SDO HMI 2014-03-10 23:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 5.11 | 21.32 | 5.90 | 22.03 | -9.30 | 299.46 | -61.91 | 96.76 | 0.8761 | -123.2 | 70.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-10 23:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 4.07 | 0.00 | 3.30 | -12.87 | 308.44 | -52.92 | 100.69 | 0.7938 | 122.0 | 138.7 | |
| 0.00 | 1.21 | 0.00 | 1.05 | -11.77 | 305.73 | -55.63 | 99.33 | 0.8211 | 469.0 | 380.5 | |
| 0.00 | 0.87 | 0.00 | 0.80 | -10.64 | 302.99 | -58.37 | 98.04 | 0.8472 | 139.0 | 149.1 | |
| 0.00 | 2.77 | 0.00 | 2.81 | -6.69 | 300.18 | -61.19 | 93.63 | 0.8740 | 591.0 | 422.9 | |
| 0.00 | 1.39 | 0.00 | 1.45 | -6.85 | 299.18 | -62.18 | 93.90 | 0.8821 | 341.0 | 326.2 | |
| 0.00 | 0.78 | 0.00 | 0.83 | -6.53 | 298.53 | -62.83 | 93.60 | 0.8876 | 106.0 | 144.1 | |
| 0.00 | 0.69 | 0.00 | 0.75 | -6.53 | 298.00 | -63.37 | 93.65 | 0.8918 | 319.0 | 317.9 | |
| 5.11 | 8.06 | 5.90 | 9.30 | -9.35 | 296.04 | -65.32 | 96.95 | 0.9050 | -587.6 | -416.8 | |
| 0.00 | 1.13 | 0.00 | 1.31 | -9.08 | 295.77 | -65.59 | 96.67 | 0.9071 | -296.0 | -298.5 | |
| 0.00 | 0.35 | 0.00 | 0.43 | -8.24 | 294.24 | -67.12 | 95.87 | 0.9183 | -159.0 | -122.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
