SDO HMI 2014-03-08 18:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 15.23 | 41.71 | 18.56 | 51.69 | -18.59 | 322.85 | -67.62 | 107.17 | 0.9185 | 138.9 | -135.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-08 18:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 4.67 | 7.44 | 5.21 | 8.30 | -17.97 | 325.91 | -64.57 | 106.50 | 0.8978 | 614.2 | 413.8 | |
| 0.87 | 4.50 | 1.02 | 5.24 | -18.14 | 324.42 | -66.05 | 106.68 | 0.9084 | 116.2 | 254.1 | |
| 0.00 | 0.61 | 0.00 | 0.73 | -19.00 | 323.75 | -66.72 | 107.62 | 0.9131 | -549.0 | -523.4 | |
| 0.78 | 1.90 | 0.91 | 2.23 | -17.90 | 324.52 | -65.96 | 106.42 | 0.9077 | 329.6 | 281.9 | |
| 0.95 | 2.25 | 1.16 | 2.74 | -19.17 | 323.36 | -67.11 | 107.81 | 0.9157 | -382.8 | -366.9 | |
| 3.63 | 10.56 | 4.48 | 12.93 | -18.83 | 323.07 | -67.40 | 107.43 | 0.9176 | -95.9 | -354.2 | |
| 0.43 | 1.73 | 0.58 | 2.32 | -18.80 | 320.93 | -69.54 | 107.40 | 0.9311 | -378.2 | -374.7 | |
| 1.56 | 8.57 | 2.16 | 11.80 | -19.49 | 320.17 | -70.31 | 108.15 | 0.9356 | -110.2 | -287.6 | |
| 2.34 | 4.15 | 3.04 | 5.40 | -17.24 | 321.75 | -68.73 | 105.71 | 0.9262 | 321.6 | 69.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
