SDO HMI 2014-03-16 11:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 8.88 | 30.62 | 4.71 | 16.24 | 13.04 | 283.22 | -5.67 | 15.49 | 0.3596 | 271.2 | -162.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-16 11:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.87 | 7.22 | 1.51 | 3.81 | 12.65 | 285.12 | -3.77 | 10.75 | 0.3458 | -1077.2 | -904.4 | |
| 0.00 | 2.00 | 0.00 | 1.06 | 12.50 | 284.36 | -4.54 | 12.96 | 0.3459 | -1020.0 | -874.1 | |
| 1.57 | 5.65 | 0.83 | 2.99 | 12.73 | 284.20 | -4.69 | 13.24 | 0.3501 | -948.7 | -839.9 | |
| 0.00 | 1.57 | 0.00 | 0.83 | 12.70 | 283.86 | -5.03 | 14.18 | 0.3509 | -749.0 | -599.4 | |
| 0.00 | 0.87 | 0.00 | 0.46 | 13.86 | 282.48 | -6.41 | 16.87 | 0.3752 | 817.0 | 602.6 | |
| 0.00 | 1.48 | 0.00 | 0.79 | 13.93 | 282.08 | -6.82 | 17.81 | 0.3783 | 1025.0 | 760.8 | |
| 0.00 | 1.22 | 0.00 | 0.64 | 12.22 | 281.75 | -7.14 | 20.18 | 0.3536 | 827.0 | 580.0 | |
| 4.44 | 6.96 | 2.37 | 3.72 | 13.85 | 281.58 | -7.31 | 19.09 | 0.3794 | 1058.1 | 738.3 | |
| 0.00 | 1.48 | 0.00 | 0.78 | 11.94 | 281.64 | -7.26 | 20.77 | 0.3500 | 928.0 | 720.8 | |
| 0.00 | 0.78 | 0.00 | 0.42 | 13.15 | 281.39 | -7.51 | 20.21 | 0.3699 | 770.0 | 638.9 | |
| 0.00 | 1.39 | 0.00 | 0.74 | 13.66 | 281.09 | -7.80 | 20.43 | 0.3793 | 755.0 | 477.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
