SDO HMI 2014-03-04 09:01:13 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.12 | 7.35 | 1.42 | 9.06 | -12.09 | 155.35 | 67.24 | 259.93 | 0.9173 | 136.5 | 166.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-04 09:01:13 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.21 | 0.00 | 1.54 | -12.02 | 156.10 | 67.99 | 259.97 | 0.9225 | 533.0 | 391.6 | |
| 1.12 | 2.59 | 1.42 | 3.28 | -12.27 | 155.99 | 67.88 | 259.70 | 0.9217 | 462.9 | 389.9 | |
| 0.00 | 1.21 | 0.00 | 1.48 | -11.52 | 155.13 | 67.02 | 260.56 | 0.9162 | 172.0 | 130.7 | |
| 0.00 | 0.95 | 0.00 | 1.18 | -12.46 | 155.44 | 67.33 | 259.53 | 0.9180 | 262.0 | 216.5 | |
| 0.00 | 0.78 | 0.00 | 0.89 | -11.90 | 153.40 | 65.29 | 260.23 | 0.9038 | -411.0 | -296.6 | |
| 0.00 | 0.61 | 0.00 | 0.69 | -12.23 | 153.41 | 65.30 | 259.86 | 0.9038 | -337.0 | -337.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
