SDO HMI 2014-03-28 16:00:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 91.63 | 529.61 | 63.78 | 365.10 | -13.24 | 172.11 | 44.19 | 257.80 | 0.6955 | 444.2 | 269.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-28 16:00:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.05 | 0.00 | 0.75 | -10.61 | 174.37 | 46.44 | 261.72 | 0.7221 | 438.0 | 333.4 | |
| 0.00 | 1.05 | 0.00 | 0.75 | -11.62 | 174.58 | 46.65 | 260.33 | 0.7249 | -205.0 | -188.0 | |
| 0.00 | 1.40 | 0.00 | 1.00 | -11.07 | 174.24 | 46.32 | 261.07 | 0.7207 | 226.0 | 169.9 | |
| 3.41 | 10.33 | 2.41 | 7.30 | -10.89 | 173.89 | 45.97 | 261.32 | 0.7165 | 744.5 | 466.8 | |
| 19.34 | 78.94 | 13.71 | 55.93 | -11.91 | 173.97 | 46.05 | 259.89 | 0.7179 | 950.4 | 440.1 | |
| 2.19 | -5.00 | 1.54 | -5.00 | -11.97 | 173.59 | 45.67 | 259.78 | 0.7133 | 926.4 | 999999 | |
| 2.80 | 11.99 | 1.96 | 8.37 | -10.71 | 173.12 | 45.19 | 261.55 | 0.7071 | 806.8 | 532.6 | |
| 0.00 | 0.26 | 0.00 | 0.18 | -10.31 | 172.83 | 44.90 | 262.11 | 0.7035 | 617.0 | 520.3 | |
| 0.00 | 3.94 | 0.00 | 2.72 | -10.55 | 172.57 | 44.64 | 261.77 | 0.7003 | 857.0 | 601.6 | |
| 0.00 | 1.93 | 0.00 | 1.34 | -12.09 | 172.87 | 44.95 | 259.57 | 0.7047 | 723.0 | 602.2 | |
| 48.66 | 310.60 | 34.09 | 217.75 | -13.89 | 173.16 | 45.23 | 257.05 | 0.7095 | 1206.8 | 350.0 | |
| 0.00 | 1.31 | 0.00 | 0.91 | -11.91 | 172.57 | 44.65 | 259.82 | 0.7010 | 850.0 | 772.3 | |
| 2.01 | 6.30 | 1.39 | 4.35 | -12.15 | 172.50 | 44.57 | 259.46 | 0.7002 | 887.8 | 755.5 | |
| 0.00 | 1.05 | 0.00 | 0.72 | -10.67 | 172.12 | 44.20 | 261.57 | 0.6949 | 666.0 | 556.9 | |
| 0.00 | 1.23 | 0.00 | 0.84 | -11.96 | 172.33 | 44.40 | 259.73 | 0.6980 | 815.0 | 637.4 | |
| 0.00 | 0.61 | 0.00 | 0.42 | -12.47 | 172.35 | 44.42 | 259.00 | 0.6986 | 613.0 | 517.4 | |
| 0.79 | -13.00 | 0.54 | -13.00 | -12.23 | 172.25 | 44.33 | 259.33 | 0.6973 | 832.9 | 999999 | |
| 0.00 | 1.84 | 0.00 | 1.25 | -10.01 | 171.66 | 43.74 | 262.51 | 0.6891 | -480.0 | -376.8 | |
| 0.00 | 4.03 | 0.00 | 2.74 | -10.06 | 171.50 | 43.58 | 262.45 | 0.6870 | -800.0 | -533.4 | |
| 0.44 | 2.89 | 0.30 | 1.96 | -12.86 | 171.24 | 43.31 | 258.34 | 0.6852 | -377.8 | -290.1 | |
| 0.00 | 1.58 | 0.00 | 1.08 | -15.26 | 171.64 | 43.71 | 254.90 | 0.6928 | 692.0 | 582.2 | |
| 0.00 | 1.23 | 0.00 | 0.83 | -12.79 | 171.01 | 43.09 | 258.42 | 0.6823 | -482.0 | -261.9 | |
| 5.34 | 14.62 | 3.60 | 9.83 | -12.28 | 170.86 | 42.94 | 259.15 | 0.6801 | 870.4 | 637.9 | |
| 0.00 | 0.96 | 0.00 | 0.66 | -16.86 | 171.60 | 43.67 | 252.60 | 0.6949 | 551.0 | 531.0 | |
| 0.00 | 0.53 | 0.00 | 0.35 | -12.71 | 170.45 | 42.52 | 258.48 | 0.6752 | -193.0 | -181.3 | |
| 0.00 | 2.10 | 0.00 | 1.38 | -13.12 | 169.37 | 41.45 | 257.74 | 0.6620 | -519.0 | -341.5 | |
| 0.00 | 1.84 | 0.00 | 1.20 | -13.07 | 168.91 | 40.99 | 257.77 | 0.6561 | -702.0 | -491.6 | |
| 0.00 | 1.84 | 0.00 | 1.20 | -12.63 | 168.62 | 40.70 | 258.39 | 0.6519 | 830.0 | 706.4 | |
| 0.00 | 1.14 | 0.00 | 0.74 | -12.68 | 168.39 | 40.47 | 258.29 | 0.6489 | 721.0 | 516.6 | |
| 0.00 | 0.61 | 0.00 | 0.39 | -12.48 | 167.83 | 39.90 | 258.54 | 0.6414 | 720.0 | 634.9 | |
| 1.14 | 20.39 | 0.73 | 13.07 | -13.69 | 167.86 | 39.94 | 256.66 | 0.6433 | -360.8 | -324.3 | |
| 1.31 | -31.00 | 0.84 | -31.00 | -13.72 | 167.50 | 39.58 | 256.56 | 0.6387 | -445.8 | 999999 | |
| 3.59 | -31.00 | 2.29 | -31.00 | -13.59 | 167.16 | 39.24 | 256.70 | 0.6340 | -735.0 | 999999 | |
| 0.00 | 0.96 | 0.00 | 0.62 | -14.58 | 167.24 | 39.32 | 255.16 | 0.6367 | -562.0 | -451.7 | |
| 0.00 | 0.96 | 0.00 | 0.61 | -12.97 | 166.49 | 38.56 | 257.58 | 0.6243 | 697.0 | 526.5 | |
| 0.00 | 2.01 | 0.00 | 1.27 | -13.96 | 166.24 | 38.32 | 255.96 | 0.6225 | -712.0 | -520.6 | |
| 0.00 | 0.79 | 0.00 | 0.50 | -14.24 | 166.14 | 38.22 | 255.49 | 0.6217 | -661.0 | -545.9 | |
| 0.00 | 1.05 | 0.00 | 0.66 | -12.42 | 165.65 | 37.73 | 258.34 | 0.6124 | 722.0 | 600.2 | |
| 0.00 | 0.96 | 0.00 | 0.60 | -12.56 | 165.44 | 37.52 | 258.09 | 0.6097 | 626.0 | 438.5 | |
| 0.61 | 1.31 | 0.38 | 0.82 | -13.02 | 165.29 | 37.36 | 257.30 | 0.6083 | -545.4 | -425.5 | |
| 0.00 | 1.40 | 0.00 | 0.85 | -12.21 | 162.98 | 35.06 | 258.28 | 0.5756 | -773.0 | -596.5 | |
| 0.00 | 1.40 | 0.00 | 0.85 | -12.90 | 163.09 | 35.17 | 257.11 | 0.5781 | -778.0 | -607.4 | |
| 0.00 | 1.58 | 0.00 | 0.95 | -12.97 | 162.46 | 34.54 | 256.86 | 0.5696 | -806.0 | -638.6 | |
| 0.00 | 1.75 | 0.00 | 1.05 | -13.66 | 161.98 | 34.06 | 255.53 | 0.5642 | -791.0 | -673.2 | |
| 0.00 | 0.96 | 0.00 | 0.58 | -15.80 | 161.87 | 33.95 | 251.77 | 0.5679 | -564.0 | -495.1 | |
| 0.00 | 1.14 | 0.00 | 0.68 | -15.90 | 161.74 | 33.82 | 251.55 | 0.5664 | -572.0 | -474.1 | |
| 0.00 | 0.96 | 0.00 | 0.57 | -13.41 | 161.27 | 33.35 | 255.81 | 0.5537 | -666.0 | -476.4 | |
| 0.00 | 1.93 | 0.00 | 1.14 | -13.12 | 161.04 | 33.12 | 256.27 | 0.5499 | -819.0 | -680.9 | |
| 0.00 | 1.23 | 0.00 | 0.73 | -13.36 | 161.08 | 33.16 | 255.85 | 0.5509 | -814.0 | -632.5 | |
| 0.00 | 1.31 | 0.00 | 0.78 | -15.38 | 161.20 | 33.27 | 252.26 | 0.5575 | -890.0 | -666.9 | |
| 0.00 | 2.10 | 0.00 | 1.24 | -14.17 | 160.73 | 32.81 | 254.29 | 0.5478 | -818.0 | -603.6 | |
| 0.00 | 0.79 | 0.00 | 0.46 | -13.15 | 159.95 | 32.03 | 255.93 | 0.5345 | -793.0 | -706.8 | |
| 0.00 | 2.98 | 0.00 | 1.76 | -15.71 | 160.29 | 32.37 | 251.36 | 0.5460 | -642.0 | -627.8 | |
| 0.00 | 2.19 | 0.00 | 1.28 | -13.46 | 159.85 | 31.93 | 255.33 | 0.5338 | -752.0 | -680.9 | |
| 0.00 | 1.75 | 0.00 | 1.02 | -13.24 | 159.57 | 31.64 | 255.67 | 0.5292 | -876.0 | -762.4 | |
| 0.00 | 2.54 | 0.00 | 1.48 | -14.14 | 159.63 | 31.71 | 254.00 | 0.5323 | -897.0 | -759.2 | |
| 0.00 | 1.58 | 0.00 | 0.92 | -14.71 | 159.72 | 31.80 | 252.97 | 0.5351 | -731.0 | -558.7 | |
| 0.00 | 1.49 | 0.00 | 0.87 | -14.90 | 159.10 | 31.17 | 252.40 | 0.5269 | -721.0 | -573.2 | |
| 0.00 | 1.31 | 0.00 | 0.75 | -11.14 | 157.80 | 29.88 | 259.30 | 0.4994 | -657.0 | -516.4 | |
| 0.00 | 2.10 | 0.00 | 1.20 | -10.61 | 157.60 | 29.68 | 260.33 | 0.4957 | -764.0 | -607.8 | |
| 0.00 | 1.49 | 0.00 | 0.85 | -13.97 | 157.95 | 30.02 | 253.76 | 0.5078 | -608.0 | -448.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
