
| 0.52 | 1.73 | 0.28 | 0.92 | -28.34 | 86.19 | -6.85 | 163.78 | 0.3772 | -996.7 | -848.4 | |
| 5.53 | 15.29 | 2.96 | 8.19 | -28.50 | 85.84 | -7.20 | 163.13 | 0.3812 | -973.9 | -617.6 | |
| 0.00 | 1.73 | 0.00 | 0.91 | -25.59 | 85.73 | -7.31 | 160.01 | 0.3372 | -841.0 | -677.8 | |
| 0.00 | 2.85 | 0.00 | 1.51 | -26.33 | 85.35 | -7.69 | 159.91 | 0.3507 | -781.0 | -838.1 | |
| 0.00 | 1.81 | 0.00 | 0.96 | -25.96 | 85.28 | -7.76 | 159.31 | 0.3454 | -841.0 | -691.7 | |
| 0.00 | 1.04 | 0.00 | 0.55 | -26.27 | 85.06 | -7.99 | 159.13 | 0.3514 | -805.0 | -624.1 | |
| 0.00 | 1.30 | 0.00 | 0.70 | -29.44 | 84.81 | -8.23 | 161.78 | 0.4005 | -707.0 | -512.9 | |
| 0.00 | 1.21 | 0.00 | 0.64 | -26.55 | 84.87 | -8.17 | 159.01 | 0.3567 | -754.0 | -612.1 | |
| 0.35 | 3.97 | 0.18 | 2.11 | -26.95 | 84.70 | -8.34 | 159.08 | 0.3637 | -827.8 | -648.8 | |
| 0.95 | 3.63 | 0.51 | 1.93 | -27.27 | 84.58 | -8.47 | 159.15 | 0.3692 | 609.5 | 250.6 | |
| 0.00 | 1.81 | 0.00 | 0.98 | -29.22 | 83.48 | -9.56 | 158.91 | 0.4043 | -767.0 | -666.6 | |
| 0.00 | 1.99 | 0.00 | 1.06 | -26.48 | 83.26 | -9.78 | 155.32 | 0.3659 | -710.0 | -621.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
