SDO HMI 2014-03-14 19:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 90.11 | 456.38 | 77.72 | 386.22 | 11.79 | 260.20 | -50.65 | 69.38 | 0.8051 | -744.7 | -226.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-14 19:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.48 | 0.00 | 1.13 | 11.63 | 264.60 | -46.26 | 68.08 | 0.7650 | -363.0 | -324.3 | |
| 0.78 | 408.98 | 0.61 | 323.86 | 12.47 | 264.01 | -46.85 | 67.32 | 0.7743 | -1233.8 | -266.4 | |
| 77.00 | -2.00 | 60.90 | -2.00 | 12.09 | 263.10 | -47.75 | 68.17 | 0.7820 | -1102.4 | 999999 | |
| 1.39 | -2.00 | 1.13 | -2.00 | 12.15 | 261.89 | -48.96 | 68.60 | 0.7942 | 47.3 | 999999 | |
| 0.00 | 1.04 | 0.00 | 0.88 | 13.93 | 260.74 | -50.11 | 66.97 | 0.8115 | -509.0 | -396.4 | |
| 0.00 | 0.78 | 0.00 | 0.66 | 14.10 | 260.64 | -50.21 | 66.82 | 0.8130 | -352.0 | -260.6 | |
| 0.00 | 1.56 | 0.00 | 1.32 | 12.74 | 260.31 | -50.54 | 68.52 | 0.8115 | -512.0 | -352.6 | |
| 0.00 | 1.04 | 0.00 | 0.87 | 11.50 | 260.20 | -50.65 | 70.02 | 0.8085 | -358.0 | -278.6 | |
| 0.00 | 0.52 | 0.00 | 0.68 | 11.05 | 245.36 | -65.50 | 74.90 | 0.9267 | 468.0 | 464.5 | |
| 10.94 | 40.98 | 15.08 | 56.82 | 10.02 | 243.81 | -67.04 | 76.32 | 0.9348 | 471.7 | 25.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
