SDO HMI 2014-03-16 08:07:15 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 13.75 | 34.28 | 7.32 | 18.21 | 12.91 | 283.32 | -7.15 | 19.42 | 0.3649 | 13.7 | -232.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-16 08:07:15 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 5.57 | 8.61 | 2.94 | 4.55 | 12.63 | 285.00 | -5.47 | 15.41 | 0.3518 | -1004.7 | -694.9 | |
| 0.00 | 2.00 | 0.00 | 1.06 | 12.48 | 284.30 | -6.18 | 17.41 | 0.3527 | -828.0 | -698.5 | |
| 2.00 | 6.70 | 1.06 | 3.55 | 12.64 | 283.95 | -6.52 | 18.16 | 0.3570 | -1002.9 | -767.4 | |
| 0.00 | 2.87 | 0.00 | 1.52 | 12.71 | 283.67 | -6.80 | 18.82 | 0.3594 | -564.0 | -577.3 | |
| 0.00 | 1.04 | 0.00 | 0.56 | 13.19 | 283.32 | -7.15 | 19.27 | 0.3687 | -625.0 | -503.0 | |
| 0.00 | 0.70 | 0.00 | 0.37 | 13.82 | 281.97 | -8.50 | 21.94 | 0.3860 | 770.0 | 691.4 | |
| 0.00 | 0.35 | 0.00 | 0.18 | 11.83 | 281.88 | -8.59 | 24.31 | 0.3567 | 649.0 | 652.0 | |
| 0.00 | 2.00 | 0.00 | 1.06 | 12.30 | 281.74 | -8.73 | 24.10 | 0.3647 | 842.0 | 693.7 | |
| 6.18 | 8.44 | 3.32 | 4.53 | 13.83 | 281.66 | -8.81 | 22.65 | 0.3880 | 971.6 | 643.6 | |
| 0.00 | 1.57 | 0.00 | 0.83 | 11.99 | 281.60 | -8.87 | 24.82 | 0.3611 | 743.0 | 588.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
