SDO HMI 2014-03-11 01:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 224.24 | 836.95 | 141.19 | 528.47 | -18.73 | 322.79 | -37.47 | 111.28 | 0.6192 | -74.1 | -118.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-11 01:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.04 | 0.00 | 0.61 | -19.80 | 328.79 | -31.48 | 115.56 | 0.5467 | 747.0 | 534.7 | |
| 0.00 | 1.13 | 0.00 | 0.67 | -19.67 | 328.67 | -31.60 | 115.27 | 0.5477 | 731.0 | 593.2 | |
| 6.42 | 125.18 | 3.77 | 73.78 | -17.37 | 328.56 | -31.71 | 111.13 | 0.5399 | 1180.8 | 489.5 | |
| 18.55 | -3.00 | 10.95 | -3.00 | -17.37 | 328.11 | -32.15 | 110.94 | 0.5459 | 984.7 | 999999 | |
| 9.28 | -3.00 | 5.50 | -3.00 | -17.56 | 327.67 | -32.59 | 111.08 | 0.5526 | 881.4 | 999999 | |
| 2.43 | 98.48 | 1.45 | 59.32 | -18.47 | 327.18 | -33.09 | 112.47 | 0.5625 | 668.4 | 57.4 | |
| 0.00 | 1.56 | 0.00 | 0.93 | -17.27 | 327.43 | -32.83 | 110.47 | 0.5548 | 405.0 | 364.6 | |
| 1.99 | 4.42 | 1.19 | 2.64 | -17.83 | 327.28 | -32.99 | 111.41 | 0.5589 | 776.1 | 606.7 | |
| 0.00 | 1.73 | 0.00 | 1.04 | -18.14 | 327.21 | -33.05 | 111.90 | 0.5608 | 786.0 | 678.8 | |
| 5.72 | 7.80 | 3.42 | 4.66 | -17.48 | 327.01 | -33.25 | 110.69 | 0.5612 | 896.8 | 674.7 | |
| 6.15 | -6.00 | 3.70 | -6.00 | -18.35 | 326.79 | -33.47 | 112.10 | 0.5672 | 647.3 | 999999 | |
| 0.00 | 1.30 | 0.00 | 0.78 | -18.94 | 326.50 | -33.76 | 112.98 | 0.5731 | 446.0 | 257.5 | |
| 10.84 | -6.00 | 6.51 | -6.00 | -17.79 | 326.61 | -33.65 | 111.06 | 0.5676 | 851.5 | 999999 | |
| 4.59 | -6.00 | 2.77 | -6.00 | -18.44 | 326.28 | -33.98 | 112.03 | 0.5743 | 478.2 | 999999 | |
| 0.00 | 4.59 | 0.00 | 2.78 | -18.89 | 326.17 | -34.09 | 112.75 | 0.5773 | -432.0 | -295.0 | |
| 2.69 | -6.00 | 1.62 | -6.00 | -17.67 | 326.26 | -34.00 | 110.72 | 0.5719 | 707.5 | 999999 | |
| 0.00 | 1.99 | 0.00 | 1.20 | -16.84 | 326.06 | -34.20 | 109.22 | 0.5720 | 616.0 | 503.4 | |
| 0.00 | 2.69 | 0.00 | 1.65 | -19.50 | 325.22 | -35.04 | 113.37 | 0.5918 | -550.0 | -340.2 | |
| 1.30 | 25.66 | 0.79 | 15.65 | -17.54 | 325.64 | -34.62 | 110.27 | 0.5797 | 667.7 | -123.5 | |
| 0.00 | 2.51 | 0.00 | 1.53 | -18.20 | 325.46 | -34.81 | 111.31 | 0.5843 | -149.0 | -124.5 | |
| 1.91 | 17.16 | 1.17 | 10.58 | -19.39 | 324.94 | -35.32 | 113.07 | 0.5951 | -848.1 | -726.6 | |
| 3.81 | 8.24 | 2.34 | 5.06 | -18.68 | 324.92 | -35.34 | 111.90 | 0.5929 | -864.9 | -584.5 | |
| 5.89 | -19.00 | 3.60 | -19.00 | -17.71 | 325.07 | -35.19 | 110.36 | 0.5878 | -564.4 | 999999 | |
| 1.73 | -21.00 | 1.07 | -21.00 | -19.31 | 324.69 | -35.58 | 112.84 | 0.5980 | -975.8 | 999999 | |
| 4.94 | -19.00 | 3.02 | -19.00 | -17.59 | 325.06 | -35.20 | 110.15 | 0.5876 | 317.6 | 999999 | |
| 0.00 | 1.21 | 0.00 | 0.73 | -14.23 | 325.62 | -34.64 | 104.59 | 0.5715 | 498.0 | 442.9 | |
| 2.34 | 138.70 | 1.45 | 86.60 | -19.39 | 324.12 | -36.14 | 112.75 | 0.6056 | -769.7 | -225.4 | |
| 0.00 | 1.39 | 0.00 | 0.86 | -18.84 | 324.22 | -36.04 | 111.91 | 0.6025 | -342.0 | -247.2 | |
| 0.52 | 1.73 | 0.32 | 1.07 | -17.81 | 324.35 | -35.91 | 110.28 | 0.5975 | 623.8 | 413.2 | |
| 2.86 | -27.00 | 1.77 | -27.00 | -17.79 | 324.01 | -36.25 | 110.12 | 0.6019 | 658.6 | 999999 | |
| 21.15 | -27.00 | 13.16 | -27.00 | -18.10 | 323.66 | -36.60 | 110.51 | 0.6073 | 841.3 | 999999 | |
| 7.11 | -27.00 | 4.45 | -27.00 | -19.09 | 323.41 | -36.85 | 112.01 | 0.6136 | -976.2 | 999999 | |
| 0.00 | 2.34 | 0.00 | 1.47 | -19.23 | 323.22 | -37.05 | 112.17 | 0.6165 | -505.0 | -364.3 | |
| 0.00 | 1.13 | 0.00 | 0.70 | -17.45 | 323.62 | -36.64 | 109.45 | 0.6060 | 619.0 | 538.5 | |
| 2.34 | -27.00 | 1.47 | -27.00 | -18.36 | 323.09 | -37.18 | 110.74 | 0.6155 | 271.3 | 999999 | |
| 3.21 | -27.00 | 2.02 | -27.00 | -18.86 | 322.84 | -37.43 | 111.46 | 0.6202 | 401.2 | 999999 | |
| 0.00 | 2.25 | 0.00 | 1.43 | -20.13 | 322.45 | -37.81 | 113.30 | 0.6290 | 729.0 | 565.3 | |
| 0.00 | 2.69 | 0.00 | 1.71 | -19.69 | 322.41 | -37.85 | 112.61 | 0.6281 | 885.0 | 720.7 | |
| 5.37 | 10.32 | 3.43 | 6.59 | -20.04 | 322.07 | -38.19 | 113.02 | 0.6334 | 855.9 | 569.8 | |
| 0.00 | 5.72 | 0.00 | 3.66 | -19.62 | 321.91 | -38.36 | 112.33 | 0.6342 | 630.0 | 437.8 | |
| 0.00 | 2.34 | 0.00 | 1.50 | -20.26 | 321.72 | -38.54 | 113.24 | 0.6384 | 513.0 | 330.6 | |
| 2.08 | 3.81 | 1.32 | 2.41 | -17.84 | 322.23 | -38.03 | 109.65 | 0.6251 | -694.6 | -466.8 | |
| 0.00 | 1.39 | 0.00 | 0.88 | -17.43 | 322.13 | -38.13 | 108.98 | 0.6253 | 287.0 | 189.2 | |
| 0.00 | 1.21 | 0.00 | 0.77 | -17.71 | 321.70 | -38.56 | 109.29 | 0.6314 | -582.0 | -498.4 | |
| 0.00 | 1.65 | 0.00 | 1.06 | -17.76 | 321.25 | -39.02 | 109.25 | 0.6374 | 563.0 | 374.0 | |
| 0.00 | 0.52 | 0.00 | 0.33 | -18.18 | 321.09 | -39.17 | 109.85 | 0.6403 | -746.0 | -663.5 | |
| 6.24 | 20.20 | 4.04 | 13.04 | -18.08 | 320.67 | -39.59 | 109.59 | 0.6454 | -965.4 | -567.4 | |
| 2.51 | 321.79 | 1.66 | 213.51 | -20.85 | 319.84 | -40.42 | 113.50 | 0.6630 | -799.5 | -328.1 | |
| 0.00 | 1.47 | 0.00 | 0.96 | -19.21 | 320.15 | -40.12 | 111.15 | 0.6547 | -226.0 | -291.1 | |
| 0.00 | 0.52 | 0.00 | 0.34 | -17.10 | 320.65 | -39.62 | 108.08 | 0.6434 | 316.0 | 385.0 | |
| 13.52 | -48.00 | 8.94 | -48.00 | -20.47 | 319.63 | -40.63 | 112.86 | 0.6644 | -1082.4 | 999999 | |
| 0.35 | 1.47 | 0.23 | 0.96 | -17.97 | 320.38 | -39.89 | 109.34 | 0.6488 | -838.5 | -701.2 | |
| 0.00 | 0.95 | 0.00 | 0.62 | -18.18 | 320.32 | -39.94 | 109.64 | 0.6500 | -612.0 | -530.0 | |
| 0.00 | 0.69 | 0.00 | 0.45 | -18.80 | 320.06 | -40.20 | 110.51 | 0.6547 | -631.0 | -503.0 | |
| 0.00 | 0.52 | 0.00 | 0.34 | -18.11 | 320.22 | -40.05 | 109.51 | 0.6511 | -585.0 | -538.3 | |
| 1.56 | -48.00 | 1.04 | -48.00 | -20.90 | 319.20 | -41.07 | 113.36 | 0.6709 | -589.6 | 999999 | |
| 2.08 | -48.00 | 1.38 | -48.00 | -20.05 | 319.47 | -40.79 | 112.20 | 0.6652 | -998.4 | 999999 | |
| 0.87 | -48.00 | 0.58 | -48.00 | -20.74 | 319.21 | -41.06 | 113.13 | 0.6703 | -680.0 | 999999 | |
| 1.21 | 3.81 | 0.79 | 2.48 | -17.79 | 320.10 | -40.17 | 109.00 | 0.6518 | -723.7 | -617.4 | |
| 4.16 | -48.00 | 2.76 | -48.00 | -20.00 | 319.20 | -41.07 | 112.04 | 0.6684 | -747.7 | 999999 | |
| 15.43 | -48.00 | 10.18 | -48.00 | -18.90 | 319.41 | -40.86 | 110.49 | 0.6630 | -1096.0 | 999999 | |
| 11.01 | -48.00 | 7.31 | -48.00 | -19.65 | 319.14 | -41.13 | 111.52 | 0.6682 | -1070.9 | 999999 | |
| 1.30 | -48.00 | 0.87 | -48.00 | -19.78 | 318.84 | -41.42 | 111.63 | 0.6720 | -507.7 | 999999 | |
| 22.97 | -48.00 | 15.29 | -48.00 | -19.36 | 318.89 | -41.37 | 111.01 | 0.6703 | -924.9 | 999999 | |
| 5.81 | -48.00 | 3.86 | -48.00 | -18.79 | 318.81 | -41.45 | 110.17 | 0.6700 | -668.1 | 999999 | |
| 0.00 | 0.87 | 0.00 | 0.59 | -18.81 | 317.49 | -42.78 | 109.86 | 0.6859 | -183.0 | -282.6 | |
| 0.00 | 0.78 | 0.00 | 0.53 | -18.49 | 317.33 | -42.93 | 109.37 | 0.6871 | -488.0 | -382.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
