SDO HMI 2014-03-20 05:00:30 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 46.98 | 177.05 | 74.06 | 271.31 | -12.93 | 167.25 | -72.19 | 101.33 | 0.9472 | 205.8 | 26.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-20 05:00:30 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 14.12 | 95.28 | 19.44 | 131.94 | -14.64 | 169.46 | -69.98 | 103.01 | 0.9346 | 603.3 | 197.1 | |
| 4.97 | -1.00 | 7.09 | -1.00 | -14.51 | 168.62 | -70.82 | 102.91 | 0.9396 | -213.7 | 999999 | |
| 0.00 | 1.48 | 0.00 | 2.17 | -15.16 | 168.11 | -71.33 | 103.62 | 0.9424 | 179.0 | 37.5 | |
| 11.77 | 32.95 | 18.99 | 53.37 | -11.39 | 166.34 | -73.10 | 99.74 | 0.9531 | 72.1 | -222.3 | |
| 1.39 | 14.47 | 2.46 | 25.75 | -12.50 | 164.60 | -74.84 | 101.02 | 0.9613 | -471.4 | -378.3 | |
| 0.00 | 1.83 | 0.00 | 3.16 | -11.71 | 165.12 | -74.33 | 100.15 | 0.9591 | -343.0 | -283.1 | |
| 6.10 | 13.08 | 10.47 | 22.59 | -11.05 | 165.25 | -74.19 | 99.46 | 0.9586 | 98.0 | -228.9 | |
| 0.00 | 1.22 | 0.00 | 2.26 | -12.54 | 163.84 | -75.60 | 101.11 | 0.9648 | -452.0 | -365.6 | |
| 8.63 | 16.74 | 15.61 | 30.07 | -10.12 | 164.38 | -75.07 | 98.57 | 0.9631 | 322.2 | 362.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
