SDO HMI 2014-03-13 03:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 14.85 | 84.56 | 55.97 | 410.46 | 13.96 | 54.54 | 81.73 | 285.01 | 0.9930 | -69.9 | -150.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-13 03:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.78 | 32.99 | 20.97 | 269.17 | 13.73 | 56.98 | 84.17 | 284.39 | 0.9980 | -221.0 | -159.6 | |
| 10.07 | 23.44 | 30.39 | 70.65 | 14.13 | 51.02 | 78.21 | 285.72 | 0.9869 | -11.9 | -83.4 | |
| 0.00 | 2.17 | 0.00 | 5.89 | 13.45 | 50.08 | 77.27 | 285.20 | 0.9839 | 101.0 | 72.6 | |
| 0.00 | 0.69 | 0.00 | 2.11 | 15.16 | 50.95 | 78.14 | 286.75 | 0.9872 | -300.0 | -223.8 | |
| 0.00 | 3.65 | 0.00 | 10.12 | 15.27 | 50.05 | 77.24 | 287.02 | 0.9848 | -398.0 | -381.6 | |
| 1.22 | 14.50 | 3.01 | 37.26 | 14.49 | 48.89 | 76.08 | 286.45 | 0.9808 | 171.2 | -234.8 | |
| 0.00 | 1.39 | 0.00 | 3.54 | 15.38 | 48.95 | 76.14 | 287.33 | 0.9815 | -448.0 | -400.6 | |
| 0.78 | 3.21 | 1.60 | 6.58 | 14.55 | 46.31 | 73.50 | 287.00 | 0.9716 | 274.4 | 233.0 | |
| 0.00 | 1.39 | 0.00 | 2.87 | 15.51 | 46.21 | 73.40 | 287.99 | 0.9720 | 318.0 | 295.1 | |
| 0.00 | 1.13 | 0.00 | 2.27 | 15.89 | 45.71 | 72.90 | 288.48 | 0.9703 | 437.0 | 424.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
