SDO HMI 2014-03-05 14:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 6.06 | 30.68 | 7.72 | 36.31 | 7.50 | 135.94 | 63.74 | 281.76 | 0.9092 | -89.5 | 26.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-05 14:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 3.63 | 7.69 | 4.91 | 10.40 | 7.33 | 139.31 | 67.11 | 280.85 | 0.9319 | -414.0 | -303.3 | |
| 1.30 | 8.73 | 1.54 | 10.33 | 7.20 | 136.13 | 63.93 | 281.37 | 0.9108 | -568.3 | -474.7 | |
| 0.61 | -2.00 | 0.71 | -2.00 | 7.14 | 135.91 | 63.71 | 281.36 | 0.9091 | -691.7 | 999999 | |
| 0.00 | 2.07 | 0.00 | 2.28 | 6.39 | 134.08 | 61.87 | 280.94 | 0.8945 | 391.0 | 227.2 | |
| 0.00 | 4.24 | 0.00 | 4.67 | 6.96 | 134.01 | 61.81 | 281.58 | 0.8949 | 598.0 | 394.2 | |
| 0.00 | 2.42 | 0.00 | 2.67 | 8.82 | 133.67 | 61.47 | 283.69 | 0.8954 | 497.0 | 362.6 | |
| 0.52 | 5.10 | 0.56 | 5.50 | 8.66 | 133.12 | 60.92 | 283.66 | 0.8910 | 650.0 | 547.1 | |
| 0.00 | 0.43 | 0.00 | 0.46 | 8.30 | 132.90 | 60.70 | 283.31 | 0.8887 | 500.0 | 499.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
