SDO HMI 2014-03-14 00:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 14.93 | 37.08 | 11.94 | 29.53 | 11.35 | 9.66 | 48.38 | 290.69 | 0.7857 | -38.8 | -130.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-14 00:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 3.47 | 13.11 | 2.83 | 10.64 | 11.77 | 10.53 | 49.25 | 290.85 | 0.7959 | -490.7 | -461.3 | |
| 2.08 | 4.08 | 1.65 | 3.24 | 10.30 | 9.83 | 48.55 | 289.35 | 0.7839 | 510.0 | 375.5 | |
| 2.86 | -1.00 | 2.32 | -1.00 | 11.99 | 10.21 | 48.93 | 291.24 | 0.7935 | -487.0 | 999999 | |
| 0.00 | 1.22 | 0.00 | 0.97 | 10.99 | 9.93 | 48.65 | 290.15 | 0.7873 | -372.0 | -297.0 | |
| 0.00 | 0.61 | 0.00 | 0.48 | 10.47 | 9.72 | 48.45 | 289.61 | 0.7835 | 355.0 | 251.1 | |
| 0.00 | 1.04 | 0.00 | 0.83 | 11.55 | 9.60 | 48.32 | 290.96 | 0.7859 | -611.0 | -465.6 | |
| 5.04 | 8.16 | 3.97 | 6.43 | 10.80 | 9.29 | 48.02 | 290.18 | 0.7802 | 414.4 | 282.2 | |
| 1.48 | 4.34 | 1.17 | 3.45 | 11.63 | 9.48 | 48.20 | 291.11 | 0.7850 | -568.0 | -423.0 | |
| 0.00 | 1.22 | 0.00 | 0.96 | 11.31 | 9.04 | 47.76 | 290.90 | 0.7794 | -420.0 | -348.9 | |
| 0.00 | 0.78 | 0.00 | 0.60 | 12.01 | 7.85 | 46.57 | 292.26 | 0.7699 | 253.0 | 221.6 | |
| 0.00 | 1.30 | 0.00 | 1.00 | 11.46 | 7.68 | 46.41 | 291.66 | 0.7660 | 300.0 | 334.3 | |
| 0.00 | 1.22 | 0.00 | 0.93 | 11.83 | 7.59 | 46.31 | 292.15 | 0.7665 | 457.0 | 362.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
