SDO HMI 2014-03-10 15:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 7.02 | 20.62 | 9.50 | 27.07 | -8.41 | 297.26 | -68.51 | 96.19 | 0.9266 | -164.4 | -48.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-10 15:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.21 | 0.00 | 1.15 | -13.08 | 306.59 | -59.19 | 100.95 | 0.8541 | 55.0 | 135.1 | |
| 1.56 | 3.73 | 1.86 | 4.44 | -6.61 | 299.82 | -65.96 | 94.00 | 0.9111 | 364.7 | 322.7 | |
| 0.00 | 1.99 | 0.00 | 2.47 | -6.74 | 298.80 | -66.98 | 94.23 | 0.9182 | 228.0 | 220.5 | |
| 0.00 | 0.78 | 0.00 | 0.98 | -6.45 | 298.41 | -67.37 | 93.95 | 0.9210 | 201.0 | 195.0 | |
| 0.00 | 0.69 | 0.00 | 0.91 | -6.40 | 297.46 | -68.32 | 93.99 | 0.9273 | 422.0 | 385.4 | |
| 5.03 | 9.27 | 7.03 | 12.95 | -9.24 | 295.72 | -70.05 | 97.19 | 0.9367 | -465.5 | -301.2 | |
| 0.43 | 1.47 | 0.61 | 2.08 | -8.90 | 295.61 | -70.17 | 96.83 | 0.9375 | -372.2 | -337.2 | |
| 0.00 | 0.87 | 0.00 | 1.22 | -8.23 | 295.62 | -70.15 | 96.12 | 0.9378 | -352.0 | -361.6 | |
| 0.00 | 0.61 | 0.00 | 0.87 | -7.29 | 295.26 | -70.51 | 95.15 | 0.9404 | -281.0 | -242.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
