SDO HMI 2014-03-14 03:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 15.11 | 64.62 | 9.83 | 40.60 | -10.00 | 357.61 | 37.98 | 262.64 | 0.6127 | 236.8 | 216.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-14 03:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 3.82 | 5.73 | 2.53 | 3.79 | -7.83 | 1.55 | 41.92 | 266.29 | 0.6655 | 648.1 | 443.0 | |
| 0.00 | 0.43 | 0.00 | 0.29 | -7.19 | 1.39 | 41.76 | 267.28 | 0.6639 | 431.0 | 385.4 | |
| 0.00 | 3.73 | 0.00 | 2.46 | -7.35 | 1.29 | 41.66 | 267.05 | 0.6624 | 587.0 | 573.0 | |
| 0.00 | 1.22 | 0.00 | 0.80 | -7.91 | 1.03 | 41.40 | 266.21 | 0.6588 | 501.0 | 460.6 | |
| 0.00 | 1.91 | 0.00 | 1.25 | -6.01 | 0.79 | 41.16 | 269.12 | 0.6569 | 588.0 | 478.9 | |
| 0.00 | 2.17 | 0.00 | 1.42 | -6.84 | 0.83 | 41.20 | 267.84 | 0.6568 | 632.0 | 478.7 | |
| 0.00 | 1.04 | 0.00 | 0.68 | -7.19 | 0.67 | 41.04 | 267.33 | 0.6544 | 619.0 | 578.2 | |
| 0.00 | 2.17 | 0.00 | 1.41 | -7.03 | 0.41 | 40.78 | 267.59 | 0.6511 | 758.0 | 647.8 | |
| 0.00 | 0.69 | 0.00 | 0.45 | -8.67 | 0.13 | 40.50 | 265.07 | 0.6467 | 380.0 | 352.6 | |
| 8.34 | 11.47 | 5.40 | 7.43 | -9.78 | 0.16 | 40.53 | 263.36 | 0.6470 | 749.6 | 498.6 | |
| 2.52 | 4.43 | 1.62 | 2.86 | -9.17 | 359.83 | 40.20 | 264.30 | 0.6427 | 715.7 | 554.3 | |
| 0.00 | 0.96 | 0.00 | 0.62 | -9.86 | 359.85 | 40.22 | 263.22 | 0.6430 | 679.0 | 571.3 | |
| 0.43 | 1.56 | 0.28 | 1.00 | -8.62 | 359.21 | 39.58 | 265.17 | 0.6345 | 758.6 | 627.8 | |
| 0.00 | 2.69 | 0.00 | 1.72 | -13.16 | 359.14 | 39.51 | 257.99 | 0.6356 | 825.0 | 686.8 | |
| 0.00 | 0.96 | 0.00 | 0.61 | -13.72 | 358.97 | 39.34 | 257.09 | 0.6341 | 589.0 | 468.0 | |
| 0.00 | 2.87 | 0.00 | 1.79 | -11.00 | 357.48 | 37.85 | 261.29 | 0.6116 | 755.0 | 630.8 | |
| 0.00 | 1.39 | 0.00 | 0.86 | -11.78 | 356.71 | 37.08 | 259.94 | 0.6017 | 614.0 | 557.9 | |
| 0.00 | 0.96 | 0.00 | 0.59 | -15.56 | 356.21 | 36.58 | 253.58 | 0.6007 | 748.0 | 511.4 | |
| 0.00 | 1.39 | 0.00 | 0.85 | -14.81 | 355.22 | 35.59 | 254.58 | 0.5858 | 720.0 | 661.2 | |
| 0.00 | 0.78 | 0.00 | 0.46 | -12.34 | 352.55 | 32.92 | 258.37 | 0.5441 | -669.0 | -607.0 | |
| 0.00 | 1.04 | 0.00 | 0.62 | -16.14 | 353.10 | 33.47 | 251.68 | 0.5602 | -420.0 | -458.2 | |
| 0.00 | 1.65 | 0.00 | 0.96 | -9.73 | 351.58 | 31.95 | 263.12 | 0.5274 | -631.0 | -452.3 | |
| 0.00 | 1.13 | 0.00 | 0.67 | -14.90 | 352.17 | 32.54 | 253.60 | 0.5440 | -525.0 | -362.8 | |
| 0.00 | 0.96 | 0.00 | 0.56 | -14.03 | 352.00 | 32.37 | 255.13 | 0.5395 | -631.0 | -527.0 | |
| 0.00 | 0.78 | 0.00 | 0.46 | -13.17 | 351.43 | 31.80 | 256.60 | 0.5296 | -469.0 | -308.7 | |
| 0.00 | 1.56 | 0.00 | 0.91 | -11.02 | 351.08 | 31.45 | 260.60 | 0.5212 | -652.0 | -578.4 | |
| 0.00 | 1.13 | 0.00 | 0.66 | -14.10 | 351.35 | 31.72 | 254.82 | 0.5305 | -604.0 | -393.6 | |
| 0.00 | 1.13 | 0.00 | 0.65 | -9.34 | 350.19 | 30.56 | 263.79 | 0.5067 | -562.0 | -521.8 | |
| 0.00 | 1.48 | 0.00 | 0.85 | -16.06 | 349.97 | 30.34 | 250.64 | 0.5166 | -708.0 | -585.2 | |
| 0.00 | 1.04 | 0.00 | 0.59 | -9.78 | 348.42 | 28.79 | 262.76 | 0.4804 | -698.0 | -543.8 | |
| 0.00 | 2.43 | 0.00 | 1.36 | -7.71 | 347.50 | 27.87 | 267.11 | 0.4657 | -612.0 | -467.6 | |
| 0.00 | 1.74 | 0.00 | 0.97 | -13.89 | 346.84 | 27.21 | 253.68 | 0.4644 | -869.0 | -741.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
