SDO HMI 2014-03-18 06:00:30 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 28.99 | 139.07 | 16.59 | 80.68 | -10.98 | 296.55 | 31.28 | 260.32 | 0.5186 | -222.6 | -94.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-18 06:00:30 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.92 | 0.00 | 1.33 | -9.98 | 310.06 | 44.79 | 262.97 | 0.7015 | 500.0 | 474.1 | |
| 0.00 | 1.57 | 0.00 | 1.08 | -9.66 | 309.87 | 44.61 | 263.42 | 0.6992 | 700.0 | 601.1 | |
| 0.00 | 1.74 | 0.00 | 1.15 | -8.31 | 307.01 | 41.75 | 265.47 | 0.6633 | 744.0 | 581.0 | |
| 0.44 | 1.31 | 0.29 | 0.86 | -11.95 | 307.06 | 41.80 | 259.98 | 0.6645 | 698.6 | 614.8 | |
| 0.00 | 1.22 | 0.00 | 0.79 | -10.60 | 305.85 | 40.59 | 261.97 | 0.6482 | 708.0 | 677.4 | |
| 0.00 | 1.92 | 0.00 | 1.23 | -11.94 | 305.24 | 39.97 | 259.85 | 0.6408 | 78.0 | 139.0 | |
| 0.00 | 1.04 | 0.00 | 0.67 | -10.97 | 304.91 | 39.65 | 261.35 | 0.6360 | 677.0 | 553.1 | |
| 0.00 | 0.78 | 0.00 | 0.48 | -5.99 | 302.14 | 36.87 | 269.50 | 0.5990 | 597.0 | 479.4 | |
| 0.00 | 0.78 | 0.00 | 0.48 | -4.11 | 301.68 | 36.42 | 272.73 | 0.5950 | 564.0 | 488.1 | |
| 0.00 | 2.44 | 0.00 | 1.44 | -8.40 | 298.41 | 33.14 | 265.50 | 0.5447 | -796.0 | -598.6 | |
| 0.00 | 5.57 | 0.00 | 3.27 | -8.43 | 297.94 | 32.68 | 265.44 | 0.5379 | -828.0 | -742.1 | |
| 0.00 | 0.96 | 0.00 | 0.56 | -10.89 | 297.96 | 32.69 | 260.86 | 0.5393 | 627.0 | 557.0 | |
| 0.35 | 1.83 | 0.20 | 1.07 | -10.55 | 297.73 | 32.47 | 261.48 | 0.5358 | 772.5 | 650.6 | |
| 0.00 | 0.78 | 0.00 | 0.46 | -10.43 | 297.65 | 32.39 | 261.69 | 0.5345 | 706.0 | 597.4 | |
| 0.00 | 2.26 | 0.00 | 1.32 | -10.70 | 297.61 | 32.35 | 261.17 | 0.5341 | 632.0 | 614.5 | |
| 1.83 | 15.50 | 1.06 | 8.98 | -10.77 | 296.97 | 31.71 | 260.96 | 0.5249 | 845.8 | 624.9 | |
| 0.52 | -16.00 | 0.30 | -16.00 | -10.57 | 296.84 | 31.58 | 261.33 | 0.5228 | 787.3 | 999999 | |
| 1.31 | 21.25 | 0.76 | 12.32 | -11.62 | 296.82 | 31.56 | 259.31 | 0.5238 | 916.0 | 597.2 | |
| 1.65 | -18.00 | 0.96 | -18.00 | -11.83 | 296.85 | 31.59 | 258.92 | 0.5245 | 961.4 | 999999 | |
| 1.74 | -18.00 | 1.01 | -18.00 | -11.48 | 296.73 | 31.47 | 259.57 | 0.5223 | 800.2 | 999999 | |
| 0.00 | 1.65 | 0.00 | 0.96 | -9.96 | 296.56 | 31.30 | 262.48 | 0.5182 | 809.0 | 647.7 | |
| 0.87 | -16.00 | 0.50 | -16.00 | -10.53 | 296.52 | 31.25 | 261.36 | 0.5180 | 847.0 | 999999 | |
| 0.87 | -16.00 | 0.50 | -16.00 | -10.30 | 296.45 | 31.19 | 261.81 | 0.5169 | 778.2 | 999999 | |
| 0.78 | -18.00 | 0.45 | -18.00 | -11.44 | 296.44 | 31.18 | 259.60 | 0.5180 | 792.7 | 999999 | |
| 0.00 | 2.53 | 0.00 | 1.45 | -11.46 | 295.63 | 30.37 | 259.42 | 0.5061 | -355.0 | -263.7 | |
| 0.00 | 0.96 | 0.00 | 0.55 | -13.37 | 295.80 | 30.54 | 255.71 | 0.5122 | -707.0 | -659.3 | |
| 0.00 | 0.70 | 0.00 | 0.40 | -12.97 | 295.53 | 30.27 | 256.43 | 0.5074 | -526.0 | -429.5 | |
| 0.00 | 2.53 | 0.00 | 1.44 | -10.80 | 295.13 | 29.87 | 260.65 | 0.4978 | -664.0 | -484.1 | |
| 0.00 | 1.13 | 0.00 | 0.64 | -10.22 | 294.83 | 29.56 | 261.78 | 0.4926 | -279.0 | -194.3 | |
| 4.96 | 9.32 | 2.83 | 5.31 | -11.77 | 294.89 | 29.63 | 258.64 | 0.4956 | -809.5 | -568.2 | |
| 0.00 | 1.83 | 0.00 | 1.04 | -11.36 | 294.74 | 29.47 | 259.44 | 0.4927 | -790.0 | -644.1 | |
| 9.14 | 18.29 | 5.18 | 10.37 | -10.53 | 294.54 | 29.28 | 261.10 | 0.4887 | -795.3 | -671.7 | |
| 0.78 | 3.48 | 0.44 | 1.98 | -11.50 | 294.44 | 29.18 | 259.10 | 0.4885 | -878.0 | -732.7 | |
| 0.00 | 1.04 | 0.00 | 0.60 | -15.24 | 294.83 | 29.57 | 251.74 | 0.5034 | -564.0 | -417.9 | |
| 0.00 | 1.22 | 0.00 | 0.70 | -15.03 | 294.76 | 29.50 | 252.11 | 0.5017 | -485.0 | -557.3 | |
| 0.00 | 1.13 | 0.00 | 0.65 | -14.59 | 294.66 | 29.40 | 252.95 | 0.4989 | -697.0 | -632.7 | |
| 0.00 | 1.83 | 0.00 | 1.04 | -14.80 | 294.69 | 29.43 | 252.55 | 0.5000 | -570.0 | -589.3 | |
| 0.00 | 1.04 | 0.00 | 0.59 | -10.98 | 294.03 | 28.77 | 260.08 | 0.4816 | -850.0 | -696.2 | |
| 0.00 | 0.87 | 0.00 | 0.49 | -11.22 | 294.03 | 28.76 | 259.58 | 0.4819 | -842.0 | -642.9 | |
| 0.00 | 2.79 | 0.00 | 1.58 | -12.48 | 294.13 | 28.87 | 257.02 | 0.4858 | -642.0 | -477.7 | |
| 0.00 | 1.31 | 0.00 | 0.73 | -8.81 | 293.76 | 28.50 | 264.60 | 0.4756 | -673.0 | -599.2 | |
| 3.40 | 5.57 | 1.91 | 3.14 | -10.57 | 293.82 | 28.56 | 260.89 | 0.4779 | -1026.5 | -853.4 | |
| 0.00 | 0.87 | 0.00 | 0.49 | -8.52 | 293.60 | 28.34 | 265.20 | 0.4730 | -798.0 | -678.6 | |
| 0.00 | 1.13 | 0.00 | 0.64 | -8.34 | 293.59 | 28.32 | 265.58 | 0.4728 | -585.0 | -487.8 | |
| 0.35 | 1.39 | 0.20 | 0.78 | -10.34 | 293.73 | 28.46 | 261.37 | 0.4762 | -1016.2 | -811.7 | |
| 0.00 | 0.44 | 0.00 | 0.25 | -14.73 | 294.26 | 28.99 | 252.51 | 0.4935 | -646.0 | -561.8 | |
| 0.00 | 0.96 | 0.00 | 0.55 | -15.45 | 294.33 | 29.07 | 251.11 | 0.4969 | -667.0 | -585.4 | |
| 0.00 | 1.13 | 0.00 | 0.64 | -10.13 | 293.67 | 28.41 | 261.80 | 0.4751 | -886.0 | -663.5 | |
| 0.00 | 5.14 | 0.00 | 2.88 | -8.89 | 293.42 | 28.16 | 264.41 | 0.4705 | -540.0 | -632.5 | |
| 0.00 | 0.96 | 0.00 | 0.54 | -14.71 | 293.55 | 28.29 | 252.26 | 0.4832 | -763.0 | -587.1 | |
| 0.00 | 0.61 | 0.00 | 0.35 | -15.85 | 293.68 | 28.42 | 250.02 | 0.4891 | -624.0 | -551.1 | |
| 0.00 | 0.96 | 0.00 | 0.54 | -15.42 | 293.34 | 28.07 | 250.72 | 0.4826 | -775.0 | -668.6 | |
| 0.00 | 1.22 | 0.00 | 0.69 | -15.86 | 293.05 | 27.79 | 249.69 | 0.4801 | -553.0 | -591.4 | |
| 0.00 | 1.13 | 0.00 | 0.62 | -12.90 | 290.71 | 25.44 | 254.93 | 0.4355 | -649.0 | -567.8 | |
| 0.00 | 1.04 | 0.00 | 0.56 | -14.37 | 287.04 | 21.77 | 249.40 | 0.3855 | -803.0 | -527.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
