SDO HMI 2014-03-31 23:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 203.55 | 752.57 | 103.37 | 382.06 | -13.10 | 73.78 | -10.71 | 123.17 | 0.2163 | -42.1 | -26.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-03-31 23:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.32 | 0.00 | 0.66 | -12.45 | 78.28 | -6.21 | 134.31 | 0.1482 | 698.0 | 560.8 | |
| 0.00 | 1.23 | 0.00 | 0.62 | -12.72 | 78.21 | -6.28 | 135.30 | 0.1523 | 743.0 | 594.4 | |
| 0.00 | 1.75 | 0.00 | 0.88 | -11.84 | 77.74 | -6.75 | 128.85 | 0.1483 | 955.0 | 731.2 | |
| 0.00 | 1.93 | 0.00 | 0.97 | -11.68 | 77.25 | -7.24 | 126.12 | 0.1534 | 1130.0 | 921.5 | |
| 0.00 | 2.46 | 0.00 | 1.23 | -11.86 | 77.19 | -7.30 | 126.82 | 0.1561 | 886.0 | 790.0 | |
| 0.00 | 5.17 | 0.00 | 2.61 | -13.72 | 76.91 | -7.58 | 134.42 | 0.1802 | 943.0 | 795.7 | |
| 0.00 | 4.82 | 0.00 | 2.42 | -11.56 | 76.98 | -7.51 | 124.47 | 0.1560 | 884.0 | 803.1 | |
| 0.00 | 1.84 | 0.00 | 0.93 | -13.69 | 76.60 | -7.89 | 133.15 | 0.1836 | 746.0 | 518.7 | |
| 0.00 | 0.70 | 0.00 | 0.35 | -11.43 | 76.55 | -7.94 | 122.37 | 0.1610 | 833.0 | 650.6 | |
| 5.17 | 333.88 | 2.60 | 168.17 | -12.42 | 76.40 | -8.09 | 126.85 | 0.1726 | 1421.5 | 426.0 | |
| 35.87 | -10.00 | 18.06 | -10.00 | -12.90 | 76.35 | -8.14 | 128.91 | 0.1782 | 1280.5 | 999999 | |
| 19.03 | -10.00 | 9.58 | -10.00 | -12.47 | 76.08 | -8.40 | 126.11 | 0.1774 | 1314.5 | 999999 | |
| 22.36 | -10.00 | 11.28 | -10.00 | -12.80 | 75.55 | -8.94 | 125.92 | 0.1880 | 1199.6 | 999999 | |
| 0.00 | 0.79 | 0.00 | 0.40 | -14.39 | 75.39 | -9.10 | 131.91 | 0.2068 | 627.0 | 492.7 | |
| 5.53 | -10.00 | 2.79 | -10.00 | -12.25 | 75.35 | -9.14 | 122.90 | 0.1857 | 823.3 | 999999 | |
| 0.96 | -10.00 | 0.49 | -10.00 | -12.03 | 75.11 | -9.38 | 121.25 | 0.1873 | 858.7 | 999999 | |
| 2.02 | -10.00 | 1.02 | -10.00 | -12.33 | 74.94 | -9.55 | 122.18 | 0.1923 | 559.3 | 999999 | |
| 0.00 | 5.70 | 0.00 | 2.88 | -13.48 | 74.86 | -9.62 | 126.85 | 0.2041 | 31.0 | 109.1 | |
| 0.96 | -10.00 | 0.49 | -10.00 | -11.97 | 74.86 | -9.63 | 120.33 | 0.1904 | 788.4 | 999999 | |
| 0.00 | 0.44 | 0.00 | 0.22 | -10.70 | 74.72 | -9.77 | 113.86 | 0.1831 | 746.0 | 580.0 | |
| 0.00 | 1.32 | 0.00 | 0.66 | -11.35 | 74.05 | -10.44 | 115.62 | 0.1980 | -837.0 | -698.0 | |
| 0.00 | 8.16 | 0.00 | 4.13 | -11.77 | 73.78 | -10.71 | 116.97 | 0.2050 | -25.0 | -149.4 | |
| 0.00 | 1.05 | 0.00 | 0.53 | -13.78 | 73.66 | -10.83 | 124.96 | 0.2236 | 610.0 | 400.2 | |
| 2.72 | 93.31 | 1.38 | 47.48 | -13.42 | 73.55 | -10.94 | 123.31 | 0.2218 | -885.1 | -422.5 | |
| 0.00 | 0.96 | 0.00 | 0.49 | -15.86 | 73.33 | -11.16 | 131.31 | 0.2489 | -815.0 | -695.8 | |
| 0.00 | 1.32 | 0.00 | 0.67 | -15.65 | 73.15 | -11.34 | 130.20 | 0.2489 | -927.0 | -752.3 | |
| 0.00 | 1.67 | 0.00 | 0.84 | -11.61 | 73.29 | -11.20 | 115.30 | 0.2114 | -601.0 | -486.1 | |
| 4.21 | -24.00 | 2.14 | -24.00 | -13.80 | 72.94 | -11.55 | 123.37 | 0.2339 | -476.0 | 999999 | |
| 0.00 | 1.58 | 0.00 | 0.81 | -15.79 | 72.76 | -11.73 | 129.73 | 0.2554 | -753.0 | -612.8 | |
| 0.00 | 0.79 | 0.00 | 0.40 | -12.44 | 72.94 | -11.55 | 118.14 | 0.2227 | -783.0 | -623.7 | |
| 4.12 | -24.00 | 2.10 | -24.00 | -13.22 | 72.87 | -11.62 | 121.07 | 0.2299 | -1175.7 | 999999 | |
| 5.35 | -24.00 | 2.72 | -24.00 | -13.46 | 72.86 | -11.63 | 121.96 | 0.2321 | -883.8 | 999999 | |
| 15.35 | -24.00 | 7.81 | -24.00 | -12.98 | 72.66 | -11.82 | 119.71 | 0.2309 | -1070.0 | 999999 | |
| 0.00 | 0.96 | 0.00 | 0.49 | -15.84 | 72.44 | -12.05 | 129.17 | 0.2602 | -690.0 | -581.8 | |
| 0.00 | 1.84 | 0.00 | 0.94 | -15.51 | 72.34 | -12.15 | 127.88 | 0.2582 | -914.0 | -741.9 | |
| 2.10 | 10.35 | 1.07 | 5.28 | -13.87 | 72.24 | -12.25 | 122.18 | 0.2444 | -1211.2 | -788.7 | |
| 0.00 | 2.37 | 0.00 | 1.21 | -14.47 | 72.17 | -12.31 | 124.15 | 0.2506 | -148.0 | -196.8 | |
| 1.05 | 4.39 | 0.54 | 2.24 | -13.29 | 72.02 | -12.47 | 119.66 | 0.2429 | -1067.8 | -801.6 | |
| 0.00 | 1.40 | 0.00 | 0.71 | -11.60 | 71.98 | -12.51 | 113.08 | 0.2317 | -472.0 | -414.9 | |
| 0.00 | 2.10 | 0.00 | 1.07 | -11.39 | 71.89 | -12.59 | 112.09 | 0.2317 | -1008.0 | -835.8 | |
| 2.81 | 64.20 | 1.43 | 32.83 | -12.68 | 71.52 | -12.97 | 116.51 | 0.2458 | -1199.6 | -740.0 | |
| 3.16 | -41.00 | 1.61 | -41.00 | -12.86 | 71.51 | -12.98 | 117.16 | 0.2473 | -1205.2 | 999999 | |
| 41.04 | 174.70 | 21.04 | 89.65 | -14.03 | 71.35 | -13.14 | 121.03 | 0.2586 | -1211.7 | -376.4 | |
| 3.86 | 10.26 | 1.97 | 5.24 | -11.95 | 71.30 | -13.19 | 113.42 | 0.2443 | -1118.7 | -758.2 | |
| 11.49 | -41.00 | 5.88 | -41.00 | -12.78 | 71.10 | -13.39 | 116.24 | 0.2529 | -1122.5 | 999999 | |
| 7.37 | -41.00 | 3.77 | -41.00 | -12.39 | 71.09 | -13.40 | 114.79 | 0.2504 | -1122.3 | 999999 | |
| 5.44 | -43.00 | 2.79 | -43.00 | -13.62 | 70.80 | -13.69 | 118.70 | 0.2634 | -1016.7 | 999999 | |
| 1.58 | -43.00 | 0.81 | -43.00 | -13.92 | 70.62 | -13.87 | 119.41 | 0.2682 | -882.8 | 999999 | |
| 0.00 | 1.49 | 0.00 | 0.77 | -12.97 | 70.33 | -14.16 | 115.75 | 0.2658 | -1071.0 | -886.8 | |
| 0.00 | 3.86 | 0.00 | 1.98 | -13.21 | 70.22 | -14.27 | 116.40 | 0.2691 | -783.0 | -651.5 | |
| 0.00 | 2.46 | 0.00 | 1.30 | -18.31 | 67.22 | -17.27 | 126.48 | 0.3521 | -808.0 | -653.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
