SDO HMI 2014-03-30 20:00:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 10.18 | 47.32 | 32.60 | 137.71 | -11.20 | 18.12 | -81.22 | 100.27 | 0.9852 | -265.5 | -120.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-30 20:00:31 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.28 | 9.55 | 4.80 | 19.71 | -10.04 | 21.98 | -77.36 | 98.78 | 0.9732 | 101.0 | 316.7 | |
| 0.44 | 6.31 | 1.05 | 15.54 | -11.08 | 20.27 | -79.07 | 99.97 | 0.9793 | 267.2 | 14.3 | |
| 0.53 | 2.98 | 1.35 | 7.59 | -11.63 | 19.48 | -79.86 | 100.60 | 0.9818 | 61.7 | 54.8 | |
| 0.00 | 1.49 | 0.00 | 3.58 | -10.40 | 20.29 | -79.05 | 99.28 | 0.9794 | -162.0 | -179.6 | |
| 0.00 | 2.72 | 0.00 | 6.84 | -10.62 | 19.73 | -79.60 | 99.54 | 0.9812 | -382.0 | -355.8 | |
| 0.00 | 1.84 | 0.00 | 4.72 | -10.92 | 19.41 | -79.93 | 99.88 | 0.9822 | -541.0 | -396.7 | |
| 0.00 | 0.53 | 0.00 | 1.37 | -9.88 | 19.44 | -79.90 | 98.82 | 0.9824 | -284.0 | -306.2 | |
| 0.53 | 4.99 | 1.43 | 13.85 | -9.99 | 18.77 | -80.57 | 98.99 | 0.9844 | -352.0 | -324.0 | |
| 6.40 | 16.91 | 23.97 | 64.51 | -11.94 | 15.71 | -83.63 | 101.23 | 0.9919 | -362.7 | -211.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
