SDO HMI 2014-03-23 12:00:30 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 39.30 | 175.03 | 34.67 | 152.59 | 10.21 | 143.21 | -52.84 | 72.45 | 0.8242 | -204.2 | -109.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-23 12:00:30 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 18.51 | 116.81 | 15.52 | 98.18 | 10.07 | 144.82 | -51.23 | 72.10 | 0.8090 | -852.6 | -286.8 | |
| 3.93 | -1.00 | 3.33 | -1.00 | 10.36 | 144.47 | -51.59 | 71.89 | 0.8133 | -425.0 | 999999 | |
| 0.79 | -1.00 | 0.67 | -1.00 | 10.34 | 144.03 | -52.03 | 72.06 | 0.8174 | -193.0 | 999999 | |
| 0.00 | 1.22 | 0.00 | 1.06 | 10.60 | 143.61 | -52.44 | 71.89 | 0.8220 | -292.0 | -196.9 | |
| 0.00 | 1.31 | 0.00 | 1.11 | 8.95 | 143.98 | -52.08 | 73.72 | 0.8140 | -354.0 | -259.3 | |
| 2.71 | 9.25 | 2.36 | 8.07 | 10.02 | 143.15 | -52.91 | 72.72 | 0.8249 | -488.1 | -156.2 | |
| 0.00 | 0.96 | 0.00 | 0.87 | 10.86 | 141.91 | -54.15 | 72.15 | 0.8385 | -412.0 | -312.0 | |
| 0.00 | 0.96 | 0.00 | 0.86 | 9.84 | 142.17 | -53.89 | 73.24 | 0.8335 | 134.0 | 151.1 | |
| 0.00 | 2.44 | 0.00 | 2.18 | 9.66 | 142.10 | -53.96 | 73.47 | 0.8336 | 286.0 | 353.6 | |
| 0.61 | 1.22 | 0.55 | 1.10 | 9.67 | 141.68 | -54.38 | 73.59 | 0.8375 | 565.6 | 558.1 | |
| 0.00 | 0.61 | 0.00 | 0.56 | 9.35 | 141.23 | -54.83 | 74.10 | 0.8408 | 418.0 | 397.0 | |
| 0.00 | 1.57 | 0.00 | 1.46 | 10.74 | 140.67 | -55.39 | 72.67 | 0.8492 | 702.0 | 571.5 | |
| 4.37 | 23.66 | 4.13 | 22.53 | 10.89 | 140.14 | -55.92 | 72.67 | 0.8542 | 696.5 | 492.6 | |
| 0.87 | -13.00 | 0.84 | -13.00 | 11.14 | 139.79 | -56.27 | 72.49 | 0.8578 | 470.9 | 999999 | |
| 3.67 | -13.00 | 3.52 | -13.00 | 10.95 | 139.57 | -56.49 | 72.77 | 0.8592 | 534.3 | 999999 | |
| 0.00 | 0.79 | 0.00 | 0.74 | 9.55 | 139.89 | -56.17 | 74.26 | 0.8532 | 543.0 | 501.6 | |
| 0.00 | 0.44 | 0.00 | 0.42 | 10.57 | 139.62 | -56.44 | 73.18 | 0.8578 | 389.0 | 368.0 | |
| 0.00 | 0.61 | 0.00 | 0.59 | 10.80 | 139.16 | -56.90 | 73.05 | 0.8622 | 320.0 | 298.1 | |
| 1.05 | 5.41 | 1.03 | 5.31 | 11.09 | 138.79 | -57.27 | 72.84 | 0.8660 | 194.4 | 228.3 | |
| 1.13 | 4.28 | 1.09 | 4.13 | 9.47 | 139.14 | -56.92 | 74.56 | 0.8595 | 580.8 | 413.6 | |
| 0.00 | 0.35 | 0.00 | 0.34 | 8.82 | 138.28 | -57.78 | 75.53 | 0.8654 | -552.0 | -509.0 | |
| 1.66 | 3.14 | 1.63 | 3.08 | 8.55 | 138.23 | -57.83 | 75.85 | 0.8653 | -537.1 | -400.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
