SDO HMI 2014-03-17 04:00:30 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 109.55 | 646.58 | 61.63 | 360.48 | 12.08 | 260.91 | -18.63 | 43.08 | 0.4534 | -641.9 | -376.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-17 04:00:30 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.78 | 0.00 | 0.41 | 11.01 | 269.59 | -9.95 | 28.72 | 0.3546 | -559.0 | -453.8 | |
| 2.96 | 5.74 | 1.63 | 3.16 | 14.09 | 265.06 | -14.48 | 34.10 | 0.4344 | 919.9 | 626.0 | |
| 0.00 | 1.48 | 0.00 | 0.82 | 14.37 | 264.31 | -15.23 | 35.08 | 0.4446 | 677.0 | 486.5 | |
| 0.00 | 1.91 | 0.00 | 1.06 | 14.19 | 262.98 | -16.56 | 37.61 | 0.4547 | -700.0 | -526.4 | |
| 87.71 | 553.92 | 48.09 | 303.95 | 12.10 | 262.90 | -16.64 | 40.80 | 0.4303 | -1536.3 | -463.9 | |
| 0.00 | 1.39 | 0.00 | 0.77 | 14.21 | 262.69 | -16.85 | 38.07 | 0.4576 | -647.0 | -536.6 | |
| 0.00 | 5.74 | 0.00 | 3.20 | 14.09 | 262.31 | -17.23 | 38.85 | 0.4599 | -811.0 | -793.9 | |
| 2.52 | -5.00 | 1.39 | -5.00 | 12.04 | 262.04 | -17.50 | 42.33 | 0.4385 | -893.1 | 999999 | |
| 1.13 | -5.00 | 0.62 | -5.00 | 12.17 | 261.87 | -17.67 | 42.40 | 0.4418 | -793.3 | 999999 | |
| 0.00 | 1.39 | 0.00 | 0.78 | 13.93 | 261.52 | -18.02 | 40.34 | 0.4658 | -883.0 | -686.6 | |
| 0.00 | 0.61 | 0.00 | 0.35 | 14.56 | 259.54 | -20.00 | 42.40 | 0.4929 | -698.0 | -614.3 | |
| 0.00 | 1.39 | 0.00 | 0.79 | 14.41 | 259.39 | -20.15 | 42.83 | 0.4928 | -765.0 | -503.5 | |
| 0.00 | 1.65 | 0.00 | 0.92 | 11.07 | 259.01 | -20.53 | 48.48 | 0.4615 | -772.0 | -661.8 | |
| 0.00 | 1.74 | 0.00 | 0.98 | 12.51 | 258.54 | -21.00 | 46.83 | 0.4816 | -732.0 | -682.2 | |
| 0.00 | 1.83 | 0.00 | 1.04 | 12.94 | 258.18 | -21.36 | 46.67 | 0.4901 | -584.0 | -507.6 | |
| 0.00 | 1.31 | 0.00 | 0.74 | 11.77 | 258.21 | -21.33 | 48.45 | 0.4778 | -809.0 | -741.1 | |
| 0.00 | 1.48 | 0.00 | 0.83 | 11.48 | 258.23 | -21.31 | 48.87 | 0.4747 | -802.0 | -583.5 | |
| 0.00 | 1.31 | 0.00 | 0.74 | 11.67 | 257.66 | -21.88 | 49.33 | 0.4831 | -608.0 | -500.8 | |
| 0.00 | 2.52 | 0.00 | 1.42 | 11.27 | 257.53 | -22.01 | 50.15 | 0.4807 | -806.0 | -637.6 | |
| 0.00 | 0.87 | 0.00 | 0.49 | 9.68 | 257.32 | -22.22 | 53.06 | 0.4683 | -657.0 | -586.0 | |
| 0.00 | 1.04 | 0.00 | 0.61 | 13.33 | 255.51 | -24.03 | 49.43 | 0.5236 | -610.0 | -461.5 | |
| 0.00 | 1.91 | 0.00 | 1.12 | 12.88 | 254.38 | -25.16 | 51.40 | 0.5324 | -716.0 | -620.7 | |
| 0.00 | 0.70 | 0.00 | 0.41 | 13.05 | 254.33 | -25.21 | 51.21 | 0.5345 | -648.0 | -551.1 | |
| 0.00 | 1.04 | 0.00 | 0.61 | 13.50 | 254.11 | -25.43 | 50.78 | 0.5411 | -766.0 | -535.2 | |
| 0.00 | 0.87 | 0.00 | 0.51 | 12.19 | 253.23 | -26.31 | 53.69 | 0.5398 | 710.0 | 601.2 | |
| 0.00 | 3.83 | 0.00 | 2.30 | 13.41 | 251.89 | -27.65 | 53.24 | 0.5657 | 731.0 | 660.3 | |
| 0.00 | 0.35 | 0.00 | 0.21 | 13.04 | 251.69 | -27.85 | 53.98 | 0.5649 | 636.0 | 574.0 | |
| 0.00 | 0.96 | 0.00 | 0.58 | 13.85 | 251.52 | -28.02 | 52.98 | 0.5735 | 672.0 | 630.9 | |
| 0.00 | 0.87 | 0.00 | 0.53 | 13.64 | 251.34 | -28.20 | 53.46 | 0.5738 | 599.0 | 462.7 | |
| 0.00 | 1.13 | 0.00 | 0.70 | 11.32 | 247.63 | -31.91 | 60.08 | 0.6002 | 639.0 | 546.7 | |
| 0.00 | 0.78 | 0.00 | 0.50 | 15.83 | 246.84 | -32.70 | 54.47 | 0.6410 | 728.0 | 533.3 | |
| 0.00 | 1.13 | 0.00 | 0.70 | 10.84 | 247.41 | -32.13 | 60.97 | 0.5997 | 588.0 | 537.8 | |
| 0.00 | 1.31 | 0.00 | 0.81 | 11.02 | 247.10 | -32.44 | 60.95 | 0.6046 | 667.0 | 531.0 | |
| 0.00 | 1.13 | 0.00 | 0.69 | 6.65 | 246.74 | -32.80 | 67.89 | 0.5830 | 668.0 | 518.7 | |
| 0.00 | 0.87 | 0.00 | 0.55 | 10.75 | 246.04 | -33.50 | 62.12 | 0.6157 | 689.0 | 609.2 | |
| 0.00 | 0.96 | 0.00 | 0.60 | 10.94 | 245.98 | -33.56 | 61.89 | 0.6176 | 740.0 | 616.1 | |
| 0.00 | 1.22 | 0.00 | 0.77 | 10.89 | 245.36 | -34.18 | 62.40 | 0.6248 | 725.0 | 621.5 | |
| 0.00 | 1.22 | 0.00 | 0.78 | 11.44 | 245.18 | -34.36 | 61.75 | 0.6303 | 790.0 | 639.1 | |
| 0.00 | 1.31 | 0.00 | 0.84 | 12.04 | 245.06 | -34.48 | 60.98 | 0.6355 | 766.0 | 601.1 | |
| 0.00 | 0.87 | 0.00 | 0.56 | 11.16 | 244.74 | -34.80 | 62.45 | 0.6339 | 572.0 | 453.5 | |
| 0.00 | 0.87 | 0.00 | 0.55 | 8.54 | 244.35 | -35.19 | 66.50 | 0.6237 | 562.0 | 394.1 | |
| 0.00 | 1.04 | 0.00 | 0.70 | 15.73 | 243.04 | -36.50 | 57.47 | 0.6813 | 508.0 | 408.6 | |
| 12.70 | 19.93 | 8.20 | 12.87 | 10.34 | 243.54 | -36.00 | 64.40 | 0.6435 | 855.0 | 528.3 | |
| 0.00 | 1.48 | 0.00 | 0.99 | 11.76 | 241.81 | -37.73 | 63.52 | 0.6717 | 799.0 | 650.8 | |
| 0.96 | 10.09 | 0.64 | 6.77 | 11.64 | 241.36 | -38.18 | 63.96 | 0.6761 | 790.0 | 637.6 | |
| 0.70 | -45.00 | 0.47 | -45.00 | 11.41 | 241.09 | -38.45 | 64.43 | 0.6781 | 693.6 | 999999 | |
| 0.87 | 2.61 | 0.59 | 1.77 | 11.83 | 240.59 | -38.95 | 64.16 | 0.6860 | 769.3 | 599.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
