SDO HMI 2014-03-15 00:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 89.99 | 475.56 | 72.68 | 379.39 | 11.80 | 260.25 | -47.85 | 68.22 | 0.7779 | -755.8 | -252.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-15 00:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 79.39 | 428.31 | 59.60 | 321.94 | 12.08 | 263.09 | -45.01 | 66.96 | 0.7538 | -1119.4 | -313.3 | |
| 0.00 | 1.13 | 0.00 | 0.89 | 13.89 | 260.97 | -47.13 | 65.73 | 0.7827 | -521.0 | -451.7 | |
| 0.00 | 0.61 | 0.00 | 0.48 | 14.16 | 260.81 | -47.29 | 65.49 | 0.7854 | -420.0 | -358.6 | |
| 0.00 | 0.52 | 0.00 | 0.44 | 13.39 | 257.98 | -50.12 | 67.59 | 0.8097 | -356.0 | -330.7 | |
| 0.00 | 0.52 | 0.00 | 0.51 | 14.84 | 252.03 | -56.07 | 68.15 | 0.8661 | -327.0 | -279.3 | |
| 0.00 | 0.43 | 0.00 | 0.54 | 12.19 | 244.02 | -64.08 | 73.35 | 0.9193 | 367.0 | 336.0 | |
| 0.00 | 0.78 | 0.00 | 0.96 | 11.45 | 244.19 | -63.90 | 74.09 | 0.9170 | 328.0 | 340.3 | |
| 10.60 | 42.65 | 13.08 | 52.82 | 10.01 | 243.78 | -64.32 | 75.72 | 0.9175 | 548.7 | 127.3 | |
| 0.00 | 0.61 | 0.00 | 0.81 | 12.22 | 242.40 | -65.70 | 73.71 | 0.9296 | 251.0 | 199.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
