SDO HMI 2014-03-29 08:00:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 78.08 | 429.93 | 66.03 | 357.56 | -13.26 | 172.89 | 53.77 | 258.38 | 0.8028 | 445.4 | 230.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-29 08:00:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.61 | 0.00 | 0.54 | -11.30 | 175.63 | 56.51 | 260.86 | 0.8305 | 260.0 | 235.3 | |
| 0.00 | 0.96 | 0.00 | 0.84 | -10.86 | 175.17 | 56.05 | 261.40 | 0.8261 | 218.0 | 169.2 | |
| 0.00 | 0.88 | 0.00 | 0.76 | -10.93 | 174.97 | 55.85 | 261.31 | 0.8242 | 424.0 | 339.1 | |
| 0.00 | 3.59 | 0.00 | 3.09 | -11.01 | 174.50 | 55.38 | 261.22 | 0.8196 | 720.0 | 524.0 | |
| 19.19 | 95.35 | 16.52 | 82.01 | -11.92 | 174.55 | 55.43 | 260.11 | 0.8200 | 688.1 | 183.1 | |
| 0.53 | -5.00 | 0.45 | -5.00 | -12.85 | 174.69 | 55.56 | 258.97 | 0.8214 | -104.5 | 999999 | |
| 1.31 | 6.48 | 1.11 | 5.48 | -10.76 | 173.90 | 54.78 | 261.53 | 0.8136 | 642.2 | 575.2 | |
| 14.20 | -5.00 | 12.06 | -5.00 | -11.75 | 174.02 | 54.90 | 260.31 | 0.8148 | 909.7 | 999999 | |
| 0.96 | -7.00 | 0.81 | -7.00 | -10.88 | 173.56 | 54.44 | 261.38 | 0.8102 | 721.7 | 999999 | |
| 0.00 | 1.23 | 0.00 | 1.03 | -11.11 | 173.41 | 54.29 | 261.10 | 0.8087 | 726.0 | 623.6 | |
| 0.00 | 0.79 | 0.00 | 0.66 | -11.28 | 173.25 | 54.12 | 260.89 | 0.8070 | 693.0 | 623.2 | |
| 0.00 | 0.88 | 0.00 | 0.73 | -11.44 | 173.19 | 54.06 | 260.70 | 0.8064 | 708.0 | 615.4 | |
| 0.00 | 1.31 | 0.00 | 1.09 | -11.40 | 172.97 | 53.84 | 260.75 | 0.8042 | 776.0 | 646.9 | |
| 0.00 | 0.88 | 0.00 | 0.73 | -11.87 | 173.10 | 53.98 | 260.16 | 0.8055 | 386.0 | 373.2 | |
| 37.07 | 259.40 | 31.26 | 219.08 | -13.86 | 173.62 | 54.50 | 257.70 | 0.8112 | 1053.7 | 310.0 | |
| 0.00 | 0.70 | 0.00 | 0.58 | -11.56 | 172.49 | 53.37 | 260.54 | 0.7993 | 139.0 | 202.6 | |
| 0.88 | -15.00 | 0.73 | -15.00 | -14.89 | 172.82 | 53.70 | 256.39 | 0.8036 | 735.2 | 999999 | |
| 2.80 | 5.96 | 2.26 | 4.79 | -12.22 | 171.60 | 52.48 | 259.70 | 0.7902 | 602.2 | 594.1 | |
| 0.00 | 1.93 | 0.00 | 1.57 | -14.76 | 172.20 | 53.08 | 256.51 | 0.7972 | 702.0 | 686.7 | |
| 0.00 | 0.70 | 0.00 | 0.56 | -12.86 | 170.93 | 51.81 | 258.86 | 0.7832 | -375.0 | -321.6 | |
| 0.00 | 0.79 | 0.00 | 0.61 | -9.18 | 170.04 | 50.92 | 263.60 | 0.7734 | 116.0 | 156.1 | |
| 0.00 | 1.23 | 0.00 | 0.97 | -12.97 | 170.71 | 51.59 | 258.71 | 0.7810 | -300.0 | -325.1 | |
| 0.00 | 1.31 | 0.00 | 1.03 | -12.69 | 170.39 | 51.27 | 259.05 | 0.7774 | 644.0 | 604.4 | |
| 0.00 | 1.05 | 0.00 | 0.85 | -17.13 | 171.80 | 52.68 | 253.50 | 0.7948 | -601.0 | -438.4 | |
| 0.00 | 0.96 | 0.00 | 0.75 | -13.00 | 170.03 | 50.91 | 258.65 | 0.7737 | -263.0 | -235.1 | |
| 0.00 | 1.23 | 0.00 | 0.94 | -12.82 | 169.25 | 50.13 | 258.84 | 0.7651 | -225.0 | -204.1 | |
| 0.00 | 1.31 | 0.00 | 0.99 | -12.88 | 168.60 | 49.48 | 258.73 | 0.7579 | 776.0 | 670.7 | |
| 0.00 | 1.05 | 0.00 | 0.79 | -13.43 | 168.18 | 49.06 | 257.97 | 0.7535 | -387.0 | -390.6 | |
| 0.00 | 0.96 | 0.00 | 0.72 | -13.23 | 167.70 | 48.58 | 258.21 | 0.7481 | 727.0 | 601.4 | |
| 0.00 | 0.79 | 0.00 | 0.58 | -13.61 | 167.48 | 48.36 | 257.68 | 0.7458 | -664.0 | -506.4 | |
| 0.00 | 0.79 | 0.00 | 0.58 | -13.94 | 167.20 | 48.08 | 257.22 | 0.7428 | -512.0 | -416.2 | |
| 0.00 | 1.05 | 0.00 | 0.77 | -13.77 | 167.02 | 47.89 | 257.43 | 0.7406 | -517.0 | -425.2 | |
| 0.00 | 0.88 | 0.00 | 0.64 | -13.52 | 166.81 | 47.69 | 257.76 | 0.7380 | -428.0 | -333.3 | |
| 0.00 | 0.96 | 0.00 | 0.70 | -12.39 | 166.48 | 47.36 | 259.27 | 0.7336 | 623.0 | 502.9 | |
| 1.14 | 5.00 | 0.83 | 3.65 | -13.92 | 166.73 | 47.61 | 257.21 | 0.7375 | -798.2 | -593.4 | |
| 0.00 | 1.14 | 0.00 | 0.83 | -13.01 | 166.36 | 47.24 | 258.42 | 0.7325 | 779.0 | 658.2 | |
| 0.00 | 1.05 | 0.00 | 0.77 | -14.86 | 166.77 | 47.64 | 255.93 | 0.7387 | -375.0 | -348.8 | |
| 0.00 | 0.44 | 0.00 | 0.31 | -12.84 | 165.82 | 46.70 | 258.61 | 0.7261 | 670.0 | 562.8 | |
| 0.00 | 1.05 | 0.00 | 0.74 | -13.58 | 164.53 | 45.41 | 257.47 | 0.7114 | -351.0 | -393.8 | |
| 0.00 | 0.88 | 0.00 | 0.60 | -9.74 | 163.32 | 44.19 | 262.88 | 0.6947 | 557.0 | 474.7 | |
| 0.00 | 0.53 | 0.00 | 0.36 | -12.54 | 163.46 | 44.34 | 258.85 | 0.6977 | -454.0 | -444.3 | |
| 0.00 | 0.96 | 0.00 | 0.67 | -13.33 | 163.55 | 44.43 | 257.74 | 0.6994 | -588.0 | -481.3 | |
| 0.00 | 0.79 | 0.00 | 0.54 | -12.53 | 163.29 | 44.17 | 258.86 | 0.6956 | -644.0 | -507.7 | |
| 0.00 | 0.96 | 0.00 | 0.66 | -13.01 | 163.27 | 44.15 | 258.16 | 0.6957 | -629.0 | -551.5 | |
| 0.00 | 1.31 | 0.00 | 0.89 | -11.87 | 162.35 | 43.22 | 259.74 | 0.6834 | -84.0 | -199.5 | |
| 0.00 | 1.14 | 0.00 | 0.77 | -13.48 | 162.39 | 43.27 | 257.39 | 0.6853 | -629.0 | -542.0 | |
| 0.00 | 1.58 | 0.00 | 1.06 | -14.28 | 161.85 | 42.73 | 256.15 | 0.6796 | -576.0 | -479.8 | |
| 0.00 | 1.40 | 0.00 | 0.94 | -13.49 | 161.42 | 42.30 | 257.26 | 0.6733 | -659.0 | -549.4 | |
| 0.00 | 0.44 | 0.00 | 0.29 | -14.87 | 161.70 | 42.58 | 255.26 | 0.6785 | -452.0 | -452.0 | |
| 0.00 | 1.49 | 0.00 | 1.00 | -15.71 | 161.45 | 42.32 | 253.97 | 0.6767 | -560.0 | -478.8 | |
| 0.00 | 0.96 | 0.00 | 0.64 | -14.35 | 160.87 | 41.74 | 255.89 | 0.6674 | -509.0 | -435.1 | |
| 0.00 | 0.79 | 0.00 | 0.52 | -13.04 | 160.50 | 41.38 | 257.81 | 0.6611 | -719.0 | -538.8 | |
| 0.00 | 2.98 | 0.00 | 1.98 | -15.21 | 160.86 | 41.74 | 254.62 | 0.6686 | -584.0 | -499.1 | |
| 0.00 | 0.96 | 0.00 | 0.63 | -13.22 | 160.25 | 41.13 | 257.52 | 0.6581 | -711.0 | -618.4 | |
| 0.00 | 0.88 | 0.00 | 0.58 | -15.29 | 160.55 | 41.42 | 254.43 | 0.6648 | -585.0 | -449.2 | |
| 0.00 | 1.58 | 0.00 | 1.03 | -12.91 | 159.90 | 40.78 | 257.95 | 0.6533 | -736.0 | -619.5 | |
| 0.00 | 4.29 | 0.00 | 2.79 | -14.03 | 159.48 | 40.36 | 256.16 | 0.6493 | -687.0 | -506.0 | |
| 0.00 | 0.88 | 0.00 | 0.56 | -13.78 | 158.78 | 39.66 | 256.44 | 0.6399 | -826.0 | -615.4 | |
| 0.00 | 0.44 | 0.00 | 0.29 | -19.56 | 158.58 | 39.46 | 247.52 | 0.6504 | -550.0 | -548.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
