SDO HMI 2014-03-13 06:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 9.29 | 23.97 | 7.21 | 18.64 | -9.53 | 22.12 | 50.95 | 263.55 | 0.7725 | -167.0 | 114.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-13 06:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.13 | 5.91 | 0.91 | 4.77 | -9.56 | 23.92 | 52.75 | 263.47 | 0.7924 | 670.2 | 542.1 | |
| 0.61 | 3.56 | 0.49 | 2.86 | -9.06 | 23.77 | 52.60 | 264.10 | 0.7909 | 570.0 | 566.0 | |
| 1.13 | -1.00 | 0.91 | -1.00 | -9.72 | 23.81 | 52.64 | 263.26 | 0.7911 | 635.9 | 999999 | |
| 0.43 | 1.82 | 0.34 | 1.44 | -9.57 | 22.88 | 51.71 | 263.49 | 0.7813 | 591.0 | 415.8 | |
| 0.00 | 0.61 | 0.00 | 0.47 | -7.80 | 21.87 | 50.70 | 265.82 | 0.7710 | -327.0 | -372.7 | |
| 0.00 | 1.56 | 0.00 | 1.21 | -9.05 | 22.05 | 50.88 | 264.19 | 0.7724 | -583.0 | -459.6 | |
| 5.99 | 8.86 | 4.56 | 6.74 | -9.72 | 21.04 | 49.87 | 263.36 | 0.7610 | -692.3 | -435.4 | |
| 0.00 | 0.78 | 0.00 | 0.59 | -9.29 | 20.77 | 49.60 | 263.93 | 0.7581 | -392.0 | -233.9 | |
| 0.00 | 0.87 | 0.00 | 0.56 | -11.31 | 11.65 | 40.48 | 260.97 | 0.6469 | -577.0 | -473.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
