SDO HMI 2014-03-13 05:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.65 | 17.02 | 2.75 | 32.80 | -18.10 | 48.34 | 76.62 | 253.10 | 0.9669 | -70.4 | 33.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-13 05:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.04 | 0.00 | 2.48 | -17.95 | 51.41 | 79.70 | 253.10 | 0.9792 | 181.0 | 132.4 | |
| 0.00 | 2.61 | 0.00 | 5.48 | -17.04 | 49.61 | 77.90 | 254.14 | 0.9729 | 261.0 | 160.2 | |
| 0.00 | 1.30 | 0.00 | 3.13 | -18.31 | 51.54 | 79.82 | 252.72 | 0.9795 | -114.0 | -18.7 | |
| 0.00 | 3.04 | 0.00 | 6.32 | -17.80 | 49.53 | 77.81 | 253.37 | 0.9724 | 426.0 | 300.2 | |
| 0.00 | 1.13 | 0.00 | 2.23 | -17.98 | 48.77 | 77.05 | 253.22 | 0.9693 | 371.0 | 321.3 | |
| 1.65 | 4.43 | 2.75 | 7.39 | -18.30 | 45.84 | 74.12 | 253.01 | 0.9562 | -182.8 | -74.2 | |
| 0.00 | 1.65 | 0.00 | 2.75 | -19.24 | 45.91 | 74.20 | 252.03 | 0.9564 | -486.0 | -412.2 | |
| 0.00 | 1.30 | 0.00 | 2.13 | -18.95 | 45.44 | 73.73 | 252.35 | 0.9541 | -429.0 | -389.1 | |
| 0.00 | 0.52 | 0.00 | 0.89 | -19.66 | 46.34 | 74.62 | 251.58 | 0.9583 | -464.0 | -511.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
