SDO HMI 2014-03-26 22:00:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 68.81 | 318.76 | 36.11 | 166.80 | 10.18 | 143.72 | -7.27 | 22.39 | 0.3215 | -209.6 | -210.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-26 22:00:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 32.35 | 177.31 | 16.78 | 92.00 | 9.84 | 146.22 | -4.77 | 15.98 | 0.2989 | -1312.2 | -439.9 | |
| 0.00 | 5.77 | 0.00 | 3.02 | 10.88 | 145.44 | -5.55 | 17.38 | 0.3193 | 51.0 | 2.1 | |
| 0.00 | 0.87 | 0.00 | 0.46 | 10.57 | 145.38 | -5.61 | 17.85 | 0.3146 | -924.0 | -778.0 | |
| 0.00 | 1.22 | 0.00 | 0.64 | 10.95 | 145.01 | -5.98 | 18.57 | 0.3226 | -462.0 | -352.5 | |
| 0.00 | 2.89 | 0.00 | 1.51 | 10.60 | 144.92 | -6.06 | 19.17 | 0.3176 | -813.0 | -756.1 | |
| 0.79 | 1.92 | 0.41 | 0.99 | 7.93 | 144.79 | -6.20 | 22.87 | 0.2767 | -1066.9 | -872.8 | |
| 0.00 | 1.05 | 0.00 | 0.55 | 10.33 | 144.65 | -6.33 | 20.27 | 0.3148 | -982.0 | -862.1 | |
| 0.00 | 0.87 | 0.00 | 0.46 | 10.64 | 144.56 | -6.43 | 20.20 | 0.3202 | -819.0 | -767.5 | |
| 0.00 | 2.27 | 0.00 | 1.19 | 10.83 | 144.43 | -6.56 | 20.36 | 0.3239 | -711.0 | -571.4 | |
| 1.31 | 9.18 | 0.68 | 4.79 | 10.24 | 144.29 | -6.70 | 21.44 | 0.3155 | -1064.8 | -892.0 | |
| 1.40 | -10.00 | 0.73 | -10.00 | 10.46 | 144.22 | -6.77 | 21.37 | 0.3193 | -1048.0 | 999999 | |
| 0.00 | 1.05 | 0.00 | 0.55 | 9.90 | 143.75 | -7.24 | 23.43 | 0.3138 | -830.0 | -613.0 | |
| 0.00 | 13.90 | 0.00 | 7.28 | 10.65 | 143.70 | -7.29 | 22.63 | 0.3256 | -1031.0 | -789.9 | |
| 0.35 | 1.22 | 0.18 | 0.64 | 10.06 | 143.50 | -7.49 | 23.93 | 0.3179 | -903.5 | -783.9 | |
| 2.62 | 4.02 | 1.37 | 2.10 | 9.94 | 143.22 | -7.77 | 24.86 | 0.3180 | -1062.7 | -820.5 | |
| 0.00 | 2.97 | 0.00 | 1.56 | 10.48 | 143.09 | -7.90 | 24.54 | 0.3269 | -711.0 | -704.9 | |
| 0.00 | 1.22 | 0.00 | 0.65 | 10.14 | 139.71 | -11.28 | 33.64 | 0.3491 | 831.0 | 690.4 | |
| 2.10 | 5.16 | 1.11 | 2.73 | 10.59 | 139.60 | -11.39 | 33.20 | 0.3561 | 893.5 | 777.8 | |
| 0.70 | 2.36 | 0.37 | 1.25 | 10.27 | 139.55 | -11.44 | 33.81 | 0.3523 | 1034.8 | 817.8 | |
| 0.00 | 2.89 | 0.00 | 1.52 | 9.40 | 139.55 | -11.44 | 35.26 | 0.3406 | 687.0 | 572.1 | |
| 20.28 | 28.77 | 10.79 | 15.30 | 10.91 | 139.00 | -11.99 | 34.05 | 0.3660 | 1054.7 | 646.1 | |
| 0.00 | 7.52 | 0.00 | 3.97 | 9.32 | 138.96 | -12.03 | 36.76 | 0.3452 | 1195.0 | 855.3 | |
| 0.00 | 7.96 | 0.00 | 4.22 | 10.29 | 138.90 | -12.09 | 35.27 | 0.3586 | 803.0 | 771.1 | |
| 0.00 | 1.40 | 0.00 | 0.74 | 9.67 | 138.67 | -12.32 | 36.81 | 0.3526 | 731.0 | 496.4 | |
| 6.91 | 33.14 | 3.69 | 17.69 | 11.06 | 138.37 | -12.62 | 35.20 | 0.3737 | 936.0 | 474.9 | |
| 0.00 | 0.87 | 0.00 | 0.47 | 12.46 | 136.88 | -14.10 | 36.08 | 0.4058 | 754.0 | 573.5 | |
| 0.00 | 0.96 | 0.00 | 0.52 | 12.18 | 136.81 | -14.18 | 36.66 | 0.4029 | 758.0 | 616.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
