SDO HMI 2014-03-09 10:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 40.30 | 223.07 | 21.52 | 120.15 | -10.23 | 358.67 | -23.03 | 99.07 | 0.3919 | 551.2 | 370.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-09 10:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.87 | 0.00 | 0.46 | -14.27 | 2.65 | -19.05 | 112.23 | 0.3432 | 920.0 | 839.8 | |
| 0.00 | 2.86 | 0.00 | 1.51 | -14.17 | 2.43 | -19.27 | 111.76 | 0.3460 | 1056.0 | 888.7 | |
| 0.00 | 1.30 | 0.00 | 0.69 | -14.58 | 2.00 | -19.70 | 112.48 | 0.3546 | 880.0 | 676.6 | |
| 0.00 | 1.30 | 0.00 | 0.69 | -6.03 | 0.68 | -21.02 | 87.97 | 0.3584 | 821.0 | 677.6 | |
| 16.47 | 149.92 | 8.77 | 79.84 | -9.46 | 0.07 | -21.62 | 97.47 | 0.3682 | 1240.2 | 485.7 | |
| 18.89 | -5.00 | 10.07 | -5.00 | -9.99 | 359.94 | -21.76 | 98.87 | 0.3711 | 1238.4 | 999999 | |
| 0.00 | 1.56 | 0.00 | 0.84 | -14.52 | 359.50 | -22.20 | 110.39 | 0.3918 | 744.0 | 582.1 | |
| 0.00 | 2.17 | 0.00 | 1.17 | -8.73 | 358.52 | -23.17 | 95.31 | 0.3923 | 969.0 | 800.6 | |
| 0.00 | 2.17 | 0.00 | 1.17 | -7.84 | 358.58 | -23.12 | 93.03 | 0.3912 | 838.0 | 752.8 | |
| 0.00 | 1.21 | 0.00 | 0.65 | -9.43 | 358.14 | -23.55 | 97.03 | 0.3989 | 670.0 | 471.0 | |
| 0.00 | 1.39 | 0.00 | 0.75 | -9.54 | 357.94 | -23.76 | 97.27 | 0.4022 | 933.0 | 733.2 | |
| 0.00 | 3.12 | 0.00 | 1.69 | -9.68 | 357.86 | -23.83 | 97.62 | 0.4036 | 826.0 | 700.1 | |
| 0.00 | 3.29 | 0.00 | 1.78 | -8.72 | 357.77 | -23.93 | 95.23 | 0.4043 | 899.0 | 759.8 | |
| 2.51 | 11.18 | 1.36 | 6.06 | -9.31 | 357.56 | -24.14 | 96.65 | 0.4080 | 785.5 | 435.7 | |
| 0.00 | 2.17 | 0.00 | 1.18 | -10.14 | 357.49 | -24.20 | 98.68 | 0.4100 | 962.0 | 616.2 | |
| 0.00 | 1.30 | 0.00 | 0.70 | -8.65 | 357.54 | -24.15 | 95.03 | 0.4079 | 712.0 | 578.5 | |
| 0.00 | 1.73 | 0.00 | 0.95 | -14.57 | 356.81 | -24.89 | 108.85 | 0.4322 | 741.0 | 589.5 | |
| 0.00 | 1.21 | 0.00 | 0.66 | -13.28 | 356.92 | -24.77 | 105.97 | 0.4260 | 841.0 | 647.4 | |
| 0.00 | 1.04 | 0.00 | 0.57 | -14.36 | 356.80 | -24.90 | 108.37 | 0.4315 | 713.0 | 584.0 | |
| 0.00 | 2.34 | 0.00 | 1.29 | -14.56 | 356.57 | -25.12 | 108.69 | 0.4357 | 715.0 | 577.1 | |
| 0.00 | 1.99 | 0.00 | 1.08 | -8.83 | 357.06 | -24.63 | 95.45 | 0.4155 | 595.0 | 487.5 | |
| 0.00 | 1.13 | 0.00 | 0.62 | -15.56 | 356.13 | -25.56 | 110.66 | 0.4461 | -830.0 | -607.2 | |
| 2.43 | 7.63 | 1.32 | 4.16 | -9.83 | 356.69 | -25.01 | 97.78 | 0.4222 | -947.2 | -538.6 | |
| 0.00 | 1.56 | 0.00 | 0.86 | -12.26 | 356.36 | -25.34 | 103.39 | 0.4317 | 800.0 | 470.2 | |
| 0.00 | 1.04 | 0.00 | 0.57 | -11.78 | 355.77 | -25.93 | 102.10 | 0.4396 | 700.0 | 575.7 | |
| 0.00 | 1.04 | 0.00 | 0.58 | -15.90 | 354.67 | -27.02 | 110.57 | 0.4687 | -757.0 | -570.2 | |
| 0.00 | 0.95 | 0.00 | 0.53 | -14.98 | 354.45 | -27.24 | 108.55 | 0.4683 | -914.0 | -785.8 | |
| 0.00 | 1.65 | 0.00 | 0.93 | -14.71 | 353.38 | -28.32 | 107.50 | 0.4831 | -861.0 | -720.3 | |
| 0.00 | 1.65 | 0.00 | 0.94 | -16.66 | 352.54 | -29.15 | 110.99 | 0.5018 | -690.0 | -551.4 | |
| 0.00 | 2.34 | 0.00 | 1.34 | -4.62 | 351.78 | -29.91 | 86.67 | 0.4999 | -806.0 | -587.4 | |
| 0.00 | 0.78 | 0.00 | 0.46 | -16.49 | 349.94 | -31.76 | 109.53 | 0.5376 | -667.0 | -530.1 | |
| 0.00 | 2.08 | 0.00 | 1.21 | -12.59 | 350.24 | -31.45 | 102.34 | 0.5233 | -855.0 | -701.0 | |
| 0.00 | 1.04 | 0.00 | 0.61 | -17.09 | 349.35 | -32.35 | 110.37 | 0.5477 | -510.0 | -354.2 | |
| 0.00 | 2.34 | 0.00 | 1.37 | -13.07 | 349.27 | -32.42 | 103.02 | 0.5381 | -664.0 | -594.3 | |
| 0.00 | 1.82 | 0.00 | 1.08 | -11.84 | 348.10 | -33.59 | 100.56 | 0.5530 | -776.0 | -540.5 | |
| 0.00 | 1.21 | 0.00 | 0.72 | -12.09 | 347.70 | -33.99 | 100.94 | 0.5590 | -669.0 | -529.6 | |
| 0.00 | 0.69 | 0.00 | 0.44 | -11.56 | 343.05 | -38.64 | 99.51 | 0.6226 | -449.0 | -498.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
