SDO HMI 2014-03-22 20:00:30 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 44.22 | 268.68 | 44.60 | 268.54 | 11.88 | 262.44 | 57.60 | 288.00 | 0.8702 | -541.3 | -234.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-22 20:00:30 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.78 | 0.00 | 0.96 | 12.83 | 268.38 | 63.54 | 287.38 | 0.9164 | -192.0 | -180.4 | |
| 0.00 | 1.22 | 0.00 | 1.36 | 13.17 | 265.49 | 60.65 | 288.51 | 0.8969 | 331.0 | 304.5 | |
| 44.22 | 257.62 | 44.60 | 259.49 | 11.85 | 262.75 | 57.91 | 287.84 | 0.8731 | -742.8 | -258.2 | |
| 0.00 | 0.96 | 0.00 | 0.84 | 11.07 | 257.61 | 52.77 | 288.58 | 0.8265 | -465.0 | -349.3 | |
| 0.00 | 1.48 | 0.00 | 1.10 | 12.88 | 249.14 | 44.30 | 294.20 | 0.7488 | 627.0 | 512.6 | |
| 0.00 | 0.87 | 0.00 | 0.64 | 11.90 | 248.29 | 43.45 | 293.37 | 0.7355 | 508.0 | 400.7 | |
| 0.00 | 0.52 | 0.00 | 0.38 | 12.68 | 248.29 | 43.45 | 294.36 | 0.7389 | 436.0 | 416.7 | |
| 0.00 | 1.05 | 0.00 | 0.77 | 13.16 | 248.31 | 43.47 | 294.95 | 0.7412 | 543.0 | 505.4 | |
| 0.00 | 2.44 | 0.00 | 1.78 | 12.96 | 247.80 | 42.96 | 294.96 | 0.7349 | 692.0 | 649.8 | |
| 0.00 | 0.96 | 0.00 | 0.70 | 13.52 | 247.34 | 42.50 | 295.90 | 0.7325 | 473.0 | 485.1 | |
| 0.00 | 0.78 | 0.00 | 0.52 | 12.00 | 242.54 | 37.70 | 296.65 | 0.6716 | 619.0 | 528.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
