SDO HMI 2014-03-15 14:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 54.49 | 237.22 | 86.58 | 375.65 | 5.26 | 11.28 | 70.85 | 277.97 | 0.9509 | 109.0 | 11.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-15 14:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.56 | 0.00 | 3.73 | 5.00 | 17.69 | 77.26 | 276.68 | 0.9793 | -21.0 | -78.1 | |
| 0.00 | 2.09 | 0.00 | 4.88 | 4.60 | 17.40 | 76.97 | 276.32 | 0.9780 | -292.0 | -156.2 | |
| 0.00 | 1.04 | 0.00 | 1.98 | 6.32 | 14.29 | 73.87 | 278.55 | 0.9667 | 357.0 | 330.7 | |
| 3.48 | 14.08 | 6.42 | 25.93 | 6.29 | 13.85 | 73.42 | 278.60 | 0.9647 | -290.0 | -125.0 | |
| 0.00 | 1.39 | 0.00 | 2.33 | 2.79 | 12.71 | 72.28 | 275.17 | 0.9566 | 447.0 | 394.8 | |
| 9.04 | 48.31 | 14.97 | 79.05 | 3.66 | 12.37 | 71.94 | 276.12 | 0.9556 | -503.8 | -299.6 | |
| 2.00 | -6.00 | 3.28 | -6.00 | 3.19 | 12.28 | 71.85 | 275.66 | 0.9548 | -425.0 | 999999 | |
| 2.61 | -6.00 | 4.18 | -6.00 | 2.87 | 11.84 | 71.42 | 275.39 | 0.9522 | -371.1 | 999999 | |
| 8.95 | 14.95 | 14.42 | 24.17 | 5.09 | 11.66 | 71.23 | 277.72 | 0.9531 | -109.3 | -283.1 | |
| 0.00 | 5.39 | 0.00 | 8.98 | 6.64 | 11.95 | 71.53 | 279.28 | 0.9559 | -256.0 | -200.6 | |
| 0.00 | 1.56 | 0.00 | 2.48 | 5.65 | 11.25 | 70.82 | 278.37 | 0.9514 | -205.0 | -183.2 | |
| 12.69 | 103.31 | 19.72 | 157.47 | 6.05 | 10.82 | 70.40 | 278.87 | 0.9495 | 398.7 | 261.0 | |
| 0.00 | 0.87 | 0.00 | 1.29 | 5.08 | 10.02 | 69.59 | 277.99 | 0.9442 | 409.0 | 450.4 | |
| 11.64 | -12.00 | 17.65 | -12.00 | 6.34 | 10.20 | 69.77 | 279.28 | 0.9464 | 679.0 | 999999 | |
| 2.52 | 41.71 | 3.66 | 61.95 | 4.61 | 9.65 | 69.23 | 277.56 | 0.9416 | 526.3 | -96.3 | |
| 1.56 | -15.00 | 2.28 | -15.00 | 4.97 | 9.65 | 69.22 | 277.94 | 0.9420 | 693.7 | 999999 | |
| 0.00 | 0.96 | 0.00 | 1.41 | 7.05 | 9.48 | 69.05 | 280.15 | 0.9430 | 441.0 | 414.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
