SDO HMI 2014-03-13 20:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.47 | 8.84 | 1.01 | 6.02 | 16.29 | 0.28 | 36.80 | 303.10 | 0.6886 | 442.5 | 102.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-13 20:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.04 | 3.99 | 0.72 | 2.75 | 16.11 | 1.27 | 37.79 | 302.17 | 0.6979 | -741.1 | -645.2 | |
| 0.00 | 1.04 | 0.00 | 0.70 | 16.37 | 359.73 | 36.25 | 303.58 | 0.6833 | 575.0 | 514.8 | |
| 0.00 | 1.21 | 0.00 | 0.82 | 16.23 | 359.47 | 35.99 | 303.58 | 0.6796 | 758.0 | 609.4 | |
| 0.43 | 2.60 | 0.29 | 1.75 | 16.57 | 359.31 | 35.83 | 304.13 | 0.6802 | 755.8 | 659.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
