SDO HMI 2014-03-25 19:00:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 22.37 | 77.57 | 12.65 | 43.94 | 3.27 | 138.71 | -27.12 | 70.22 | 0.4854 | -106.6 | 62.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-25 19:00:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.83 | 0.00 | 1.02 | 3.76 | 141.07 | -24.76 | 67.48 | 0.4543 | -980.0 | -801.9 | |
| 1.66 | 26.21 | 0.92 | 14.60 | 3.40 | 140.92 | -24.91 | 68.34 | 0.4543 | -1061.0 | -588.7 | |
| 4.02 | -2.00 | 2.23 | -2.00 | 3.23 | 140.73 | -25.11 | 68.85 | 0.4561 | -1040.7 | 999999 | |
| 2.18 | 4.28 | 1.22 | 2.39 | 3.91 | 140.51 | -25.33 | 67.66 | 0.4633 | -871.0 | -627.0 | |
| 3.23 | -2.00 | 1.80 | -2.00 | 3.43 | 140.46 | -25.38 | 68.68 | 0.4612 | -854.3 | 999999 | |
| 0.00 | 1.22 | 0.00 | 0.69 | 4.89 | 140.37 | -25.46 | 65.85 | 0.4713 | -700.0 | -605.6 | |
| 1.49 | -2.00 | 0.83 | -2.00 | 3.19 | 140.36 | -25.47 | 69.23 | 0.4611 | -729.9 | 999999 | |
| 0.00 | 0.52 | 0.00 | 0.29 | 3.07 | 139.77 | -26.07 | 69.94 | 0.4691 | -464.0 | -440.3 | |
| 0.00 | 1.22 | 0.00 | 0.69 | 3.81 | 139.68 | -26.15 | 68.56 | 0.4745 | -635.0 | -384.8 | |
| 0.00 | 1.31 | 0.00 | 0.74 | 3.99 | 139.61 | -26.23 | 68.25 | 0.4766 | -662.0 | -532.9 | |
| 0.00 | 1.40 | 0.00 | 0.79 | 5.04 | 138.86 | -26.97 | 66.86 | 0.4934 | -874.0 | -726.2 | |
| 0.00 | 1.14 | 0.00 | 0.64 | 3.41 | 138.68 | -27.15 | 70.09 | 0.4864 | 277.0 | 161.0 | |
| 0.00 | 0.61 | 0.00 | 0.35 | 5.60 | 138.12 | -27.71 | 66.42 | 0.5070 | -510.0 | -513.7 | |
| 1.92 | 22.89 | 1.09 | 13.04 | 3.53 | 138.11 | -27.73 | 70.27 | 0.4953 | 1106.0 | 702.3 | |
| 1.14 | -14.00 | 0.65 | -14.00 | 3.72 | 138.03 | -27.80 | 69.97 | 0.4974 | 863.3 | 999999 | |
| 1.40 | -14.00 | 0.80 | -14.00 | 3.27 | 137.94 | -27.89 | 70.89 | 0.4963 | 963.3 | 999999 | |
| 0.00 | 0.79 | 0.00 | 0.45 | 2.94 | 137.78 | -28.05 | 71.61 | 0.4969 | 676.0 | 484.4 | |
| 0.00 | 1.22 | 0.00 | 0.71 | 1.85 | 136.27 | -29.56 | 74.60 | 0.5135 | 746.0 | 599.3 | |
| 0.00 | 1.31 | 0.00 | 0.76 | 2.51 | 135.88 | -29.96 | 73.61 | 0.5221 | 675.0 | 484.9 | |
| 0.00 | 1.14 | 0.00 | 0.66 | 2.39 | 135.43 | -30.40 | 74.09 | 0.5279 | 894.0 | 692.6 | |
| 5.33 | 10.48 | 3.11 | 6.12 | 2.01 | 135.12 | -30.71 | 74.93 | 0.5306 | 930.8 | 569.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
