SDO HMI 2014-03-05 10:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 8.31 | 35.04 | 9.65 | 38.00 | 7.60 | 135.66 | 61.27 | 282.43 | 0.8912 | -103.5 | 126.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-05 10:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 4.76 | 8.73 | 5.85 | 10.74 | 7.32 | 139.24 | 64.84 | 281.31 | 0.9173 | -479.4 | -307.2 | |
| 2.34 | 5.28 | 2.56 | 5.76 | 7.14 | 136.03 | 61.63 | 281.81 | 0.8939 | -537.6 | -476.6 | |
| 0.00 | 0.61 | 0.00 | 0.66 | 6.72 | 135.87 | 61.48 | 281.40 | 0.8920 | -538.0 | -507.4 | |
| 0.00 | 1.47 | 0.00 | 1.59 | 6.79 | 135.70 | 61.30 | 281.51 | 0.8908 | -454.0 | -407.0 | |
| 0.00 | 1.47 | 0.00 | 1.56 | 7.38 | 134.96 | 60.57 | 282.34 | 0.8861 | 387.0 | 212.9 | |
| 0.78 | 2.25 | 0.80 | 2.31 | 6.49 | 134.10 | 59.71 | 281.55 | 0.8776 | 382.6 | 243.4 | |
| 0.00 | 0.35 | 0.00 | 0.36 | 7.13 | 134.12 | 59.72 | 282.26 | 0.8789 | 463.0 | 467.2 | |
| 0.00 | 1.30 | 0.00 | 1.33 | 6.94 | 134.02 | 59.62 | 282.07 | 0.8777 | 497.0 | 409.4 | |
| 0.00 | 1.30 | 0.00 | 1.31 | 7.84 | 133.33 | 58.93 | 283.25 | 0.8738 | 468.0 | 377.1 | |
| 0.00 | 2.94 | 0.00 | 3.01 | 8.79 | 133.56 | 59.17 | 284.24 | 0.8775 | 518.0 | 335.8 | |
| 0.43 | 9.34 | 0.44 | 9.37 | 8.40 | 133.11 | 58.72 | 283.93 | 0.8731 | 490.6 | 524.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
