SDO HMI 2014-03-16 12:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 118.17 | 608.01 | 71.05 | 361.11 | 12.03 | 261.22 | -27.13 | 54.25 | 0.5481 | -629.9 | -334.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-16 12:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.00 | 9.91 | 1.17 | 5.81 | 14.59 | 264.10 | -24.25 | 47.87 | 0.5380 | 747.8 | 677.6 | |
| 0.61 | -1.00 | 0.36 | -1.00 | 14.27 | 264.10 | -24.24 | 48.32 | 0.5349 | 751.1 | 999999 | |
| 0.00 | 0.96 | 0.00 | 0.56 | 13.82 | 264.12 | -24.23 | 48.95 | 0.5305 | 526.0 | 367.2 | |
| 0.00 | 1.65 | 0.00 | 0.97 | 14.37 | 263.41 | -24.93 | 48.97 | 0.5435 | 657.0 | 467.4 | |
| 94.09 | 521.67 | 54.78 | 303.96 | 11.99 | 262.93 | -25.42 | 53.05 | 0.5275 | -1273.2 | -400.3 | |
| 0.00 | 3.04 | 0.00 | 1.80 | 13.73 | 262.43 | -25.91 | 50.99 | 0.5485 | -852.0 | -565.3 | |
| 0.96 | 9.74 | 0.57 | 5.76 | 13.86 | 262.38 | -25.96 | 50.85 | 0.5502 | -769.5 | -652.6 | |
| 1.65 | -5.00 | 0.97 | -5.00 | 12.17 | 262.47 | -25.88 | 53.27 | 0.5345 | -778.4 | 999999 | |
| 2.17 | -5.00 | 1.27 | -5.00 | 11.46 | 262.34 | -26.01 | 54.51 | 0.5299 | -1013.2 | 999999 | |
| 1.04 | -5.00 | 0.61 | -5.00 | 11.92 | 261.98 | -26.36 | 54.17 | 0.5380 | -786.8 | 999999 | |
| 0.00 | 2.43 | 0.00 | 1.45 | 13.90 | 261.73 | -26.62 | 51.50 | 0.5580 | -619.0 | -411.0 | |
| 1.65 | -5.00 | 0.97 | -5.00 | 12.27 | 261.84 | -26.50 | 53.77 | 0.5427 | -638.8 | 999999 | |
| 0.00 | 1.91 | 0.00 | 1.15 | 14.07 | 261.05 | -27.30 | 51.95 | 0.5671 | -801.0 | -548.9 | |
| 0.00 | 1.65 | 0.00 | 1.01 | 14.76 | 260.08 | -28.26 | 51.93 | 0.5838 | -616.0 | -435.3 | |
| 0.00 | 3.65 | 0.00 | 2.23 | 14.31 | 259.69 | -28.66 | 52.95 | 0.5844 | -898.0 | -678.6 | |
| 0.00 | 2.09 | 0.00 | 1.28 | 14.42 | 259.43 | -28.92 | 53.04 | 0.5883 | -590.0 | -498.0 | |
| 0.00 | 1.22 | 0.00 | 0.72 | 10.52 | 259.66 | -28.69 | 58.58 | 0.5552 | -695.0 | -576.6 | |
| 0.00 | 0.87 | 0.00 | 0.53 | 12.65 | 258.36 | -29.98 | 56.55 | 0.5867 | -740.0 | -587.7 | |
| 0.00 | 1.39 | 0.00 | 0.85 | 12.33 | 258.33 | -30.01 | 57.03 | 0.5847 | -820.0 | -708.0 | |
| 0.00 | 1.30 | 0.00 | 0.80 | 11.29 | 257.04 | -31.30 | 59.66 | 0.5926 | -535.0 | -410.8 | |
| 0.00 | 1.57 | 0.00 | 0.97 | 12.13 | 256.22 | -32.13 | 59.09 | 0.6083 | -674.0 | -556.7 | |
| 0.00 | 2.70 | 0.00 | 1.73 | 13.13 | 254.13 | -34.22 | 59.28 | 0.6393 | -697.0 | -587.2 | |
| 0.00 | 0.52 | 0.00 | 0.34 | 11.74 | 252.51 | -35.83 | 62.33 | 0.6495 | 550.0 | 452.5 | |
| 0.00 | 0.61 | 0.00 | 0.40 | 13.37 | 251.83 | -36.52 | 60.57 | 0.6670 | 529.0 | 467.0 | |
| 0.00 | 0.78 | 0.00 | 0.52 | 13.23 | 251.28 | -37.07 | 61.13 | 0.6723 | 690.0 | 609.1 | |
| 0.00 | 1.83 | 0.00 | 1.23 | 14.03 | 250.78 | -37.56 | 60.40 | 0.6825 | 632.0 | 518.7 | |
| 0.00 | 1.30 | 0.00 | 0.91 | 12.32 | 247.74 | -40.60 | 64.46 | 0.7070 | 626.0 | 534.3 | |
| 0.00 | 1.04 | 0.00 | 0.75 | 12.48 | 245.83 | -42.52 | 65.28 | 0.7288 | 603.0 | 470.6 | |
| 0.00 | 0.87 | 0.00 | 0.62 | 10.71 | 246.12 | -42.23 | 67.42 | 0.7175 | 714.0 | 601.5 | |
| 0.00 | 0.87 | 0.00 | 0.62 | 10.08 | 245.40 | -42.95 | 68.58 | 0.7229 | 543.0 | 484.1 | |
| 0.00 | 0.52 | 0.00 | 0.38 | 11.77 | 244.71 | -43.63 | 66.75 | 0.7376 | 599.0 | 558.8 | |
| 0.00 | 1.39 | 0.00 | 1.02 | 11.51 | 244.42 | -43.92 | 67.21 | 0.7396 | 694.0 | 599.9 | |
| 14.00 | 26.44 | 10.35 | 19.54 | 10.32 | 243.50 | -44.85 | 69.15 | 0.7448 | 772.3 | 485.4 | |
| 0.00 | 1.13 | 0.00 | 0.86 | 11.65 | 242.28 | -46.07 | 68.02 | 0.7629 | 317.0 | 357.8 | |
| 0.00 | 0.87 | 0.00 | 0.69 | 11.95 | 240.69 | -47.66 | 68.33 | 0.7804 | 431.0 | 338.3 | |
| 0.00 | 1.13 | 0.00 | 0.89 | 11.45 | 240.71 | -47.64 | 68.93 | 0.7783 | 412.0 | 349.6 | |
| 0.00 | 0.96 | 0.00 | 0.76 | 11.43 | 240.26 | -48.09 | 69.14 | 0.7828 | 432.0 | 316.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
