SDO HMI 2014-03-14 10:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 184.62 | 871.08 | 94.74 | 446.83 | -18.53 | 324.68 | 8.88 | 214.37 | 0.2586 | -11.3 | 0.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-14 10:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.04 | 344.32 | 0.54 | 178.40 | -17.79 | 330.26 | 14.46 | 231.66 | 0.3045 | 831.7 | 407.0 | |
| 70.72 | -1.00 | 36.63 | -1.00 | -17.32 | 329.77 | 13.97 | 232.06 | 0.2936 | 1303.5 | 999999 | |
| 1.04 | -1.00 | 0.54 | -1.00 | -17.64 | 329.09 | 13.29 | 229.83 | 0.2879 | 969.7 | 999999 | |
| 0.00 | 1.13 | 0.00 | 0.59 | -18.87 | 328.73 | 12.93 | 225.83 | 0.2965 | 703.0 | 501.2 | |
| 0.00 | 1.13 | 0.00 | 0.59 | -19.27 | 328.63 | 12.83 | 224.62 | 0.2998 | 814.0 | 649.3 | |
| 0.00 | 1.39 | 0.00 | 0.71 | -16.27 | 328.29 | 12.49 | 232.21 | 0.2639 | 850.0 | 737.2 | |
| 0.00 | 2.26 | 0.00 | 1.17 | -18.66 | 328.46 | 12.66 | 225.77 | 0.2910 | 852.0 | 692.2 | |
| 1.39 | 5.99 | 0.72 | 3.09 | -18.00 | 328.38 | 12.57 | 227.37 | 0.2827 | 1006.3 | 875.5 | |
| 0.00 | 0.96 | 0.00 | 0.49 | -16.39 | 328.20 | 12.40 | 231.65 | 0.2639 | 1039.0 | 873.6 | |
| 0.00 | 1.22 | 0.00 | 0.62 | -14.65 | 327.91 | 12.11 | 236.79 | 0.2437 | 773.0 | 623.2 | |
| 0.00 | 1.91 | 0.00 | 0.97 | -14.20 | 327.86 | 12.05 | 238.29 | 0.2390 | 1053.0 | 788.3 | |
| 3.91 | 6.60 | 2.01 | 3.40 | -17.73 | 327.88 | 12.08 | 226.98 | 0.2738 | 1200.1 | 897.4 | |
| 0.00 | 1.04 | 0.00 | 0.53 | -15.11 | 327.65 | 11.85 | 234.65 | 0.2442 | 848.0 | 617.3 | |
| 0.00 | 2.43 | 0.00 | 1.25 | -18.13 | 327.68 | 11.88 | 225.43 | 0.2758 | 833.0 | 698.3 | |
| 0.00 | 0.87 | 0.00 | 0.45 | -17.70 | 326.66 | 10.86 | 224.16 | 0.2588 | 1125.0 | 910.6 | |
| 0.00 | 5.39 | 0.00 | 2.76 | -18.01 | 326.46 | 10.66 | 222.78 | 0.2601 | 799.0 | 657.4 | |
| 0.00 | 2.26 | 0.00 | 1.16 | -18.35 | 326.22 | 10.42 | 221.25 | 0.2616 | 1195.0 | 949.5 | |
| 0.00 | 1.13 | 0.00 | 0.58 | -19.51 | 326.17 | 10.36 | 218.20 | 0.2755 | 788.0 | 617.8 | |
| 13.12 | 43.09 | 6.74 | 22.10 | -18.84 | 325.96 | 10.16 | 219.29 | 0.2649 | 1105.0 | 673.8 | |
| 0.00 | 1.13 | 0.00 | 0.58 | -18.02 | 325.76 | 9.96 | 220.87 | 0.2524 | 881.0 | 681.1 | |
| 0.00 | 4.08 | 0.00 | 2.10 | -19.22 | 325.47 | 9.67 | 217.03 | 0.2646 | 798.0 | 633.9 | |
| 0.00 | 2.00 | 0.00 | 1.02 | -17.92 | 324.96 | 9.16 | 218.86 | 0.2424 | 997.0 | 804.7 | |
| 0.00 | 2.35 | 0.00 | 1.18 | -13.88 | 324.72 | 8.91 | 231.84 | 0.1922 | 1000.0 | 716.9 | |
| 0.00 | 1.04 | 0.00 | 0.53 | -19.14 | 324.64 | 8.84 | 214.81 | 0.2554 | 787.0 | 572.7 | |
| 0.00 | 1.13 | 0.00 | 0.58 | -17.81 | 324.10 | 8.30 | 216.47 | 0.2321 | -812.0 | -551.1 | |
| 0.00 | 1.65 | 0.00 | 0.84 | -18.45 | 324.03 | 8.23 | 214.61 | 0.2402 | -517.0 | -558.8 | |
| 0.00 | 1.22 | 0.00 | 0.62 | -18.63 | 323.91 | 8.11 | 213.78 | 0.2416 | -755.0 | -518.2 | |
| 0.00 | 0.87 | 0.00 | 0.44 | -18.76 | 323.86 | 8.05 | 213.30 | 0.2427 | -859.0 | -682.0 | |
| 0.00 | 2.43 | 0.00 | 1.24 | -18.67 | 323.66 | 7.86 | 212.88 | 0.2397 | -751.0 | -718.0 | |
| 0.00 | 1.74 | 0.00 | 0.88 | -17.88 | 323.59 | 7.79 | 214.63 | 0.2281 | -999.0 | -836.8 | |
| 1.04 | 5.56 | 0.53 | 2.84 | -19.25 | 323.34 | 7.54 | 210.49 | 0.2451 | -893.3 | -722.4 | |
| 1.56 | 8.95 | 0.80 | 4.56 | -18.76 | 323.25 | 7.45 | 211.30 | 0.2374 | -1044.6 | -651.4 | |
| 0.43 | 3.65 | 0.22 | 1.86 | -19.13 | 323.14 | 7.34 | 210.10 | 0.2417 | -1127.2 | -885.2 | |
| 0.00 | 1.48 | 0.00 | 0.75 | -19.41 | 323.09 | 7.29 | 209.34 | 0.2453 | -862.0 | -830.0 | |
| 0.35 | 1.91 | 0.18 | 0.97 | -18.04 | 323.00 | 7.20 | 212.17 | 0.2248 | 776.5 | 593.6 | |
| 0.00 | 4.95 | 0.00 | 2.52 | -18.47 | 322.92 | 7.12 | 210.87 | 0.2302 | -933.0 | -866.4 | |
| 0.00 | 0.96 | 0.00 | 0.49 | -18.22 | 322.88 | 7.08 | 211.30 | 0.2264 | -661.0 | -491.3 | |
| 0.00 | 4.69 | 0.00 | 2.40 | -19.44 | 322.84 | 7.03 | 208.43 | 0.2437 | -1042.0 | -844.1 | |
| 0.00 | 1.22 | 0.00 | 0.62 | -18.83 | 322.75 | 6.95 | 209.42 | 0.2341 | -1106.0 | -886.9 | |
| 0.00 | 2.00 | 0.00 | 1.00 | -13.61 | 322.51 | 6.71 | 225.14 | 0.1609 | 1026.0 | 801.9 | |
| 0.00 | 1.82 | 0.00 | 0.92 | -15.48 | 322.13 | 6.33 | 216.18 | 0.1807 | 973.0 | 775.4 | |
| 0.00 | 2.17 | 0.00 | 1.11 | -19.05 | 322.19 | 6.38 | 206.96 | 0.2328 | -1145.0 | -878.6 | |
| 4.52 | 99.22 | 2.32 | 50.76 | -20.79 | 322.22 | 6.42 | 203.87 | 0.2595 | 976.8 | -167.6 | |
| 0.00 | 1.04 | 0.00 | 0.53 | -18.93 | 322.15 | 6.35 | 207.08 | 0.2307 | -914.0 | -682.1 | |
| 25.20 | -43.00 | 12.88 | -43.00 | -20.09 | 321.97 | 6.17 | 204.23 | 0.2471 | -1192.9 | 999999 | |
| 0.00 | 2.95 | 0.00 | 1.50 | -18.58 | 321.06 | 5.26 | 203.67 | 0.2174 | -971.0 | -716.5 | |
| 0.00 | 3.30 | 0.00 | 1.68 | -19.43 | 320.96 | 5.16 | 201.73 | 0.2301 | -963.0 | -858.8 | |
| 0.00 | 4.52 | 0.00 | 2.30 | -19.65 | 320.75 | 4.94 | 200.55 | 0.2322 | -1002.0 | -899.2 | |
| 0.00 | 0.78 | 0.00 | 0.40 | -20.29 | 320.73 | 4.93 | 199.53 | 0.2423 | -829.0 | -685.0 | |
| 0.00 | 5.21 | 0.00 | 2.66 | -20.57 | 320.68 | 4.88 | 198.93 | 0.2464 | -649.0 | -671.9 | |
| 0.00 | 1.74 | 0.00 | 0.89 | -20.05 | 320.60 | 4.80 | 199.39 | 0.2377 | -943.0 | -735.7 | |
| 0.00 | 4.60 | 0.00 | 2.34 | -19.68 | 320.40 | 4.60 | 199.17 | 0.2307 | -1268.0 | -950.3 | |
| 0.00 | 1.56 | 0.00 | 0.79 | -18.28 | 320.17 | 4.37 | 200.55 | 0.2071 | -1031.0 | -706.2 | |
| 0.00 | 0.52 | 0.00 | 0.27 | -24.62 | 320.36 | 4.56 | 193.53 | 0.3101 | -734.0 | -548.8 | |
| 0.00 | 1.65 | 0.00 | 0.84 | -20.42 | 320.23 | 4.42 | 197.49 | 0.2417 | -678.0 | -539.2 | |
| 0.00 | 1.65 | 0.00 | 0.84 | -19.59 | 320.11 | 4.31 | 198.19 | 0.2278 | -919.0 | -626.3 | |
| 0.00 | 0.87 | 0.00 | 0.44 | -19.60 | 319.44 | 3.64 | 195.53 | 0.2246 | -664.0 | -543.8 | |
| 25.20 | 171.42 | 12.77 | 86.78 | -18.90 | 319.15 | 3.34 | 195.18 | 0.2117 | -1245.4 | -481.6 | |
| 11.47 | -58.00 | 5.80 | -58.00 | -18.47 | 319.04 | 3.24 | 195.29 | 0.2043 | -1313.1 | 999999 | |
| 19.72 | 61.43 | 10.07 | 31.41 | -20.95 | 319.03 | 3.22 | 192.43 | 0.2451 | -1180.8 | -408.6 | |
| 0.96 | -58.00 | 0.49 | -58.00 | -19.48 | 318.93 | 3.13 | 193.58 | 0.2204 | -909.6 | 999999 | |
| 2.95 | -58.00 | 1.50 | -58.00 | -19.33 | 318.90 | 3.10 | 193.61 | 0.2178 | -1081.0 | 999999 | |
| 0.00 | 1.39 | 0.00 | 0.70 | -16.69 | 318.51 | 2.71 | 195.33 | 0.1723 | -939.0 | -729.6 | |
| 0.00 | 18.07 | 0.00 | 9.20 | -20.18 | 318.22 | 2.41 | 189.96 | 0.2297 | -1192.0 | -933.5 | |
| 0.00 | 4.78 | 0.00 | 2.44 | -20.58 | 318.13 | 2.32 | 189.30 | 0.2362 | -913.0 | -692.5 | |
| 0.00 | 2.26 | 0.00 | 1.15 | -20.61 | 313.25 | -2.55 | 169.85 | 0.2372 | -788.0 | -403.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
