SDO HMI 2014-03-15 03:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 94.81 | 493.71 | 74.61 | 380.72 | 11.80 | 260.36 | -46.09 | 67.48 | 0.7603 | -795.0 | -253.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-15 03:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 82.21 | 442.69 | 59.95 | 323.40 | 12.04 | 263.09 | -43.36 | 66.23 | 0.7361 | -1193.0 | -311.7 | |
| 0.00 | 1.13 | 0.00 | 0.87 | 13.86 | 261.09 | -45.36 | 64.95 | 0.7649 | -621.0 | -508.0 | |
| 0.00 | 0.78 | 0.00 | 0.61 | 11.66 | 259.66 | -46.79 | 68.28 | 0.7707 | -466.0 | -405.6 | |
| 0.00 | 2.09 | 0.00 | 1.74 | 12.25 | 256.28 | -50.17 | 68.96 | 0.8063 | -94.0 | -179.3 | |
| 0.00 | 1.48 | 0.00 | 1.51 | 12.85 | 248.49 | -57.96 | 70.96 | 0.8763 | 236.0 | 233.5 | |
| 0.00 | 4.00 | 0.00 | 4.08 | 12.00 | 248.27 | -58.18 | 71.96 | 0.8761 | 85.0 | 114.7 | |
| 12.60 | 40.84 | 14.66 | 47.65 | 10.02 | 243.73 | -62.72 | 75.33 | 0.9065 | 549.6 | 134.6 | |
| 0.00 | 0.70 | 0.00 | 0.86 | 12.28 | 242.42 | -64.03 | 73.24 | 0.9191 | 243.0 | 208.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
