SDO HMI 2014-03-06 13:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 63.74 | 353.05 | 47.37 | 262.10 | -12.62 | 108.17 | 48.60 | 259.53 | 0.7459 | 419.2 | 298.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-06 13:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.69 | 0.00 | 0.76 | -18.22 | 123.81 | 64.23 | 253.21 | 0.8954 | 470.0 | 401.4 | |
| 0.00 | 1.82 | 0.00 | 1.99 | -17.97 | 123.56 | 63.99 | 253.49 | 0.8935 | 543.0 | 509.4 | |
| 0.00 | 0.43 | 0.00 | 0.39 | -15.46 | 116.51 | 56.93 | 256.22 | 0.8338 | 398.0 | 281.2 | |
| 0.00 | 2.94 | 0.00 | 2.59 | -15.85 | 116.00 | 56.42 | 255.73 | 0.8292 | 667.0 | 544.4 | |
| 0.00 | 1.21 | 0.00 | 1.07 | -16.21 | 115.99 | 56.41 | 255.28 | 0.8292 | 618.0 | 559.9 | |
| 0.00 | 0.95 | 0.00 | 0.84 | -16.39 | 116.07 | 56.49 | 255.08 | 0.8300 | 392.0 | 311.2 | |
| 0.00 | 1.38 | 0.00 | 1.14 | -11.03 | 113.22 | 53.65 | 261.62 | 0.8013 | 476.0 | 443.6 | |
| 0.00 | 0.86 | 0.00 | 0.74 | -16.14 | 114.90 | 55.32 | 255.32 | 0.8188 | 432.0 | 404.7 | |
| 2.25 | 4.07 | 1.90 | 3.44 | -16.17 | 114.32 | 54.74 | 255.25 | 0.8131 | -511.3 | -320.6 | |
| 0.00 | 1.73 | 0.00 | 1.47 | -16.83 | 114.43 | 54.85 | 254.45 | 0.8146 | 196.0 | 189.6 | |
| 0.00 | 0.86 | 0.00 | 0.73 | -16.35 | 114.01 | 54.44 | 255.01 | 0.8103 | -503.0 | -310.8 | |
| 0.00 | 0.69 | 0.00 | 0.58 | -17.34 | 113.95 | 54.37 | 253.79 | 0.8102 | -122.0 | -190.1 | |
| 10.03 | 19.03 | 7.93 | 15.01 | -11.49 | 111.33 | 51.75 | 261.06 | 0.7814 | 786.1 | 594.6 | |
| 0.61 | 14.10 | 0.48 | 11.18 | -12.26 | 111.39 | 51.81 | 260.06 | 0.7820 | -452.0 | 292.5 | |
| 0.00 | 0.26 | 0.00 | 0.21 | -12.80 | 111.49 | 51.91 | 259.38 | 0.7832 | -239.0 | -278.7 | |
| 0.00 | 1.04 | 0.00 | 0.86 | -19.11 | 112.93 | 53.35 | 251.50 | 0.8017 | -449.0 | -380.7 | |
| 0.00 | 5.54 | 0.00 | 4.27 | -11.27 | 110.16 | 50.58 | 261.34 | 0.7687 | 756.0 | 645.4 | |
| 0.00 | 1.12 | 0.00 | 0.85 | -11.52 | 109.36 | 49.78 | 261.00 | 0.7599 | -404.0 | -336.0 | |
| 0.00 | 0.86 | 0.00 | 0.66 | -12.62 | 109.54 | 49.97 | 259.56 | 0.7621 | -302.0 | -304.3 | |
| 2.85 | 11.50 | 2.16 | 8.71 | -12.50 | 109.27 | 49.70 | 259.72 | 0.7590 | -776.9 | -518.3 | |
| 1.73 | -20.00 | 1.31 | -20.00 | -12.71 | 109.24 | 49.66 | 259.43 | 0.7587 | -632.0 | 999999 | |
| 0.00 | 1.04 | 0.00 | 0.80 | -16.60 | 109.87 | 50.29 | 254.37 | 0.7679 | -545.0 | -500.1 | |
| 0.00 | 1.56 | 0.00 | 1.16 | -13.21 | 108.38 | 48.80 | 258.73 | 0.7493 | -407.0 | -325.7 | |
| 0.95 | 1.99 | 0.70 | 1.46 | -13.82 | 107.67 | 48.09 | 257.87 | 0.7415 | -240.5 | -132.8 | |
| 0.00 | 0.43 | 0.00 | 0.32 | -16.00 | 108.09 | 48.51 | 254.98 | 0.7478 | -543.0 | -487.0 | |
| 43.68 | 259.14 | 31.69 | 187.94 | -12.25 | 106.99 | 47.42 | 259.97 | 0.7330 | 1111.6 | 387.1 | |
| 0.00 | 2.34 | 0.00 | 1.73 | -15.96 | 107.88 | 48.31 | 255.01 | 0.7455 | -646.0 | -557.9 | |
| 0.00 | 1.64 | 0.00 | 1.21 | -15.72 | 107.81 | 48.23 | 255.32 | 0.7445 | -619.0 | -587.3 | |
| 0.00 | 0.86 | 0.00 | 0.64 | -15.46 | 107.68 | 48.10 | 255.66 | 0.7428 | -548.0 | -487.2 | |
| 1.64 | 4.07 | 1.20 | 2.97 | -14.43 | 107.29 | 47.71 | 257.02 | 0.7375 | -503.7 | -358.8 | |
| 0.00 | 1.47 | 0.00 | 1.08 | -15.36 | 107.46 | 47.89 | 255.78 | 0.7403 | -708.0 | -647.9 | |
| 0.00 | 1.21 | 0.00 | 0.88 | -14.90 | 107.19 | 47.61 | 256.38 | 0.7368 | -615.0 | -566.9 | |
| 0.00 | 0.95 | 0.00 | 0.69 | -14.58 | 107.05 | 47.47 | 256.80 | 0.7349 | -453.0 | -383.6 | |
| 0.00 | 1.12 | 0.00 | 0.82 | -14.50 | 106.85 | 47.27 | 256.89 | 0.7325 | -530.0 | -411.2 | |
| 0.00 | 1.47 | 0.00 | 1.12 | -21.76 | 108.56 | 48.98 | 247.45 | 0.7610 | -92.0 | -245.7 | |
| 0.00 | 1.64 | 0.00 | 1.10 | -9.39 | 102.27 | 42.69 | 263.98 | 0.6751 | -704.0 | -578.1 | |
| 0.00 | 1.04 | 0.00 | 0.69 | -9.84 | 102.26 | 42.68 | 263.31 | 0.6749 | -627.0 | -623.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
