SDO HMI 2014-03-15 11:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 93.70 | 527.36 | 67.95 | 375.18 | 11.77 | 260.53 | -41.54 | 65.27 | 0.7122 | -685.1 | -244.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-15 11:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 81.01 | 471.11 | 55.12 | 321.11 | 12.01 | 263.03 | -39.04 | 63.95 | 0.6881 | -1089.5 | -304.2 | |
| 0.00 | 1.48 | 0.00 | 1.04 | 13.33 | 261.67 | -40.40 | 63.03 | 0.7100 | -421.0 | -337.6 | |
| 0.00 | 0.78 | 0.00 | 0.56 | 13.69 | 261.07 | -41.01 | 62.90 | 0.7185 | -468.0 | -405.9 | |
| 0.00 | 1.56 | 0.00 | 1.11 | 11.30 | 259.98 | -42.10 | 66.56 | 0.7188 | -602.0 | -471.7 | |
| 0.00 | 1.13 | 0.00 | 0.80 | 10.79 | 259.78 | -42.29 | 67.32 | 0.7187 | -536.0 | -402.9 | |
| 0.00 | 1.13 | 0.00 | 0.84 | 12.00 | 257.79 | -44.28 | 66.75 | 0.7457 | -450.0 | -423.8 | |
| 0.00 | 0.96 | 0.00 | 0.71 | 11.46 | 257.13 | -44.95 | 67.73 | 0.7505 | -520.0 | -441.2 | |
| 0.00 | 2.35 | 0.00 | 1.80 | 11.91 | 255.72 | -46.36 | 67.81 | 0.7670 | -115.0 | -217.3 | |
| 0.00 | 0.70 | 0.00 | 0.62 | 14.00 | 249.82 | -52.25 | 67.74 | 0.8312 | 419.0 | 306.5 | |
| 0.00 | 0.35 | 0.00 | 0.32 | 11.38 | 247.31 | -54.76 | 71.61 | 0.8459 | 395.0 | 360.0 | |
| 0.00 | 0.70 | 0.00 | 0.66 | 9.54 | 245.65 | -56.43 | 74.21 | 0.8560 | 363.0 | 294.8 | |
| 0.00 | 1.13 | 0.00 | 1.14 | 10.46 | 243.69 | -58.38 | 73.73 | 0.8743 | 256.0 | 354.7 | |
| 12.69 | 43.98 | 12.83 | 44.47 | 10.06 | 243.69 | -58.38 | 74.18 | 0.8735 | 595.6 | 236.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
