SDO HMI 2014-03-05 04:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 3.11 | 23.86 | 1.87 | 14.24 | -17.40 | 44.59 | -33.09 | 110.60 | 0.5586 | -173.8 | -76.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-05 04:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.86 | 1.99 | 0.51 | 1.17 | -17.05 | 46.10 | -31.57 | 110.59 | 0.5368 | 868.9 | 744.4 | |
| 0.00 | 3.29 | 0.00 | 1.93 | -16.94 | 45.80 | -31.88 | 110.26 | 0.5407 | 660.0 | 580.2 | |
| 0.00 | 1.38 | 0.00 | 0.82 | -17.35 | 45.53 | -32.14 | 110.88 | 0.5457 | 739.0 | 649.6 | |
| 0.00 | 1.21 | 0.00 | 0.72 | -17.44 | 45.44 | -32.23 | 111.00 | 0.5472 | 449.0 | 473.1 | |
| 0.00 | 4.50 | 0.00 | 2.67 | -17.56 | 44.97 | -32.70 | 111.02 | 0.5540 | -265.0 | -149.5 | |
| 0.00 | 1.12 | 0.00 | 0.67 | -17.30 | 44.69 | -32.98 | 110.44 | 0.5569 | -744.0 | -566.5 | |
| 0.00 | 1.64 | 0.00 | 0.98 | -17.61 | 44.44 | -33.24 | 110.90 | 0.5613 | -379.0 | -301.8 | |
| 2.25 | 5.01 | 1.36 | 3.03 | -17.65 | 43.61 | -34.07 | 110.63 | 0.5726 | -909.0 | -734.3 | |
| 0.00 | 1.47 | 0.00 | 0.89 | -17.56 | 43.17 | -34.50 | 110.32 | 0.5781 | -666.0 | -487.3 | |
| 0.00 | 2.25 | 0.00 | 1.36 | -17.33 | 42.96 | -34.72 | 109.85 | 0.5803 | -716.0 | -504.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
