SDO HMI 2014-03-06 17:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 9.77 | 0.00 | 5.00 | -11.80 | 44.13 | -13.25 | 110.56 | 0.2400 | 680.2 | 579.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-06 17:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.95 | 0.00 | 0.48 | -10.77 | 46.47 | -10.91 | 108.93 | 0.1974 | 851.0 | 697.3 | |
| 0.00 | 1.30 | 0.00 | 0.66 | -11.27 | 46.17 | -11.20 | 110.84 | 0.2048 | 954.0 | 774.0 | |
| 0.00 | 1.12 | 0.00 | 0.57 | -11.80 | 46.00 | -11.38 | 112.97 | 0.2108 | 877.0 | 747.9 | |
| 0.00 | 0.95 | 0.00 | 0.48 | -11.47 | 45.95 | -11.43 | 111.42 | 0.2096 | 817.0 | 617.5 | |
| 0.00 | 1.04 | 0.00 | 0.53 | -11.70 | 45.66 | -11.72 | 111.99 | 0.2155 | 865.0 | 720.3 | |
| 0.00 | 1.21 | 0.00 | 0.62 | -12.80 | 45.45 | -11.92 | 116.29 | 0.2257 | 785.0 | 618.1 | |
| 0.00 | 1.30 | 0.00 | 0.66 | -10.84 | 44.61 | -12.76 | 106.86 | 0.2278 | 841.0 | 675.6 | |
| 0.00 | 0.95 | 0.00 | 0.49 | -11.34 | 39.91 | -17.47 | 104.68 | 0.3056 | 890.0 | 736.1 | |
| 0.00 | 0.95 | 0.00 | 0.51 | -14.30 | 35.71 | -21.67 | 110.18 | 0.3828 | -758.0 | -479.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
