SDO HMI 2014-03-17 00:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 16.00 | 43.83 | 8.46 | 23.17 | 13.05 | 284.13 | 2.40 | 353.16 | 0.3500 | -54.3 | -221.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-17 00:00:29 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.26 | 4.70 | 1.19 | 2.48 | 12.62 | 285.69 | 3.95 | 348.74 | 0.3460 | -848.2 | -713.9 | |
| 3.57 | 19.57 | 1.88 | 10.33 | 12.62 | 285.29 | 3.55 | 349.85 | 0.3447 | -1016.4 | -724.2 | |
| 4.43 | -2.00 | 2.34 | -2.00 | 12.90 | 285.05 | 3.31 | 350.66 | 0.3487 | -963.4 | 999999 | |
| 0.70 | 2.00 | 0.37 | 1.05 | 12.20 | 284.64 | 2.91 | 351.49 | 0.3363 | -813.5 | -586.9 | |
| 0.00 | 1.39 | 0.00 | 0.74 | 13.18 | 284.59 | 2.86 | 352.04 | 0.3522 | -679.0 | -553.3 | |
| 0.00 | 1.91 | 0.00 | 1.00 | 12.01 | 284.33 | 2.60 | 352.30 | 0.3324 | 581.0 | 385.2 | |
| 0.00 | 0.78 | 0.00 | 0.41 | 12.83 | 284.34 | 2.61 | 352.60 | 0.3459 | -786.0 | -693.1 | |
| 0.00 | 0.87 | 0.00 | 0.46 | 11.85 | 283.69 | 1.96 | 354.13 | 0.3286 | 680.0 | 518.7 | |
| 0.00 | 1.39 | 0.00 | 0.73 | 12.35 | 282.48 | 0.74 | 357.83 | 0.3355 | 650.0 | 605.1 | |
| 0.00 | 2.00 | 0.00 | 1.07 | 14.49 | 282.24 | 0.50 | 358.68 | 0.3703 | 892.0 | 736.8 | |
| 0.00 | 0.96 | 0.00 | 0.51 | 14.30 | 282.15 | 0.41 | 358.91 | 0.3672 | 764.0 | 594.2 | |
| 0.00 | 1.30 | 0.00 | 0.69 | 13.31 | 281.65 | -0.08 | 0.23 | 0.3509 | 736.0 | 513.9 | |
| 5.04 | 6.96 | 2.68 | 3.70 | 14.30 | 281.59 | -0.14 | 0.38 | 0.3671 | 934.0 | 660.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
