SDO HMI 2014-03-17 22:00:30 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 93.68 | 618.77 | 49.59 | 328.90 | 12.16 | 261.61 | -8.04 | 21.85 | 0.3619 | -785.6 | -428.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-17 22:00:30 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.74 | 2.96 | 0.92 | 1.57 | 13.55 | 265.55 | -4.11 | 11.16 | 0.3611 | 849.2 | 620.0 | |
| 0.00 | 1.22 | 0.00 | 0.63 | 9.99 | 264.90 | -4.75 | 15.53 | 0.3064 | -677.0 | -572.0 | |
| 88.55 | 551.89 | 46.82 | 291.86 | 12.19 | 262.75 | -6.90 | 19.61 | 0.3517 | -1452.9 | -486.3 | |
| 0.00 | 0.87 | 0.00 | 0.47 | 14.43 | 262.25 | -7.40 | 18.81 | 0.3886 | -671.0 | -513.4 | |
| 2.26 | -3.00 | 1.20 | -3.00 | 12.27 | 261.82 | -7.83 | 21.92 | 0.3582 | -807.8 | 999999 | |
| 0.00 | 1.74 | 0.00 | 0.93 | 14.19 | 261.52 | -8.14 | 20.76 | 0.3890 | -824.0 | -691.4 | |
| 0.00 | 2.09 | 0.00 | 1.12 | 13.97 | 261.15 | -8.50 | 21.81 | 0.3878 | -732.0 | -594.1 | |
| 0.00 | 1.13 | 0.00 | 0.61 | 14.52 | 259.73 | -9.93 | 24.46 | 0.4048 | -732.0 | -671.9 | |
| 0.00 | 0.43 | 0.00 | 0.24 | 14.26 | 259.58 | -10.07 | 25.05 | 0.4021 | -741.0 | -698.2 | |
| 0.00 | 1.04 | 0.00 | 0.55 | 11.37 | 259.60 | -10.05 | 28.49 | 0.3604 | -954.0 | -774.8 | |
| 0.00 | 0.96 | 0.00 | 0.51 | 11.17 | 259.05 | -10.60 | 30.08 | 0.3618 | -690.0 | -606.0 | |
| 0.00 | 0.96 | 0.00 | 0.51 | 12.56 | 258.94 | -10.72 | 28.48 | 0.3823 | -749.0 | -488.6 | |
| 0.00 | 1.22 | 0.00 | 0.65 | 11.77 | 258.94 | -10.72 | 29.51 | 0.3712 | -917.0 | -743.1 | |
| 0.00 | 1.04 | 0.00 | 0.56 | 12.02 | 258.93 | -10.73 | 29.20 | 0.3748 | -825.0 | -646.1 | |
| 0.00 | 3.65 | 0.00 | 1.95 | 11.87 | 258.62 | -11.03 | 30.09 | 0.3751 | -937.0 | -804.0 | |
| 0.00 | 3.31 | 0.00 | 1.76 | 11.65 | 258.63 | -11.02 | 30.37 | 0.3720 | -936.0 | -799.3 | |
| 0.00 | 1.48 | 0.00 | 0.80 | 13.01 | 258.48 | -11.17 | 28.91 | 0.3923 | -763.0 | -550.1 | |
| 0.00 | 1.65 | 0.00 | 0.89 | 12.60 | 258.47 | -11.19 | 29.46 | 0.3866 | -774.0 | -644.1 | |
| 0.00 | 0.87 | 0.00 | 0.47 | 13.02 | 258.23 | -11.42 | 29.44 | 0.3943 | -564.0 | -469.4 | |
| 0.00 | 3.91 | 0.00 | 2.09 | 11.60 | 258.23 | -11.42 | 31.35 | 0.3746 | -757.0 | -715.4 | |
| 0.00 | 1.04 | 0.00 | 0.56 | 11.42 | 257.86 | -11.79 | 32.42 | 0.3752 | -797.0 | -616.2 | |
| 0.00 | 1.65 | 0.00 | 0.88 | 11.33 | 257.59 | -12.07 | 33.15 | 0.3765 | -822.0 | -596.7 | |
| 0.00 | 0.61 | 0.00 | 0.33 | 14.64 | 257.40 | -12.26 | 29.17 | 0.4232 | -642.0 | -517.9 | |
| 0.00 | 1.22 | 0.00 | 0.67 | 13.40 | 254.37 | -15.29 | 36.53 | 0.4327 | -726.0 | -573.8 | |
| 0.00 | 1.22 | 0.00 | 0.67 | 13.32 | 253.77 | -15.89 | 37.70 | 0.4374 | -687.0 | -542.1 | |
| 0.00 | 0.78 | 0.00 | 0.42 | 10.05 | 253.64 | -16.01 | 43.08 | 0.3994 | 812.0 | 668.9 | |
| 0.00 | 1.04 | 0.00 | 0.56 | 10.18 | 253.60 | -16.05 | 42.93 | 0.4013 | 808.0 | 628.8 | |
| 0.00 | 1.39 | 0.00 | 0.76 | 11.37 | 253.51 | -16.15 | 41.12 | 0.4164 | 732.0 | 625.7 | |
| 0.00 | 1.30 | 0.00 | 0.71 | 11.13 | 253.33 | -16.32 | 41.82 | 0.4154 | 759.0 | 620.1 | |
| 0.00 | 1.48 | 0.00 | 0.80 | 10.16 | 253.16 | -16.49 | 43.73 | 0.4060 | 661.0 | 508.4 | |
| 0.00 | 0.78 | 0.00 | 0.42 | 7.12 | 252.54 | -17.11 | 50.52 | 0.3800 | 773.0 | 536.4 | |
| 0.00 | 1.22 | 0.00 | 0.68 | 13.22 | 251.56 | -18.09 | 41.51 | 0.4581 | 794.0 | 673.5 | |
| 0.00 | 0.87 | 0.00 | 0.49 | 11.27 | 247.81 | -21.84 | 49.94 | 0.4787 | 622.0 | 456.3 | |
| 0.35 | 2.78 | 0.20 | 1.59 | 11.02 | 245.49 | -24.17 | 53.20 | 0.5039 | 989.8 | 772.7 | |
| 0.00 | 1.65 | 0.00 | 0.96 | 12.38 | 244.72 | -24.93 | 51.93 | 0.5251 | 635.0 | 490.9 | |
| 0.00 | 0.78 | 0.00 | 0.47 | 14.69 | 243.81 | -25.84 | 49.54 | 0.5563 | 617.0 | 585.3 | |
| 0.78 | 6.18 | 0.45 | 3.58 | 10.45 | 243.79 | -25.86 | 55.96 | 0.5197 | 998.4 | 780.5 | |
| 0.00 | 0.78 | 0.00 | 0.45 | 10.62 | 243.71 | -25.94 | 55.79 | 0.5220 | 292.0 | 510.4 | |
| 0.00 | 1.74 | 0.00 | 1.03 | 12.88 | 242.59 | -27.06 | 53.45 | 0.5543 | 603.0 | 356.9 | |
| 0.00 | 1.48 | 0.00 | 0.88 | 12.28 | 241.66 | -27.99 | 55.27 | 0.5602 | 729.0 | 607.9 | |
| 0.00 | 0.70 | 0.00 | 0.41 | 10.91 | 241.36 | -28.29 | 57.63 | 0.5532 | 658.0 | 561.9 | |
| 0.00 | 1.48 | 0.00 | 0.89 | 11.77 | 240.75 | -28.91 | 56.89 | 0.5672 | 748.0 | 648.8 | |
| 0.00 | 2.35 | 0.00 | 1.41 | 11.69 | 240.48 | -29.18 | 57.26 | 0.5698 | 663.0 | 615.7 | |
| 0.00 | 1.83 | 0.00 | 1.11 | 11.88 | 240.00 | -29.66 | 57.40 | 0.5769 | 419.0 | 430.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
