SDO HMI 2014-03-11 23:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 34.77 | 163.95 | 17.59 | 82.75 | -10.52 | 357.81 | 9.62 | 245.91 | 0.1890 | 430.2 | 350.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-11 23:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.30 | 0.00 | 0.66 | -8.23 | 1.96 | 13.78 | 264.90 | 0.2377 | 711.0 | 548.3 | |
| 0.00 | 0.87 | 0.00 | 0.45 | -15.73 | 1.14 | 12.95 | 235.04 | 0.2645 | 719.0 | 463.3 | |
| 0.00 | 1.47 | 0.00 | 0.75 | -7.14 | 0.26 | 12.08 | 269.66 | 0.2086 | 813.0 | 687.6 | |
| 0.00 | 1.82 | 0.00 | 0.92 | -6.73 | 0.25 | 12.07 | 271.66 | 0.2087 | 814.0 | 602.8 | |
| 0.00 | 1.04 | 0.00 | 0.53 | -6.28 | 0.24 | 12.06 | 273.81 | 0.2091 | 754.0 | 640.1 | |
| 0.00 | 0.87 | 0.00 | 0.45 | -20.07 | 0.91 | 12.72 | 222.57 | 0.3071 | 678.0 | 502.7 | |
| 1.04 | 2.17 | 0.53 | 1.10 | -8.13 | 0.23 | 12.04 | 264.91 | 0.2083 | 929.2 | 757.8 | |
| 0.00 | 0.78 | 0.00 | 0.39 | -6.94 | 0.11 | 11.92 | 270.67 | 0.2060 | 872.0 | 791.7 | |
| 16.39 | 55.84 | 8.30 | 28.29 | -9.97 | 0.17 | 11.98 | 256.10 | 0.2116 | 1162.3 | 490.5 | |
| 0.00 | 5.38 | 0.00 | 2.72 | -7.71 | 0.10 | 11.91 | 266.89 | 0.2058 | 882.0 | 870.9 | |
| 0.00 | 1.73 | 0.00 | 0.88 | -8.28 | 0.08 | 11.90 | 264.13 | 0.2060 | 928.0 | 738.5 | |
| 0.00 | 1.04 | 0.00 | 0.53 | -6.40 | 0.00 | 11.82 | 273.31 | 0.2048 | 830.0 | 656.0 | |
| 0.00 | 1.47 | 0.00 | 0.75 | -7.36 | 359.87 | 11.69 | 268.61 | 0.2019 | 675.0 | 545.2 | |
| 0.00 | 2.25 | 0.00 | 1.14 | -7.72 | 359.57 | 11.39 | 266.75 | 0.1969 | 813.0 | 768.0 | |
| 16.39 | 20.20 | 8.28 | 10.21 | -9.33 | 359.59 | 11.40 | 258.65 | 0.1999 | 1064.6 | 677.9 | |
| 0.00 | 3.47 | 0.00 | 1.75 | -7.52 | 359.39 | 11.20 | 267.78 | 0.1936 | 961.0 | 868.8 | |
| 0.00 | 0.95 | 0.00 | 0.48 | -6.96 | 359.37 | 11.19 | 270.72 | 0.1935 | 685.0 | 581.5 | |
| 0.00 | 3.73 | 0.00 | 1.88 | -7.08 | 359.19 | 11.01 | 270.10 | 0.1903 | 777.0 | 665.3 | |
| 0.00 | 0.87 | 0.00 | 0.44 | -7.50 | 359.11 | 10.92 | 267.89 | 0.1889 | 849.0 | 697.6 | |
| 0.00 | 1.73 | 0.00 | 0.87 | -8.51 | 358.86 | 10.67 | 262.36 | 0.1857 | 1019.0 | 808.2 | |
| 0.00 | 0.61 | 0.00 | 0.31 | -6.67 | 358.60 | 10.42 | 272.43 | 0.1806 | 407.0 | 624.7 | |
| 0.00 | 2.25 | 0.00 | 1.13 | -8.41 | 358.43 | 10.24 | 262.71 | 0.1782 | 974.0 | 797.3 | |
| 0.00 | 0.95 | 0.00 | 0.48 | -6.74 | 358.24 | 10.05 | 272.18 | 0.1743 | 716.0 | 695.4 | |
| 0.00 | 0.78 | 0.00 | 0.39 | -6.47 | 358.20 | 10.02 | 273.73 | 0.1740 | 892.0 | 773.7 | |
| 0.00 | 0.87 | 0.00 | 0.44 | -13.83 | 357.28 | 9.09 | 232.79 | 0.1936 | 748.0 | 642.3 | |
| 0.00 | 2.08 | 0.00 | 1.05 | -12.31 | 356.98 | 8.79 | 238.92 | 0.1752 | 989.0 | 719.8 | |
| 0.00 | 2.34 | 0.00 | 1.18 | -14.29 | 356.77 | 8.58 | 229.32 | 0.1916 | 908.0 | 724.1 | |
| 0.00 | 1.21 | 0.00 | 0.61 | -13.81 | 356.50 | 8.32 | 230.46 | 0.1830 | 970.0 | 837.9 | |
| 0.00 | 1.39 | 0.00 | 0.70 | -14.51 | 356.37 | 8.19 | 227.14 | 0.1889 | 883.0 | 636.9 | |
| 0.95 | 2.25 | 0.48 | 1.13 | -13.43 | 356.21 | 8.03 | 231.19 | 0.1751 | 973.3 | 837.6 | |
| 0.00 | 1.99 | 0.00 | 1.00 | -12.59 | 356.19 | 8.00 | 235.12 | 0.1663 | 856.0 | 699.2 | |
| 0.00 | 2.60 | 0.00 | 1.31 | -12.83 | 356.10 | 7.91 | 233.65 | 0.1675 | 923.0 | 700.6 | |
| 0.00 | 2.43 | 0.00 | 1.22 | -13.07 | 356.08 | 7.89 | 232.40 | 0.1696 | 1079.0 | 845.4 | |
| 0.00 | 1.65 | 0.00 | 0.83 | -13.80 | 355.30 | 7.11 | 226.16 | 0.1674 | 840.0 | 690.9 | |
| 0.00 | 1.13 | 0.00 | 0.57 | -14.43 | 355.25 | 7.07 | 223.33 | 0.1745 | 717.0 | 610.9 | |
| 0.00 | 2.51 | 0.00 | 1.26 | -14.11 | 355.15 | 6.96 | 224.28 | 0.1692 | 790.0 | 732.4 | |
| 0.00 | 0.87 | 0.00 | 0.44 | -15.88 | 354.77 | 6.58 | 216.10 | 0.1881 | -843.0 | -674.7 | |
| 0.00 | 0.95 | 0.00 | 0.48 | -15.53 | 354.23 | 6.05 | 214.98 | 0.1778 | -913.0 | -697.0 | |
| 0.00 | 1.65 | 0.00 | 0.83 | -15.86 | 354.18 | 5.99 | 213.67 | 0.1820 | -886.0 | -692.8 | |
| 0.00 | 1.39 | 0.00 | 0.70 | -15.65 | 354.11 | 5.92 | 214.05 | 0.1783 | -912.0 | -730.5 | |
| 0.00 | 1.21 | 0.00 | 0.61 | -17.07 | 354.06 | 5.87 | 209.69 | 0.1983 | -672.0 | -515.0 | |
| 0.00 | 0.87 | 0.00 | 0.43 | -8.34 | 353.20 | 5.02 | 257.12 | 0.0892 | -857.0 | -651.7 | |
| 0.00 | 4.08 | 0.00 | 2.04 | -14.56 | 351.52 | 3.33 | 203.77 | 0.1403 | -409.0 | -670.6 | |
| 0.00 | 0.87 | 0.00 | 0.43 | -11.93 | 351.24 | 3.06 | 212.45 | 0.0977 | -787.0 | -595.9 | |
| 0.00 | 1.21 | 0.00 | 0.60 | -6.24 | 350.72 | 2.54 | 291.29 | 0.0474 | -920.0 | -748.1 | |
| 0.00 | 0.87 | 0.00 | 0.43 | -11.13 | 350.48 | 2.29 | 209.96 | 0.0789 | -729.0 | -620.5 | |
| 0.00 | 2.43 | 0.00 | 1.21 | -13.25 | 350.40 | 2.21 | 199.72 | 0.1120 | -793.0 | -713.1 | |
| 0.00 | 1.04 | 0.00 | 0.52 | -9.88 | 349.68 | 1.50 | 209.12 | 0.0531 | -810.0 | -664.6 | |
| 0.00 | 1.13 | 0.00 | 0.56 | -11.61 | 349.35 | 1.17 | 194.68 | 0.0793 | -766.0 | -675.5 | |
| 0.00 | 0.95 | 0.00 | 0.47 | -12.98 | 349.27 | 1.08 | 190.40 | 0.1024 | -943.0 | -798.5 | |
| 0.00 | 1.91 | 0.00 | 0.95 | -12.83 | 348.84 | 0.65 | 186.51 | 0.0987 | -1128.0 | -908.9 | |
| 0.00 | 1.82 | 0.00 | 0.91 | -15.77 | 348.84 | 0.66 | 184.26 | 0.1496 | -827.0 | -610.6 | |
| 0.00 | 0.87 | 0.00 | 0.43 | -13.36 | 346.42 | -1.76 | 164.37 | 0.1116 | -846.0 | -635.3 | |
| 0.00 | 1.56 | 0.00 | 0.78 | -14.44 | 346.29 | -1.89 | 165.70 | 0.1302 | -900.0 | -672.3 | |
| 0.00 | 1.30 | 0.00 | 0.65 | -10.31 | 345.60 | -2.59 | 140.53 | 0.0702 | -809.0 | -643.9 | |
| 0.00 | 0.95 | 0.00 | 0.48 | -19.30 | 345.38 | -2.80 | 167.56 | 0.2153 | -746.0 | -594.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
