SDO HMI 2014-03-17 04:00:30 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 7.14 | 72.05 | 3.69 | 37.85 | -11.42 | 297.86 | 18.32 | 254.47 | 0.3216 | -14.3 | -123.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-17 04:00:30 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.70 | 0.00 | 0.40 | -9.81 | 311.31 | 31.77 | 262.86 | 0.5249 | 608.0 | 500.4 | |
| 0.00 | 1.83 | 0.00 | 1.06 | -9.81 | 310.92 | 31.38 | 262.84 | 0.5192 | 625.0 | 527.8 | |
| 0.00 | 1.91 | 0.00 | 1.08 | -10.95 | 308.37 | 28.83 | 260.22 | 0.4824 | 623.0 | 520.2 | |
| 0.00 | 1.13 | 0.00 | 0.64 | -9.48 | 307.85 | 28.31 | 263.22 | 0.4729 | 677.0 | 536.8 | |
| 0.00 | 1.04 | 0.00 | 0.58 | -9.52 | 306.14 | 26.60 | 262.97 | 0.4469 | 687.0 | 639.0 | |
| 0.00 | 1.31 | 0.00 | 0.72 | -10.16 | 305.22 | 25.68 | 261.35 | 0.4333 | 436.0 | 295.5 | |
| 0.00 | 2.00 | 0.00 | 1.10 | -10.59 | 305.02 | 25.48 | 260.31 | 0.4308 | 733.0 | 648.9 | |
| 0.00 | 1.57 | 0.00 | 0.86 | -11.97 | 304.98 | 25.44 | 257.12 | 0.4329 | 875.0 | 697.0 | |
| 0.00 | 0.78 | 0.00 | 0.43 | -11.46 | 304.53 | 24.99 | 258.17 | 0.4248 | 659.0 | 580.8 | |
| 0.00 | 1.13 | 0.00 | 0.62 | -11.93 | 304.07 | 24.53 | 256.90 | 0.4188 | 770.0 | 637.8 | |
| 0.00 | 0.78 | 0.00 | 0.43 | -11.58 | 303.83 | 24.29 | 257.64 | 0.4144 | 734.0 | 577.0 | |
| 0.00 | 0.70 | 0.00 | 0.38 | -11.85 | 303.83 | 24.29 | 256.99 | 0.4149 | 659.0 | 487.8 | |
| 0.00 | 1.13 | 0.00 | 0.61 | -12.05 | 303.34 | 23.80 | 256.32 | 0.4080 | 747.0 | 622.5 | |
| 0.00 | 1.91 | 0.00 | 1.04 | -14.16 | 302.62 | 23.08 | 250.85 | 0.4041 | 655.0 | 534.2 | |
| 0.00 | 2.35 | 0.00 | 1.23 | -9.62 | 298.02 | 18.48 | 260.97 | 0.3178 | -813.0 | -649.0 | |
| 0.00 | 0.96 | 0.00 | 0.50 | -9.30 | 297.87 | 18.33 | 261.95 | 0.3149 | -804.0 | -725.4 | |
| 0.00 | 1.31 | 0.00 | 0.68 | -9.42 | 297.69 | 18.15 | 261.49 | 0.3121 | -731.0 | -639.8 | |
| 3.13 | 5.48 | 1.63 | 2.85 | -10.99 | 297.30 | 17.76 | 256.29 | 0.3096 | 841.8 | 702.2 | |
| 0.00 | 2.78 | 0.00 | 1.45 | -10.88 | 297.00 | 17.46 | 256.46 | 0.3045 | 835.0 | 778.1 | |
| 0.00 | 1.48 | 0.00 | 0.77 | -11.12 | 297.02 | 17.48 | 255.70 | 0.3055 | 787.0 | 672.6 | |
| 0.00 | 1.39 | 0.00 | 0.72 | -11.43 | 296.59 | 17.05 | 254.39 | 0.2998 | 586.0 | 438.1 | |
| 0.44 | 2.18 | 0.23 | 1.13 | -11.39 | 296.18 | 16.64 | 254.23 | 0.2929 | 956.0 | 763.0 | |
| 0.00 | 1.04 | 0.00 | 0.54 | -12.77 | 296.01 | 16.47 | 249.53 | 0.2964 | -788.0 | -607.2 | |
| 0.00 | 1.83 | 0.00 | 0.95 | -15.22 | 295.77 | 16.23 | 241.67 | 0.3077 | -869.0 | -710.3 | |
| 0.00 | 1.39 | 0.00 | 0.72 | -11.71 | 294.52 | 14.98 | 251.65 | 0.2678 | -788.0 | -705.4 | |
| 0.00 | 2.70 | 0.00 | 1.38 | -11.42 | 294.28 | 14.74 | 252.49 | 0.2627 | -902.0 | -796.2 | |
| 0.00 | 1.04 | 0.00 | 0.54 | -14.84 | 294.49 | 14.95 | 241.03 | 0.2863 | -765.0 | -727.2 | |
| 0.00 | 5.66 | 0.00 | 2.90 | -11.01 | 294.04 | 14.50 | 253.80 | 0.2571 | -971.0 | -760.3 | |
| 0.00 | 0.70 | 0.00 | 0.36 | -15.05 | 294.25 | 14.71 | 239.98 | 0.2845 | -770.0 | -625.6 | |
| 3.57 | 10.62 | 1.83 | 5.43 | -10.47 | 293.92 | 14.38 | 255.75 | 0.2531 | -1132.4 | -785.5 | |
| 0.00 | 1.13 | 0.00 | 0.58 | -15.24 | 293.97 | 14.43 | 238.95 | 0.2820 | -812.0 | -635.0 | |
| 0.00 | 1.65 | 0.00 | 0.84 | -8.70 | 293.10 | 13.56 | 262.43 | 0.2349 | -973.0 | -774.8 | |
| 0.00 | 3.57 | 0.00 | 1.82 | -8.68 | 292.82 | 13.28 | 262.41 | 0.2301 | -996.0 | -789.0 | |
| 0.00 | 1.04 | 0.00 | 0.53 | -14.26 | 292.61 | 13.07 | 239.89 | 0.2545 | -787.0 | -606.3 | |
| 0.00 | 1.83 | 0.00 | 0.94 | -16.04 | 292.47 | 12.93 | 233.72 | 0.2679 | -908.0 | -714.3 | |
| 0.00 | 0.96 | 0.00 | 0.49 | -15.80 | 292.45 | 12.91 | 234.45 | 0.2654 | -837.0 | -694.7 | |
| 0.00 | 1.04 | 0.00 | 0.55 | -21.10 | 292.36 | 12.82 | 220.30 | 0.3216 | 789.0 | 647.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
