SDO HMI 2014-03-12 01:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 32.18 | 165.46 | 16.35 | 83.87 | -10.76 | 357.99 | 10.91 | 247.72 | 0.2091 | 425.9 | 352.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-12 01:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.47 | 0.00 | 0.77 | -14.68 | 4.76 | 17.68 | 245.24 | 0.3249 | 732.0 | 412.2 | |
| 0.00 | 0.78 | 0.00 | 0.40 | -14.14 | 2.19 | 15.11 | 243.77 | 0.2830 | 737.0 | 636.1 | |
| 0.00 | 2.08 | 0.00 | 1.06 | -7.18 | 0.27 | 13.19 | 269.41 | 0.2274 | 729.0 | 670.7 | |
| 0.00 | 2.43 | 0.00 | 1.24 | -6.79 | 0.26 | 13.18 | 271.12 | 0.2274 | 786.0 | 646.2 | |
| 0.87 | 4.86 | 0.44 | 2.47 | -8.16 | 0.27 | 13.19 | 265.07 | 0.2277 | 825.2 | 667.7 | |
| 0.00 | 3.21 | 0.00 | 1.63 | -7.83 | 0.23 | 13.14 | 266.50 | 0.2267 | 894.0 | 794.9 | |
| 0.43 | 56.90 | 0.22 | 28.95 | -9.68 | 0.23 | 13.15 | 258.41 | 0.2299 | 809.8 | 457.1 | |
| 0.00 | 1.39 | 0.00 | 0.71 | -7.00 | 0.08 | 13.00 | 270.20 | 0.2242 | 810.0 | 606.4 | |
| 0.00 | 1.13 | 0.00 | 0.57 | -6.44 | 0.07 | 12.98 | 272.73 | 0.2245 | 752.0 | 531.2 | |
| 16.22 | -7.00 | 8.25 | -7.00 | -9.98 | 0.15 | 13.07 | 257.05 | 0.2295 | 1128.9 | 999999 | |
| 0.00 | 2.69 | 0.00 | 1.37 | -7.60 | 0.07 | 12.98 | 267.53 | 0.2239 | 995.0 | 850.1 | |
| 0.00 | 0.78 | 0.00 | 0.40 | -7.45 | 359.91 | 12.82 | 268.18 | 0.2212 | 784.0 | 645.6 | |
| 0.00 | 1.73 | 0.00 | 0.88 | -7.76 | 359.58 | 12.49 | 266.74 | 0.2157 | 768.0 | 677.3 | |
| 14.66 | 18.39 | 7.44 | 9.33 | -9.34 | 359.60 | 12.51 | 259.47 | 0.2185 | 1045.4 | 724.2 | |
| 0.00 | 1.47 | 0.00 | 0.75 | -8.39 | 359.57 | 12.48 | 263.83 | 0.2161 | 799.0 | 602.5 | |
| 0.00 | 1.99 | 0.00 | 1.01 | -7.58 | 359.51 | 12.43 | 267.56 | 0.2145 | 1053.0 | 907.3 | |
| 0.00 | 1.21 | 0.00 | 0.62 | -8.54 | 359.42 | 12.33 | 263.06 | 0.2138 | 751.0 | 615.4 | |
| 0.00 | 1.47 | 0.00 | 0.75 | -7.26 | 359.26 | 12.17 | 269.08 | 0.2102 | 840.0 | 676.2 | |
| 0.00 | 0.95 | 0.00 | 0.48 | -7.15 | 359.16 | 12.08 | 269.65 | 0.2086 | 902.0 | 765.7 | |
| 0.00 | 1.13 | 0.00 | 0.57 | -8.49 | 358.86 | 11.78 | 263.04 | 0.2043 | 933.0 | 768.5 | |
| 0.00 | 0.95 | 0.00 | 0.49 | -13.81 | 358.89 | 11.80 | 239.47 | 0.2317 | 751.0 | 598.5 | |
| 0.00 | 1.30 | 0.00 | 0.66 | -6.62 | 358.54 | 11.45 | 272.35 | 0.1983 | 882.0 | 755.9 | |
| 0.00 | 3.30 | 0.00 | 1.67 | -8.41 | 358.46 | 11.38 | 263.25 | 0.1974 | 733.0 | 664.6 | |
| 0.00 | 1.91 | 0.00 | 0.96 | -6.72 | 358.33 | 11.24 | 271.93 | 0.1946 | 940.0 | 725.5 | |
| 0.00 | 2.43 | 0.00 | 1.22 | -10.64 | 357.49 | 10.40 | 250.88 | 0.1886 | 818.0 | 638.1 | |
| 0.00 | 1.91 | 0.00 | 0.97 | -14.57 | 357.21 | 10.12 | 232.69 | 0.2148 | 964.0 | 701.3 | |
| 0.00 | 1.21 | 0.00 | 0.61 | -12.29 | 356.90 | 9.81 | 241.58 | 0.1901 | 833.0 | 630.2 | |
| 0.00 | 1.39 | 0.00 | 0.70 | -14.30 | 356.82 | 9.73 | 232.68 | 0.2069 | 833.0 | 756.6 | |
| 0.00 | 1.30 | 0.00 | 0.66 | -13.83 | 356.58 | 9.50 | 233.96 | 0.1990 | 807.0 | 743.5 | |
| 0.00 | 1.21 | 0.00 | 0.61 | -14.13 | 356.41 | 9.32 | 232.22 | 0.1997 | 810.0 | 618.1 | |
| 0.00 | 0.69 | 0.00 | 0.35 | -12.43 | 356.31 | 9.23 | 239.52 | 0.1825 | 764.0 | 580.6 | |
| 0.00 | 3.56 | 0.00 | 1.79 | -13.47 | 356.23 | 9.14 | 234.47 | 0.1907 | 722.0 | 775.7 | |
| 0.00 | 3.56 | 0.00 | 1.79 | -13.18 | 356.22 | 9.13 | 235.76 | 0.1877 | 601.0 | 746.0 | |
| 0.00 | 3.21 | 0.00 | 1.62 | -12.67 | 356.17 | 9.08 | 237.98 | 0.1825 | 876.0 | 689.7 | |
| 0.00 | 1.13 | 0.00 | 0.57 | -12.85 | 356.17 | 9.09 | 237.15 | 0.1841 | 838.0 | 688.2 | |
| 0.00 | 1.04 | 0.00 | 0.53 | -17.54 | 356.28 | 9.19 | 220.16 | 0.2373 | -628.0 | -542.6 | |
| 0.00 | 1.56 | 0.00 | 0.79 | -17.49 | 355.42 | 8.34 | 217.62 | 0.2276 | -734.0 | -612.1 | |
| 0.00 | 1.39 | 0.00 | 0.70 | -13.88 | 355.22 | 8.13 | 229.55 | 0.1813 | 905.0 | 731.7 | |
| 0.00 | 1.99 | 0.00 | 1.00 | -14.03 | 355.13 | 8.04 | 228.61 | 0.1818 | 1025.0 | 883.7 | |
| 0.00 | 0.87 | 0.00 | 0.44 | -17.80 | 355.06 | 7.97 | 215.58 | 0.2280 | -731.0 | -626.7 | |
| 0.00 | 1.47 | 0.00 | 0.74 | -15.60 | 354.56 | 7.48 | 220.52 | 0.1938 | -804.0 | -648.8 | |
| 0.00 | 1.47 | 0.00 | 0.75 | -16.96 | 354.36 | 7.28 | 215.47 | 0.2098 | -657.0 | -547.7 | |
| 0.00 | 1.39 | 0.00 | 0.70 | -15.88 | 354.17 | 7.08 | 218.08 | 0.1931 | -800.0 | -700.2 | |
| 0.00 | 2.34 | 0.00 | 1.18 | -15.73 | 354.07 | 6.98 | 218.20 | 0.1901 | -930.0 | -784.0 | |
| 0.00 | 1.04 | 0.00 | 0.52 | -14.50 | 351.59 | 4.50 | 210.93 | 0.1486 | -899.0 | -732.3 | |
| 0.00 | 1.04 | 0.00 | 0.52 | -16.07 | 349.94 | 2.86 | 197.30 | 0.1619 | -837.0 | -650.7 | |
| 0.00 | 1.04 | 0.00 | 0.52 | -9.85 | 349.76 | 2.67 | 225.13 | 0.0652 | -869.0 | -698.5 | |
| 0.00 | 2.78 | 0.00 | 1.40 | -18.01 | 349.47 | 2.38 | 191.94 | 0.1921 | -621.0 | -647.0 | |
| 0.00 | 2.08 | 0.00 | 1.04 | -13.16 | 349.39 | 2.30 | 200.73 | 0.1111 | -791.0 | -620.7 | |
| 0.00 | 0.95 | 0.00 | 0.47 | -11.49 | 349.32 | 2.23 | 207.16 | 0.0839 | -837.0 | -660.4 | |
| 0.00 | 0.87 | 0.00 | 0.43 | -8.60 | 349.00 | 1.91 | 234.06 | 0.0410 | -923.0 | -751.2 | |
| 0.00 | 1.65 | 0.00 | 0.82 | -12.86 | 348.93 | 1.84 | 197.70 | 0.1036 | -1117.0 | -929.4 | |
| 0.00 | 0.95 | 0.00 | 0.48 | -15.77 | 348.83 | 1.74 | 191.12 | 0.1522 | -751.0 | -592.8 | |
| 0.00 | 1.56 | 0.00 | 0.78 | -13.07 | 348.04 | 0.96 | 189.08 | 0.1036 | -914.0 | -722.3 | |
| 0.00 | 0.95 | 0.00 | 0.48 | -13.37 | 346.39 | -0.69 | 173.72 | 0.1082 | -734.0 | -530.8 | |
| 0.00 | 1.04 | 0.00 | 0.52 | -14.51 | 346.29 | -0.79 | 173.98 | 0.1280 | -950.0 | -789.7 | |
| 0.00 | 0.87 | 0.00 | 0.43 | -14.24 | 346.11 | -0.97 | 172.31 | 0.1237 | -721.0 | -518.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
